Air Flow Transmitter, Flow Meter Gas, Vortex Flow Meter
| Price: |
Negotiable/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Size: |
Dn50-100 |
| Medium Temperature: |
(-30~+180) Degree Celsius |
| Power Supply: |
220VAC |
| Display: |
LCD, LED Indicator |
| Output: |
4-20mA |
| Velocity Range: |
(0.1~15)M/S |
| Application: |
Industrial Production |
| Type: |
Vortex Flow Meter |
| Accuracy Grade: |
0.5%Fs, 1.0%Fs, 1.5%Fs |
| Certification: |
Ce, RoHS, ISO |
Product Description
Application:This Water treatment application Air flow transmitter, flow meter gas, vortex flow meter can be widely used inl Food plant, Sugar, Vintagel Metallurgy, Paper & Pulpl Petroleum Chemical industryl Waste water and environmental protectionl Dyeing and Coal and other industries Description:WPLD series Air flow transmitter, flow meter gas, vortex flow meter (magmeters) are component of electromagnetic flow transducer and converter, used for measuring the volumetric flow rate of almost any electrically conductive liquids, as well as sludges, pastes and slurries in pipeline. The prerequisite is that the medium must have a certain minimum conductivity. The temperature, pressure, viscosity and density have little influence on the result. Our various magnetic flow transmitters offer reliable operation as well as easy installation and maintenance. WPLD series water & waste water electromagnetic flow meters have wide range of flow solution with high quality, accurate and reliable products. Our Flow Technologies can provide a solution for virtually all flow applications. The transmitter is robust, cost-effective and suitable for all-round applications and has a ± 0.5% measuring accuracy of the flow rate.Specification:
| Name | Air flow transmitter, flow meter gas, vortex flow meter |
| Medium | Liquid, Gas, Steam (Avoid Multiphase Flow and Sticky Fluids) |
| Accuracy | Liquid±1.0%of Reading(Depends on Reynolds number)
Gas(steam)±1.5%of Reading(Depends on Reynolds number)
Insert type±2.5%of Reading(Depends on Reynolds number) |
| Operation pressure | 1.6MPa,2.5MPa,4.0MPa,6.4MPa |
| Medium temperature | -40~150ºC standard
-40~250ºC Middle temperature type
-40~350ºCspecial |
| Output signal | Two-wire 4~20mA;three-wire 0~10mA
analog and pulse output available)
Communication: HART |
| Ambient Temperature | -35ºC~+60ºC,humidity:≤95%RH |
| Supply Voltage | DC12V; DC24V |
| House material | Body: Carbon steel. Stainless steel(Special: Hastelloy, )
Shedder Bar: Duplex stainless steel(Option: Stainless steel, Hastelloy)
Converter housing, case& cover: Aluminum alloy(Option: Stainless steel) |
| Explosion Protected Type | Ex iaIICT6, |
| More parameters of this Biogas Vortex Flow please contact us |
Our service:
1. We have rich experience of OEM, factory can manufacture according to your request.
2. We could also send the goods which is labelling your brand name to your customer's warehouse directly.
3. We can offer you neutral packing without our logo and company information.
4. Warranty: We offer 12 months warranty for all of our products from shipping date;
5. You will enjoy free repair service for failures found within the warranty, if there are any problems of manufacturing quality;
6. We provide paid repair services for instrumentation damages beyond the warranty period or not arising from manufacturing quality problem.
Shanghai Wangyuan Instruments of Measurement Co., Ltd. is a high-tech enterprise level company specializing in industrial process control technology and products. We offer a complete product line of pressure, temperature, flow and indicator. Our products and services comply with the professional standards of CE, ISO 9001, RoHS, Explosion proof and CPA.
Our main products are including Pressure transmitters, Pressure transducers, Pressure sensor, Level Transmitter, Differential pressure transmitter (DP transmitter), Temperature transmitter, Flow meter, Intelligent indicator, Control instrument, Paperless recorder, Pressure switch and etc.
Our products are applying in the fields like food & beverage plant, water and waste water treatment, oil & gas, electric power, scientific research, ocean, boiler, coal mine, forklift weighing system HVAC systems, CNG & LNG, air condition, fuel pressure measurement and other process control industries.
In addition, with our highly skilled and experienced team of professional engineers and technicians we can provide integrated research and development services that rank us at the top of our industry. All products are thoroughly tested in-house with our vast array of calibration and special testing equipment. Our testing process is conducted in accordance with a strict quality control system.
With our on-site experience, research and development services we are a leader in the industrial automation field, and provide global customers with high quality products and services.
