Acb Intelligent Circuit Breaker (fixed, drawer)

Name: Acb Intelligent Circuit Breaker (fixed, drawer)
Brand: all-electronics-online.com
SKU: 754410995
Availability: InStock
Rating: 5 (129 reviews)

Price:	US $ 500-3800/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	TSW8-3200
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Current:	2000-6300A
Rated Voltage:	400V / 690V
Number Of Poles:	3, 4
ICU (400V):	80-120ka
ICU (690V):	50-80ka
Ics (400V):	50-100ka
Ics (690V):	40-65ka
Rated Current At N Pole In:	50% in, 100% in
Mounting:	Fixed or Withdrawable
Intelligent Controller:	Standard M Type, Telecommunication H Type
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Structure:	ACB
Poles Number:	3
Certification:	CB

Product Description

APPLICATION

1. TSW8 Intelligent Circuit Breaker is suitable for the circuit of AC 50/60Hz with rated voltage 400V, 690V and rated current up to 6300A.

2. It is mainly used for distribution electric energy as well asprotecting circuit and power supply equipment from overload, under-voltage, short-circuit and single phase earthing.

3. With intelligent and selective protection functions, the breaker can improve the reliability of power supply, and avoide unnecessary power failure.

4. The breaker is applied to power stations, factories, mines (for 690V) and modern high-building, especially to the distribution system of intelligent building.

5. The breakers comply to IEC60947-2.

SPECIFICATION

TYPE		TSW8-2000	TSW8-3200	TSW8-4000	TSW8-6300
Frame Rated Current Inm(A)		2000	3200	4000	6300
Number of Poles		3,4	3,4	3,4	3,4
Rated Current In(A)		630,800,1000, 1250,1600,2000	2000,2500, 2900,3200	3200,3600,4000	4000,5000,6300
Lcu(kA)	400V	80	100	100	120
	690V	50	65	65	80
Lcs=Lcw (kA)	400V	50	80	80	100
	690V	40	50	50	665
Rated Current at N-pole In(A)		50% In, 100% In
Inherent Making & Breaking Time		23-32ms
Operational Performance(Operational)	Electrical Life	500
	Mechanical Life	Maintenance-free 2500 Maintenance 10000
Mounting Mode		Fixed type or Withdrawable type
Arcing Distance(mm)		0
Intelligent Controller		Standard type (M) telecommunication type (H)

WHY US?

1. Clients' benefit first.

2. Experinced in the line for more than 24 years.

3. Reasonable price and good source of raw material.

4. A group of professional inspectors monitor quality.

5. TUV, SEMKO, CE, CB, ROHS Approval for products.

5. Unique design for packing.

6. Experienced salesmen offer one-to-one service.

We are one of the most reliable manufacturers and exporters of low tension electrical items and illumination products in China. We have successfully developed and dealt with numerous electrical products in high quality, such as Circuit Breaker, AC Contact, Panel Enclosure, Electrical Accessories for Panel Enclosure, Pushbutton, Switch, Fuse, Meter, Temperature Controller, Cable Tie, Wiring System products as well as illumination items.

· Qualifications and Technological Strength

We possess full line of high-tech production equipment and great strength of technology support besides advanced designing forces powered by the first class engineering teams with super industrial computer systems. Thus, Our products are novel in designs, excellent in workmanship and tope reliable in quality. A lot of our products have obtained "RoHS", "CB", "CE" and "IRAM", and other international quality approvals. The products now are being well sold in more than 82 countries and regions in the world.

· Contact Us Today

We have always pays special attention to protecting the benefits of clients' so that both the clients ans our company are able to gain the maximum benefits from the relations between us. We warmly look forward to establishing, reinforcing and expanding long term fruitful relationship with the reliable clients all over the world.

Let's get busy and pull together to create a better future.
