AC DC 12V F24-60 Industrial Radio Wireless Dual Joystick Remote Control

Prod Model:	F24-60
Product Name:	Industrial Wireless Radio Remote Control
Unique Code:	Over 4.3billon Unique ID Codes
Temperature Range:	-35ºC-----------+80ºC
Application:	Hoist
Signal Transmission:	RF Remote Control
Type:	Button
Certification:	CE
Universal:	Universal
Transmission Distance:	>100m
Voltage:	3V
Battery Type:	AA Battery
Material:	Glass Fiber

Product Description

Product Description
  Ac DC 12v f24-60 industrial radio wireless dual joystick remote control

Brife introduction
1.More than 10 years researching and exporting experience in radio remote control industry.
2.More than 20 people r&d working team, have the ability to research and develop new product independently.
3.Have 15 production lines.We also have many production machines such printing circuit board machine, smt
Machine, automatic wave soldering machine, automatic soldering robot, etc.Also have many testing machine.
4.Well and high quality control, all working process according to iso9001:2008.
5.Ce, fcc & iso certificates.
6.Oem acceptable
7.One year warranty


Specification

Application	Overhead cranes, hoist, chain hoist and other industrial machine.
Frequency	310.0325~331.165mhz
Frequency generation:	Crystal (plug in)
Channel	80
Channel spacing	0.2675mhz
Control motions	40
Control distance	Up to 100m
Certificates	Ce, fcc, iso9001:2008
Number of push button	Dual speed joystick
Unique code	Over 4.3billon unique id codes.
Working temperature	-35°c ~ +80°c
Enclosure protection class	Ip65
Transmitter power	Aa-size batteries
Receiver power	Ac 380v/220v/110v/48v/ 36v/24v or ac/dc12v
Output capacity	Full sealed relay output with 5 amperes
Warranty	1 year
Material	Glass fiber

Standard configuration:
One transmitter;
One receiver;
One 1m cable connect with receiver
One operation and maintain manual.

application:
Widely applied for lifting equipments, construction machinery, cargo loading/unloading machines, water supply system,
Data transmission, the iron-smelting and steel-making, the automobile manufacturing, papermaking and chemical industry,
Steel structure processing, galvanization, shipbuilding, railroad, bridge, tunnel construction and other equipments and sites
Which can be worked by radio controls.


Certificates:
CE,FCC,ISO9001:2008

Notes:
The led on the front of the transmitter indicates the condition of the batteries.It will flash green during operation if the battery power is sufficient, and will flash red if the battery power is low.If the led is flashing red, or if the operation becomes erratic,
Or will only work from a short distance, replace both batteries with new aa alkaline batteries.
