86mm 48V 600W High Torque Brushless DC Motor

Name: 86mm 48V 600W High Torque Brushless DC Motor
Brand: all-electronics-online.com
SKU: 678539462
Availability: InStock
Rating: 4.8 (131 reviews)

Price:	US $ 75.8-130/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	86BLF
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Eastern Asia,Western Europe
Structure And Working Principle:	Brushless
Operating Speed:	Constant Speed
Application:	Universal

Product Description

Brushless Motor:

We have brushless DC motor with following information

1) Voltage: 12V, 24V(36V, 48V, 110V, 310V)
2) Output power: 1W, 5W, 10W, 15W, 20W, 25W, 30W, 50W, 60W, 100W, 150W, 200W, 250W, 300W, 500W, 600W, 1000W)
3) Speed: 1500-8000rpm
4) Rated torque: 0.01-6 N. M
5) Motor Dia: 28mm, 33mm, 36mm, 42mm, 57mm, 60mm, 80mm, 86m, 110mm, 130mm
6) Lenth: 26mm-165mm
7) Can with driver

8) Note: Technical datasheet and Price range are only for reference, It's decide by the motor's torque, Body length and so on, Please contact with me ask for the excat price

Model	86BLF07	86BLF06	86BLF01	86BLF02	86BLF03	86BLF04
Number of Poles	8
Number of Phases	3
Nominal voltage VDC	48
Rated speed RPM	3000
Rated Torque N-m	2.1	1.8	1.4	1.05	0.7	0.35
Rated Current Amps	22	18	14	9.6	6.6	3.9
Output Power Watts	660	550	440	330	220	110
Peak Tourque1 N-m	6.3	5.4	4.2	3.2	2.1	1.05
Peak Current Amps	55	46	38.0	29.0	19.8	10.8
Torque constant N-m/A	0.116	0.115	0.115	0.115	0.112	0.11
Back EMF V/kRPM	12.2	12.0	12.0	12.0	11.8	11.5
Rotor inertia g· cm²	1850	1550	1250	950	650	350
Body Length(L) mm	124	109	94	81	67	57
Mass kg	4.8	3.2	2.75	2.2	1.75	1.1

Ningbo Leison Motor Co. Ltd is a manufacturer and exporter of virious of motors,

Our Product range are:

DC Brush motor: 6-130mm diameter, 0.01-1500W output power.

DC Spur Gear Motor: 12-110mm diameter, 0.1-300W output power

DC Planeary Gear Motor: 10-82mm diameter, 0.1-1000W output power

Brushless DC Motor: 28-110mm, 5-1000W output power

Stepper Motor: NEMA 08 to NEMA 43, Can with gearox and lead screw

AC Gear Motor: 49 to 100mm diameter, 6-140 output power

Compare with other competitors, Our advantages are:

1) High Quality Guarantee: 10 years experiences in this field makes us have mature manufacturing process, Most of motors have CE, RoHS marks.

2) Competitive Price: We have a very high competitive ability of the list prices based on low cost labour force in China.

3) Good Service: LEISON MOTOR sales are professional and with good attitude, We will response with our customer within 24 hours(Holiday excepted), So you don' T need way about can' T not find the person when have agent things.

4) On Time Delivery: The delay delivery always are a headache problem for most of buyers, Our technical team and sales team make us can promise about 95% delivery on time.

5) Customized requirement: Beside normal products, We also design the motors according to customer requirement. Meanwhlile our MOQ is very low, (Even 1PC for some motors).

Still need more reasons? Now begin business with LEISON MOTOR, You will find we are a reliable and trustworthy in China.
