Name: AC Motor Tubular Motor 60-140n
Brand: all-electronics-online.com
SKU: 822171815
Availability: InStock
Rating: 4.7 (149 reviews)

Price:	US $ 25/Piece
Min Order:	10/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	MRX59-N-W
Number Of Stator:	Single-Phase
Function:	Control
Application:	Electric Windows and Doors

Product Description

Product description
35/45/59/88/92mm tubular motor for window curtain/shutter/roller shutter blind

1.Stator size is optional
2.Safe, reliable, low noise, good starting, long life
3.Strong power
Rated voltage 5~120v/220~240v-50/60hz
Usage:Roller blinds, venetian blinds, honeycomb blinds, pleated blinds

Electric Tubular Motor Advantages:

Non -malfunction for the brake

Double sided magnetism, cone magnetism, electromagnetism brake system is used in this new type tubular motor in order to meet different customers'requirement. It takes our team many years' research and test for the material of brake system which makes it perfect.

Adopted the plastic sealed technology, all the tubular motor components have the accurate location dimension, low coefficient of the variation, and the service life time can be amounted to 10 years. Advanced design and crafts, the highest torque

Low noise delicate design and manufacture, the tubular motor lowest noise is less than 38dB, nearly silent move is bigger than the similar products in the same condition. Ment.

Strong intensity Adopted the special material, the tubular motor gear is more wear-resisting, toughness and steel feature is more stronger which will increase the service life of the gear box.

Oil proof The sealed structure helped the gear oil hard to leak, ensure the gear works normally longer.

Accurate limit The accuracy for limit is <+-0.5 degree tolerance, limit configuration by screw pole drive makes accuracy for limit <+- 1.5 degree

Large effective limit Reasonable and compact design increases effective distance for limit very much, and the tubular motor effectiveness could reach 50 circles.

Build-in remote control Good quality and stable receiver built in tbular motor not only shorten the installation time, Effective distance for remote control system is more than 30m.

	Model	Voltage/Frequence	Rated Torque	Rated Power Input	Rated Current	Rated Speed
MRX59-N-W Series	MRX59-N-60W	230V/50Hz	60N.m	288W	1.28A	12rpm
	MRX59-N-80W	230V/50Hz	80N.m	350W	1.50A	12rpm
	MRX59-N-100W	230V/50Hz	100N.m	441W	1.94A	12rpm
	MRX59-N-120W	230V/50Hz	120N.m	450W	2.00A	12rpm
	MRX59-N-140W	230V/50Hz	140N.m	465W	2.02A	9rpm

Changsha Saicoo Industrial Limited is an all-round company which mainly produce and sell some newfashioned building materials and home automation products. We have several branch companies(factories) which include: Changsha Tyssun Aluminium Co., Ltd., Changsha Saicoo Window & Door factory, Changsha Saicoo Sun-shading products factory, Changsha Saicoo Motor factory, etc.

Our main products:

1) Aluminium Profiles

2) Aluminium Roller Shutters & other Window/Door Products

3) Retractable Awnings & other Sun-shading Products

4) Rolling Door Motors & other Window/Door Operators

Our company has obtained ISO 9001: 2008 international quality system certifications.

With good quality products, reasonable prices and excellent services, we are making great effort to improve city buildings rank and create wonderful life together with our vast users. We warmly welcome friends all around the world to visit our company and sincerely hope we may establish good cooperation relations together.
