| Prod Model: |
S2800E |
| Markets: |
North America,South America,Southeast Asia |
| Power Rate: |
0.4kw-315kw |
| Voltage: |
220V, 380V |
| Control Mode: |
Vector Control |
| AC Drive: |
AC Motor Drives |
| Phase: |
1 / 3 Phases |
| VSD: |
Variable Speed Drive |
| VFD: |
Variable Frequency Drive |
| Warranty: |
18 Months |
| Multi-Speed Function: |
8 Speeds |
| Carrier Frequency: |
0.5~15kHz |
| Application: |
High Frequency Converter Transducer |
| Output Type: |
Triple |
| Principle Of Work: |
Vector Control Transducer |
| Switch Mode: |
PWM Control |
| Main Circuit Type: |
Current |
| Function: |
General Used |
| Brand: |
Machtric |
Product Description
1. Specification
Model NO. | Rated output power(KW) |
Rated inout current(A) |
Rated output current(A) |
Motor power (KW) |
| 1PH/3PH AC 220V -15%~15% |
| S2800-2T0.4GE | 0.4 | 5.4 | 2.3 | 0.4 |
| S2800-2T0.75GE | 0.75 | 8.2 | 4.5 | 0.75 |
| S2800-2T1.5GE | 1.5 | 14.2 | 7 | 1.5 |
| S2800-2T2.2GE | 2.2 | 23 | 10 | 2.2 |
| S2800-2T3.7GE | 3.7 | 35 | 16 | 3.7 |
| 3PH AC 380V ±15% |
| S2800-4T0.4GE | 0.4/0.75 | 3.4/3.8 | 1.2/2.5 | 0.4/0.75 |
| S2800-4T0.75GE | 0.75/1.5 | 3.8/5.0 | 2.5/3.7 | 0.75/1.5 |
| S2800-4T1.5GE | 1.5/2.2 | 5.0/5.8 | 3.7/5.0 | 1.5/2.2 |
| S2800-4T2.2GE | 2.2/3.7 | 5.8/10.0 | 5.0/9.0 | 2.2/3.7 |
| S2800-4T3.7GE | 3.7/5.5 | 10.0/15.0 | 9.0/13.0 | 3.7/5.5 |
| S2800-4T5.5GE | 5.5/7.5 | 15.0/20.0 | 13.0/17.0 | 5.5/7.5 |
| S2800-4T7.5GE | 7.5/11 | 20.0/26.0 | 13.0/17.0 | 7.5/11 |
| S2800-4T11GE | 11/15 | 26.0/35.0 | 25.0/32.0 | 11/15 |
| S2800-4T15GE | 15/18.5 | 35.0/38.0 | 32.0/37.0 | 15/18.5 |
| S2800-4T18.5GE | 18.5/22 | 38.0/46.0 | 37.0/45.0 | 18.5/22 |
| S2800-4T22GE | 22/30 | 46.0/62.0 | 45.0/60.0 | 22/30 |
| S2800-4T30GE | 30/37 | 62.0/76.0 | 60.0/75.0 | 30/37 |
| S2800-4T37GE | 37/45 | 76.0/90.0 | 75.0/90.0 | 37/45 |
| S2800-4T45GE | 45/55 | 90.0/105.0 | 90.0/110.0 | 45/55 |
| S2800-4T55GE | 55 | 105 | 110 | 55 |
| S2800-4T75GE | 75/90 | 140.0/160.0 | 150.0/176.0 | 75/90 |
| S2800-4T90GE | 90/110 | 160.0/210.0 | 176.0/210.0 | 90/110 |
| S2800-4T110GE | 110/132 | 210.0/240.0 | 210.0/253.0 | 110/132 |
| S2800-4T132GE | 132/160 | 240.0/290.0 | 253.0/300.0 | 132/160 |
| S2800-4T160GE | 160/185 | 290.0/330.0 | 300.0/340.0 | 160/185 |
| S2800-4T185GE | 185/200 | 330.0/370.0 | 340.0/380.0 | 185/200 |
| S2800-4T200GE | 200/220 | 370.0/410.0 | 380.0/420.0 | 200/220 |
| S2800-4T220GE | 220/250 | 410.0/460.0 | 420.0/470.0 | 220/250 |
| S2800-4T250GE | 250/280 | 460.0/500.0 | 470.0/520.0 | 250/280 |
| S2800-4T280GE | 280/315 | 500.0/580.0 | 520.0/600.0 | 280/315 |
| S2800-4T315GE | 315/350 | 580.0/620.0 | 600.0/640.0 | 315/350 |
| S2800-4T350GE | 350/400 | 620.0/670.0 | 640.0/690.0 | 350/400 |
| S2800-4T400GE | 400/450 | 670.0/790.0 | 690.0/790.0 | 400/450 |
| S2800-4T450GE | 450/500 | 790.0/835.0 | 790.0/860.0 | 450/500 |
| S2800-4T500GE | 500/560 | 835.0/920.0 | 860.0/950.0 | 500/560 |
| S2800-4T560GE | 560/630 | 920.0/1050.0 | 950.0/1100.0 | 560/630 |
| S2800-4T630GE | 630/710 | 1050.0/1126.0 | 1100.0/1280.0 | 630/710 |
| S2800-4T710GE | 710/800 | 1126.0/1460.0 | 1280.0/1380.0 | 710/800 |
| S2800-4T800GE | 800/900 | 1460.0/1640.0 | 1380.0/1640.0 | 800/900 |
| S2800-4T900GE | 900/1000 | 1640.0/1800.0 | 1640.0/1720.0 | 900/1000 |
| S2800-4T1000GE | 1000 | 1800 | 1720 | 1000 |
2. Quick details.
Place of OriginFujian, China (Mainland)
Brand Name Machtric
Model Number S2800E
Output Power 0.75kw-160kw
Output TypeTriple
Input Voltage: 380V
Output Voltage: 380V
Type AC-DC-AC
Output Frequency 0.01-600.0Hz
3. ADVANTAGE OF PRODUCTS.
| Monthly production capacity | More than 10000 units. |
| Specification | Customized is accepted. |
| Quality | Implement strict quality testing and control procedure to make superior quality. |
| Delivery | 3-7 days after payment |
| Certification | ISO 9001,ISO14001,OHSAS18001 & CE |
4. Company Advantage
| Advantageness | 10 years OEM/ODM Experience |
| Manufacture in this field for almost 20 years experience. |
| Reasonable price and punctual delivery time |
| 70 R & D personnel have many years experience |
| Received the National Invention Award |
5. Our other products:
1). Computerized control system of textile machines:
Seamless Underwear machine, Computerized Flat Knitting Machine, Glove Machine, Circular Knitting machine, Auto-Stripper Knitting Machine, Hosiery Machine, Automatic Winding Machine, Automatic Spooler Machine etc.
2). Inverter series:
Vector series: Z900, S2800E,S1100VG,S2200E, S3800E series
Universal series: S2800E, S1100VG,S900GS series, S2100S series
Dedicated series: S100 Series, S200 series(circular knitting machine),
Mini Series:S800E
3). Power controller: SPC3 series
4). Knitting panel: SC-2000E, SC-2200M
Feel free to contact us, we will reply very soon.
------Contact Shelly
Machtric Automation Equipment Co., Ltd.
Tel: +86 59522555211-802
Website : http://sanch.en.alibaba.com or www.machtric.com
M.B: +86 15860365439
Quanzhou Machtric Automation Equipment Co., Ltd., together with three leading enterprises and several affiliated organizations in China and Taiwan has been established to supply "Total Project Solutions" in Industrial Automation.Sanch is geared to integrate the development, manufacture and systems engineering for local and international clients alike.
Our professional teams of engineering, product development, manufacturing and integration staff, devote themselves to the development and application of motor, electric, electronic, microelectronic, information and control technology.
We continue to maintain close co-operation with scientific research institutions both at home and abroad, in order to provide "intelligent" products that not only offer the best solutions, but also have a "humanized" approach to functionality.
At present, our manufacturing capacity is over 100 thousand devices per annum.
This includes products such as:
A/C Frequency Inverters (INVERTER)
Thyristor power controller
Circular knitting machine
Intelligent Control Instruments
Peripheral equipment for Industrial Process Control (IPC)
Microcomputer Controllers for various applications and many others.
In order to service the Chinese market, we have already established dozens of marketing, distribution agents and service organizations, to cover the Northern, Eastern, Central and Southern areas.A Pathway Management System and CRM Customer Relationship Centre with high-efficiency logistic and linkage service has also been established.
SANCH have already applied their range of products and services to the following industries;Textile, dye, ceramic, transportation, building, metallurgy, chemical, light, military ---etc.
SANCH philosophy is to continually improve the electric management platform to account for all facets of applications, thus maximising the competitiveness of technology, quality, service and efficiently in accordance with the principle of satisfying our customers and creating excellent products.
SANCH actively promote a philosophy of, maximising production outputs and yet minimizing energy consumption, using modern technological developments.
Our goal is to achieve "Automation---Energy Saving---Green World", and we will try our best to improve the environment and society as a whole.
