Al Cu XLPE PVC Insualtion Armoured Non-Armoured 1 Core 2core 3core 3+1core 4core 5 Core 0.6/1kv Power Cable

Name: Al Cu XLPE PVC Insualtion Armoured Non-Armoured 1 Core 2core 3core 3+1core 4core 5 Core 0.6/1kv Power Cable
Brand: all-electronics-online.com
SKU: 711076732
Availability: InStock
Rating: 4.4 (126 reviews)

Price:	US $ 2-100/Meter
Min Order:	1000/Meter
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	YJV YJLV YJV22 YJLV22 YJV32 YJLV32 BL37
Application:	Underground
Current:	AC Cable
Certification:	CE
Voltage:	0.6/1kv
Insulation Material:	XLPE PVC
Wire Core Material:	Aluminum or Copper
Model:	Yjv Yjlv Yjv22 Yjlv22 Yjv32 Yjlv32
Brand:	Yifang

Product Description

AL CU XLPE PVC Insualtion Armoured Non-armoured 1 core 2core 3core 3+1core 4core 5 core 0.6/1kv Power Cable

1.Manufactured according to the shandard of IEC,BS,DIN or ICEA upon requst.

2.Suitable for use in power transmission and distribution lines with rated power frequency voltage 0.6/1kV.

3.The ambient temperature for installation: ≥0°C

4.Maximun conductor temperature in normal operation:≤90°C

5.Max operating temperature of conductor when cable short-circuited(5s maximun duration): 250°C

6.Permissible bending radius:

Single cable: [20(D+d)±5%]mm

Multi cable: [15(D+d)±5%]mm

7. Suitable for under ground,can bear mechanical stress.

8. Products Parameter (structure, weight and current rating)

Type	Dia. of conductor	XLPE insulation thickness	Inner sheath thickness	Steel tape thickness	PVC jacket thickness	Approx. dia. of cable	Approx. weight of cable	Current rating of cable
mm²	mm	mm	mm	mm	mm	mm	kg/km	in the air	under ground
4*4	2.25	0.7	1.2	0.2	1.8	16	402	28	35
4*6	2.76	0.7	1.2	0.2	1.8	17	488	37	46
4*10	4.05	0.7	1.2	0.2	1.8	21	688	47	56
4*16	5.10	0.7	1.2	0.2	1.8	23	927	64	76
4*25	6.00	0.9	1.2	0.2	1.8	27	1367	84	98
4*35	7.00	0.9	1.2	0.2	1.8	30	1558	115	126
4*50	6.81	1.0	1.2	0.5	1.9	33	2163	141	152
4*70	8.23	1.1	1.2	0.5	2.1	36	2485	172	181
4*95	9.71	1.1	1.2	0.5	2.2	41	2813	218	222
4*120	10.95	1.2	1.3	0.5	2.4	44	2945	269	267
4*150	12.16	1.4	1.4	0.5	2.5	49	3533	313	305
4*185	13.61	1.6	1.5	0.5	2.7	54	4236	359	344
4*240	15.65	1.7	1.6	0.5	3.0	60	5625	405	383
4*300	17.53	1.8	1.7	0.5	3.1	66	6286	451	422

Certificates:

Zhengzhou Yifang Cable Co., Ltd is a large joint-stock\hi-tech enterprise established in 1988. We are specialized in wires & cables, including designment, production and sales.

There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.

Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire), flame retardant mining cable, etc

We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
