| Prod Model: |
A7, F7, |
| Power Dissipation: |
200 |
| Peake Reverse Voltage: |
30 |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
N-type Semiconductor |
| Package: |
PGA(',Pin Grid Array Package) |
| Model: |
Bat54ws |
| Batch Number: |
2016 |
| Brand: |
Sy |
Product Description
| TYPE | Maximum Peak | Maximum Average | Maximum Forward | Maximum Reverse | Maximum Forward | Maximum | Package |
| Reversee | Rectified | Prak Surge Current | Current | Voltage | Reverse |
| Voltag | Current | @8.3ms Superimposed | @VRRM TA=25ºC | TA=25ºC | Recovery Time |
| VRRM | I(AV) | IFSM | IR | IF | VF | trr |
| V | A | A | μA | A | V | ns |
| SOD4001 | 50 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- | SOD-123FL |
| SOD4002 | 100 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| SOD4003 | 200 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| SOD4004 | 400 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| SOD4005 | 600 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| SOD4006 | 800 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| SOD4007 | 1000 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| DSR1A | 50 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| DSR1B | 100 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| DSR1D | 200 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| DSR1G | 400 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| DSR1J | 600 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| DSR1K | 800 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| DSR1M | 1000 | 1.0 | 25 | 5.0 | 1.0 | 1.1 | -- |
| RS07A | 50 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| RS07B | 100 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| RS07D | 200 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| RS07G | 400 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| RS07J | 600 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 250 |
| RS07K | 800 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 500 |
| RS07M | 1000 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 500 |
| FFM101-M | 50 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| FFM102-M | 100 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| FFM103-M | 200 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| FFM104-M | 400 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 150 |
| FFM105-M | 600 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 250 |
| FFM106-M | 800 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 500 |
| FFM107-M | 1000 | 1.0 | 25 | 5.0 | 1.0 | 1.3 | 500 |
| US1AL | 50 | 1.0 | 25 | 5.0 | 1.0 | 1.00 | 50 |
| US1BL | 100 | 1.0 | 25 | 5.0 | 1.0 | 1.00 | 50 |
| US1DL | 200 | 1.0 | 25 | 5.0 | 1.0 | 1.00 | 50 |
| US1GL | 400 | 1.0 | 25 | 5.0 | 1.0 | 1.30 | 50 |
| US1JL | 600 | 1.0 | 25 | 5.0 | 1.0 | 1.70 | 70 |
| US1KL | 800 | 1.0 | 25 | 5.0 | 1.0 | 1.70 | 70 |
| US1ML | 1000 | 1.0 | 25 | 5.0 | 1.0 | 1.70 | 70 |
| ES1AL | 50 | 1.0 | 25 | 5.0 | 1.0 | 0.95 | 35 |
| ES1BL | 100 | 1.0 | 25 | 5.0 | 1.0 | 0.95 | 35 |
| ES1CL | 150 | 1.0 | 25 | 5.0 | 1.0 | 0.95 | 35 |
| ES1DL | 200 | 1.0 | 25 | 5.0 | 1.0 | 0.95 | 35 |
| ES1EL | 300 | 1.0 | 25 | 5.0 | 1.0 | 1.25 | 35 |
| ES1GL | 400 | 1.0 | 25 | 5.0 | 1.0 | 1.25 | 35 |
| ES1JL | 600 | 1.0 | 25 | 5.0 | 1.0 | 1.70 | 35 |
| MBRS120 | 20 | 1.0 | 25 | 1.0 | 1.0 | 0.50 | -- |
| MBRS130 | 30 | 1.0 | 25 | 1.0 | 1.0 | 0.50 | -- |
| MBRS140 | 40 | 1.0 | 25 | 1.0 | 1.0 | 0.50 | -- |
| MBRS150 | 50 | 1.0 | 25 | 1.0 | 1.0 | 0.70 | -- |
| MBRS160 | 60 | 1.0 | 25 | 1.0 | 1.0 | 0.70 | -- |
| MBRS180 | 80 | 1.0 | 25 | 1.0 | 1.0 | 0.85 | -- |
| MBRS1100 | 100 | 1.0 | 25 | 1.0 | 1.0 | 0.85 | -- |
| SS2020FL | 20 | 2.0 | 30 | 1.0 | 2.0 | 0.50 | -- |
| SS2030FL | 30 | 2.0 | 30 | 1.0 | 2.0 | 0.50 | -- |
| SS2040FL | 40 | 2.0 | 30 | 1.0 | 2.0 | 0.50 | -- |
| SS2050FL | 50 | 2.0 | 30 | 1.0 | 2.0 | 0.70 | -- |
| SS2060FL | 60 | 2.0 | 30 | 1.0 | 2.0 | 0.70 | -- |
| SS2080FL | 80 | 2.0 | 30 | 1.0 | 2.0 | 0.85 | -- |
| SS20100FL | 100 | 2.0 | 30 | 1.0 | 2.0 | 0.85 | -- |
