Air Conditioner Part Cbb65 AC Motor Run Capacitor

Name: Air Conditioner Part Cbb65 AC Motor Run Capacitor
Brand: all-electronics-online.com
SKU: 674581742
Availability: InStock
Rating: 4.7 (73 reviews)

Price:	US $ 0.64/Piece
Trade Terms:	FOB
Min Order:	300/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	CBB65
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Supercapacitor
Application:	Air Conditioner
Package Type:	Surface Mount
Capacitance:	5-100UF

Product Description

CBB65 capacitor:

1. Used widely in motors, air conditioner, water pump etc.
2. High performance & Long life.
3. Work well even in hot area.
4. We can producs according to customer's requirement.

CBB65 capacitor Technical Specifications:

Standard: IEC 60252-1: 2001
Climate type: 40/70/21 or 40/85/21
Capacitance range: 2MFD-100MFD, 15+5MFD-80+7.5MFD
Capacitance tolerance: ± 5%
I. R: ≥ 3000S(MΩ . μ F)

CBB65 capacitor Dielectric dissipation factor:

Tgδ ≤ 0.002 (50Hz~100Hz)
Application requirements:
Altitude: ≤ 2000m
Residual voltage while loading: Less than 10% of rated voltage.
Allowed maximum voltage: Less than 1.1 times of rated voltage
Permissible maximum current: Less than 1.3 times of rated current.

CBB65 capacitor Dimensional specification (mm):
1. Rated voltage(VAC): 200, 250, 370, 400, 440, 450, 480.
2. Nominal capacitance (MFD): More than 1μ F
3. Size(mm) (1). D: 40, 45, 50, 55, 60, 70, 80, 100, 25+5, 30+5, 35+5, 50+5.
(2). H: 60, 65, 70, 75, 80, 85, 90, 95, 100, 105, 110, 115, 120, 125, 135, 138.

If you need this capacitor, you can contact me.
Sophia huang

Jinan Retek Industries Inc. is a professional supplier in China, specializing in refrigeration parts. Our main products are refrigerator parts. Now we have two factories in China, manufacturing different kinds of refrigeration parts. One is mainly manufacturing condensers and evaporators. The other one is mainly manufacturing copper filter driers, accumulators and access valves.

With the idea of "Best Products, Best Price and Best Services", our company spares no efforts to achieve the target of "Being the best one, not better one". We concentrate on our products, and hope to provide our customers with best quality products at best price. We know we are young, and we are able to make great progress in future. We have great confidence in our products.

Now we sell our products mainly to refrigerator, freezer and water cooler factories in more than 15 countries and areas, including China, Pakistan, Italy, the USA and Russia. We also welcome customers all over the world to visit our company and set up business relationship for further development.
