8s Li-ion/Li-Polymer/LiFePO4 Battery Protection Circuit Module

Name: 8s Li-ion/Li-Polymer/LiFePO4 Battery Protection Circuit Module
Brand: all-electronics-online.com
SKU: 727873835
Availability: InStock
Rating: 5 (45 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,EXW
Min Order:	3/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	306(8S)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Delivery Date:	15days
Warranty:	One Year
Use For:	Lithium Battery/LiFePO4 Battery
Size:	L140W85T9mm
Customized:	Non-Customized
Condition:	New
Metal Coating:	No
Mode Of Production:	DIP-SMT

Product Description

8s Li-ion/Li-Polymer/LiFePO4 Battery Protection Circuit Module

Voltage

33.6v li-ion battery, 28.8v lifepo4 battery

Specification
Voltage: Charging voltage: CC/CV:
Li-ion/Li-polymer(4.2V/cell);
LiFePO4(3.6V/cell)
Balance voltage for single cellLi-ion: 4.20 V± 0.025V,
LiFePO4: 3.60V± 0.025V

2CurrentBalance current for single cell 0~85mA
Balance current for single cell ≤ 20μ A
Maximal continuous charging and discharging current 16A

3Over-charge ProtectionOver charge detection voltage 3.8~4.4V(can adjust)
Over charge detection delay time 0.5~2.5S
Over charge release voltage3.8~4.4V(can adjust)

4Over-discharge ProtectionOver discharge detection voltage1.9~3.1V(can adjust)
Over discharge detection delay time50~300mS
Over discharge release voltage1.9~3.1V(can adjust)

5Over-Current ProtectionOver current detection voltage0.6V
Over current detection current20~100A
Detection delay time1~50ms
Release conditionCut load

6Short ProtectionDetection conditionExterior short circuit
Detection delay time200-500us
Release conditionCut load

7ResistanceProtection circuitry(B- to P-)≤ 20mΩ

8TemperatureOperating temperature range-40~+85° C
Storage temperature range-40~+125° C

9Size
L140*W85*T9mm
