AC/DC 12V7a84W Desktop Power Supply Adapter for Notebbook

Name: AC/DC 12V7a84W Desktop Power Supply Adapter for Notebbook
Brand: all-electronics-online.com
SKU: 836684485
Availability: InStock
Rating: 5 (124 reviews)

Price:	US $ 7.99-9.99/Piece
Min Order:	500/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FAS-84W-12V-D
Efficiency:	84%Min
Protections:	Short Circuit/Overload/Over
Rated Voltage:	5V-48V Optional
Input Voltage:	100~240V AC
Usage:	Consumer Electronic Devices,Telecommunication Devi
Output Type:	DC
Connection:	Desktop
Certification:	ETL
Bluetooth Standard:	N/a
Brand:	Fining

Product Description

12V7A AC/DC desktop power adapter

The power adapter is 90W desktop type adapter series .This product is equipped with a 2-pin
C8 power plug,adopting the input range from 100VAC to 240VAC.The entire series supplies
output voltage between 5VDC and 48VDC that can satisfy the demands for various types of DC
consumer electronic devices.The effiency is not lower than 84% and designed accordion to UL/
CE/FCC safty regulations.

Features:

Universal Input 100-240 VAC
2 pin C8 AC inlet
Output with Low Ripple Noise
Efficiency 88%min
Class II power (without earth pin)
Protections:	Short circuit/Overload/Over voltage
Fully enclosed plastic case
LED indicator for power on
100% full load burn-in test
CE/FCC and RoHS Certified
Desktop Style / Non-vented Case
Case Dimension (LWH mm):	1426235mm
Modified and Custom Design Available
2 years warranty

Iutput Characteristics

Input Voltage:	100~240V AC
Input Voltage Range:	90-264VAC
Rated Input Frequency:	50Hz or 60Hz single phase.
AC Input Frequency Range:	47Hz to 63Hz

Output Characteristics

Rated Voltage:	5V~48V optional
Output voltage regulation precision:	±5%
Loading regulation:	±1%
Ripple :	1% Vp-p max.
Transient Response :	0.5ms for 50% Load Change Typical
Protection:	Fold back Overcurrent Protection; Short Circuit Protection

Environmental Conditions

Operating temperature:	0ºC~40ºC
Operating humidity:	20%~ 90% (Relative humidity).
Storage temperature:	-20ºC ~ 70ºC .
Storage humidity:	5%~ 95% . (Relative humidity).
Cooling:By natural air flow

Immunity

Dielectric Withstand Voltage ( HI-POT ):	HI-POT-A IEC 320 2pin primary to secondary 3000Vac 5mA 1min
Safety Approvals:	CE /RoHS Certified and Designed according to UL/ standards

Reliability

MTBF (Mean-Time-Between-Failures) Calculation:	MTBF shall be 50K hours of continuous operation at 20ºC, maximum load and normal voltage
MTBF Verification:	The MTBF shall be verified from life testing performed by factory Quality Department. The operating conditions are: 40ºC ambient temperature , sea level , both nominal line voltage ranges (230Vac) and a minimum load of 70% of the maximum load.

Our company supplies different kinds of power adapter products to global market with good quality and reasonable price, and very familiar with CE, FCC, UL, ETL standrads.

We have the following advantages:

1. Have cooperated with a lot of importers for more than 6 years.

2. Experenced in handling OEM orders.

3. Qiuck delivery time for decent orders.

4. Own designing team for new products development.

5. Factory audited by SGS, INTERTEK&WEINSPCTION.

6. Free samples could be provided.

We are power adapter manufacture and focusing on providing high efficiency and reliability power supplies. Our main products include PoE(Power over ehternet)products, custom AC/DC power adapters and LED Driver power supply. We can afford custom service according to your requirements.
