Aerial Bundled Twisted Pair Aluminum Wire ABC Power Cable
| Price: |
US $ 0.5-1/Meter |
| Min Order: |
1000/Meter |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
ABC cable |
| Application: |
Construction |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
AC Cable |
| Insulation Material: |
XLPE |
| Certification: |
VDE |
| Model: |
Triplex Service Drop |
| Sheath Material: |
XLPE |
| Brand: |
Jinshui |
| Wire Core Material: |
Aluminum |
Product Description
Low voltage cable wire 4 core overhead insulated power cable 3.37mm Costena
Product Description
The insulated abc cable electrical cables have been widely used in the world with the advantages of the excellent electric properties,Strong ability to resist short circuit,long service life,light weight,without the limit of fall,easy to install,operate and maintain,etc.
The product of Low voltage cable wire 4 core overhead insulated power cable 3.37mm Costenaprimarily used for overhead service applications such as street lighting ,outdoor lighting,and temporary service for construction, Especially suitable for the city streets and greening areas near the building of the power supply and overhead lines,and suit for the operation and management requiements of the rural areas, and the densely populated cities and towns.
The Service drop cable meets or exceeds all applicable requirements of ANSI/ICEA S-76-474.

Specifications of Triplex Service drop
code word | AWG or kcmil | Bare Neutral Messenger | Phase Conductor | Allowable Ampacities(A) |
| ACSR | Rated Strength Ibs. | AAC | Insul. Thick. Mm | XLPE | PE |
| Number | Dia. Mm | Number | Dia. Mm | Number | Dia. Mm |
| Paludina | 2*6AWG+1*6AWG | 1 | 1.68 | 6 | 1.68 | 1190 | 1 | 4.11 | 1.14 | 85 | 70 |
| Voluta | 2*6AWG+1*6AWG | 1 | 1.68 | 6 | 1.68 | 1190 | 7 | 1.56 | 1.14 | 85 | 70 |
| Whelk | 2*4AWG+1*4AWG | 1 | 2.12 | 6 | 2.12 | 1860 | 1 | 5.19 | 1.14 | 115 | 90 |
| Periwinkle | 2*4AWG+1*4AWG | 1 | 2.12 | 6 | 2.12 | 1860 | 7 | 1.96 | 1.14 | 115 | 90 |
| Conch | 2*2AWG+1*2AWG | 1 | 2.67 | 6 | 2.67 | 2850 | 7 | 2.47 | 1.14 | 150 | 120 |
| Neritina | 2*1/0AWG+1*1/0AWG | 1 | 3.37 | 6 | 3.37 | 4380 | 7 | 3.12 | 1.52 | 205 | 160 |
| Cenia | 2*1/0AWG+1*1/0AWG | 1 | 3.37 | 6 | 3.37 | 4380 | 19 | 1.89 | 1.52 | 205 | 160 |
Specifications of Quadruplex Service Drop
code word | AWG or kcmil | Bare Neutral Messenger | Phase Conductor | Allowable Ampacities(A) |
| ACSR | Rated Strength Ibs. | AAC | Insul. Thick. Mm | XLPE | PE |
| Number | Dia. Mm | Number | Dia. Mm | Number | Dia. Mm |
| Morochuca | 3*6AWG+1*6AWG | 1 | 1.68 | 6 | 1.68 | 1190 | 1 | 4.11 | 1.14 | 85 | 70 |
| Chola | 3*6AWG+1*6AWG | 1 | 1.68 | 6 | 1.68 | 1190 | 7 | 1.56 | 1.14 | 85 | 70 |
| Morgan | 3*4AWG+1*4AWG | 1 | 2.12 | 6 | 2.12 | 1860 | 1 | 5.19 | 1.14 | 115 | 90 |
| Hackney | 3*4AWG+1*4AWG | 1 | 2.12 | 6 | 2.12 | 1860 | 7 | 1.96 | 1.14 | 115 | 90 |
| Palomino | 3*2AWG+1*2AWG | 1 | 2.67 | 6 | 2.67 | 2850 | 7 | 2.47 | 1.14 | 150 | 120 |
| Costena | 3*1/0AWG+1*1/0AWG | 1 | 3.37 | 6 | 3.37 | 4380 | 19 | 1.89 | 1.52 | 205 | 140 |
| Grullo | 3*2/0AWG+1*2/0AWG | 1 | 3.78 | 6 | 3.78 | 5310 | 19 | 2.13 | 1.52 | 205 | 160 |
| Suffolk | 3*3/0AWG+1*3/0AWG | 1 | 4.25 | 6 | 4.25 | 6620 | 19 | 2.39 | 1.52 | 235 | 185 |



HENAN JINSHUI WIRE&CABLE Co., Ltd., subordinated to the Jinshui Cable Group Co., Ltd., is an international trading company professional in the research and development, manufacturing and sales of wires and cables.
Jinshui Cable Group, founded in 1983 and formerly known as Zhengzhou 2ND Cable Plant, is the largest cables and wire and electrical products R&D and production base, sales and export base, and CNC logistics distribution base in central China, as well as Top-10 of China in comprehensive cables and wire strength.
The company covers an area of 360000 square meters and the fixed assets of RMB 680 million; Having main production equipment of more than 300 sets (units), measuring and testing equipment of more than 50 sets (units), and reaching the annual production capacity of RMB 5 billion. The company has the most advanced production equipment and a high-quality production management team. Its "Jinshui" brand wire, cable and electrical products are widely used all over the world in real estate, transportation, energy, and power transmission and other fields, and well received by customers.
The company has a full range of products, including various high, medium and low voltage cable wire products from 300V to 220kV and all kinds of electrical products, where the annual production capacity of cables and wire can reach up to 800, 000 km. The company has more than 500 varieties of products in more than 5, 000 kinds of specifications, including high conductive green cable, XLPE insulated cables and wire, PVC insulated cables and wire, rubber insulated cables and wire, aluminum alloy cable, special cable, flame retardant & fireproof cable, mineral insulated cable, PVC cable material, bare wire, oxygen-free copper rod, electrician round aluminum rod and aluminum alloy rod, as well as electrician and electrical supporting products. Those products implement IEC, DIN, BS, GB, ASTM, JIS, and CSA and other standards.
The company took the lead in the same industry to pass the ISO9001 international quality system certification, ISO14001 environmental management system certification and ISO18001 occupational health and safety management system certification, and holds the People's Republic of China import and export qualification certificate and railway material supplier access certificate. The company is a recommended supplier for the national urban and rural power grid transformation, recommended supplier for government procurement, supplier for military material procurement. Those products have passed or obtained China Compulsory Certification (CCC certification), production licenses, mining products safety certification and fire-retardant products permit for flame retardant products and so likes. At present the company's products have been exported to more than 30 countries and regions including Singapore, Malaysia, Bangladesh, Pakistan, Nigeria, Sudan, Somalia, Britain, Australia, the United States and Italy.
Build a century-old enterprise of China, and strive for a world-class brand. The company will continue adhering to the service principle of "quality first, customer oriented" to carry forward the enterprise spirit of pioneering and keeping improving and innovating to provide better products and better services for users and the community!
