AC Variable Speed Drive (SANYU SY7000 TYPE)

Prod Model:	Sy7000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Voltage&Phase:	0-220V, 0-380V 3pH
Carrier Frequency:	0~15kHz
Output Frequency:	0-600Hz
IP Grade:	20
Weight:	1.8kgs-259kgs
Communication:	RS 485 Modbus
Output Current:	2.5-690A
Input Voltage&Phase:	220V+/-15% 1pH/3pH 380V+/-15% 3pH
Output Power:	0.75-400kw
Size:	210*110*170-1750*685*590
Application:	General Transducer
Output Type:	Triple
Principle Of Work:	Vector Control Transducer
Switch Mode:	PWM Control
Main Circuit Type:	Voltage
Brand:	Sanyu

Product Description

AC Variable Speed Drive (SANYU SY7000 TYPE)


1. AC drive leading manufacturer
2. CE, ISO, SGS, ISO9001
3. Multi-function, high torque AC drive
4. Olympic Application Type
5. Japanese Design

Features:

1. Various control modes and widely used
2. Automatically recognize the motor parameters
3. RS-485 communication inferface, standards, MODBUS protocol
4. PWM flexible energy braking, can quickly halt machine
5. The torque output will be 150% when the frequency is 0.5Hz. More powerful when at low rate, More stable when at high rate.
6. Zero speed torque output
7. Super-silent running
8. 16 segment speed control
9. Quick menu design.

Functions

1. Dual-DSP + MCU + IPM high performance, high reliability
2. Automatic identification of motor parameters, automatic temperature compansation
3. Start by excitation, speed up the rapid response to vector control
4. Speed control and torque control switching online
5. Zero-servo lock function
6. The frequency of carrier wave can be up to 16k, carry out a comprehensive silent running

Widely used in:

MetallurgyChemical
Petroleum
Textile
Electric power
Building materials
Coal
Plastics
Printing and Dyeing
Cable
Washing
Water supply
Heating.

	Item	Specification
Input	Rated voltage; frequency	380V or 220V; 50Hz/60Hz
	Allowed Voltage Working Range	Fluctuation range: 400V+/-15%; Voltage imbalance rate: < 3%
Output	Rated voltage	0-380V or 0-220V
	Frequency	0-600Hz
	Overload capacity	150% of rated current for 60s; 180% of rated current for 1s; 200% of rated current instant protection
Main control performance	Control mode	V/F control, vector control, torque control
	Modulation mode	space voltage vector PWM modulation
	Speed range	1: 100 (vector control without PG)
	Starting torque	180% of rated torque at 0.5HZ(current vector control without PG)
	Speed stabilization accuracy	< +/-0.2% of rated synchronous speed
	Speed fluctuation	< +/-0.5% of rated synchronous speed
	Torque response	< 100ms current vector control without PG
	Torque increase	Automatic torque increase, manual torque increase 0.1%-30%
	V/F curve	Four kinds of acceleration and decoration time: time unit(minute/second)selected; longest time: 60hrs
	Acc/Dec curve	Three modes: Straight-line acceleration and decoration mode, S-curve acceleration and decoration mode, Six modes: one kind of user setting V/F curve, four kinds of decrease torque characteristic curve(2.0Power, 1.7power, 1.5power, 1.3power)and linearity curve
	DC brake	DC braking frequency: 0.0Hz-max output frequency; braking time: 0.0-50s; braking current: 0.0%-150% of rated current.
	Auto voltage regulation	When the network voltage makes the change, it can automatically keep the output voltage constant
	Auto current limiting	It automatically limits current during working to prevent tripping caused by frequent over current
	Voltage stall	Control the voltage during deceleration to prevent over voltage and protect stopping
	Auto carrier regulation	It can automatically regulate carrier frequency according to load characteristic and temperature characteristic; and multiple carrier modes can be selected.
Customization function	Separation VF control	Realizing all kinds of power designs conveniently
	Wobble frequency control	Wobble frequency control for spinning can realize functions of fixed wobble frequency and change wobble frequency
	Frequency combination function	Running command channel and frequency setting channel can be optionally combined
	Fixed length function	Length achieves stop function and the max length is 65.535KM
	Jogging control	Jogging frequency range: 0.00Hz-the Max; Jogging acceleration and deceleration time: 0.1-3600s, jogging inteval time: 0.1-3600s
	Multi-speed running	Realizing multi-speed running via built-in PLC or control terminal
	Built-in process closed loop ctrl	Realizing the process closed control sysytem conveniently
	Power consumption measure	It can calculate electric energy consumed by electric motor to observe energy-saving effect conveniently
Running function	Running command channel	Operation panel, control terminal, serial port, external expansion setting can be shifted via various methods.
	Frequency setting channel	Three kinds of digital settings, analog voltage setting, analog current setting, vital channel setting, terminal setting, multi-segment speed setting and so on.
	Auxiliary frequency setting	Realizing flexible auxiliary frequency fine regulation, frequency synthesis
	Impulse output terminal	0-50Khz of impulse square signal output, it can realize physical quantity output of setting frequency, output frequency and so on.
	Analog output terminal	Two routes of analog signal output, output range can be flexibly set between 0-20mA or 0-10V and it can realize physical quantity output of setting frequency, ouput frequency and so on.
Operation panel	LED display	Displaying sixty-one kinds of parameters of setting frequency, ouput frequency, output voltage and output current
	LCD display	Option, prompting operation content in Chinese/English
	Parameter copy	Quickly uploading and downloading parameter via operation panel. The function is effective only for LCD keyboard.
	Option of key function	Defining function range of part keys to prevent wrong operating
Environment	Protection function	Open-phase protection(option), over-current, over-voltage, low-voltage, overheat, overload, off-load protection, etc.
	Service Location	Indoors, free from direct sunlight, dust, corrosive gas, combustible gas, oil mist, water vapor, drip or salt, etc.
	Altitude	Please use it by derating when it is higher than 1000m and derated 10% per increasing 1000m
	Ambient temp	-10c- 40c (at 40c-50c, please use it by derating)
	Humidity	Less than 95% RH, no water condensation
	Vibration	Less than 5.9m/s2(0.6g)
Structure	Protection level	IP20
	Cooling Mode	Winding cooling, control with fans
	Effiency	45KW and lower than 45KW≥ 93%; 55KW and more than 55KW≥ 95%
