Product Description

5 Years Warranty All in One Solar LED Street Light

SunMaster can provide Engineering Work for your specific projects. According to your brightness requirements and our own calculations, we can help you in designing the location and orientation of the solar light poles, in order to achieve the best performances. Our services include:

• Optimized positioning of the street light poles
• Simulation made according to the lighting standards
• Technical and design documents for sales pitches
• A preview on the final project

1. Look at Specification of SunMaster solar street light SMLN-100W

Features:
- Above system configurations are designed to allow the lamp to work for 10hrs per night, battery capacity with continuous 3 days backup. The configuration is based on scientific calculation and engineering project experience. For clients' specific project, please tell us the exact installation location and working hours, so that we can provide customized solution and quotation accordingly.
-The batteries are suggested to be placed in a underground buried PVC battery box. In this way, it can avoid overhigh temperature due to sunshine exposure or too cold weather in Winter. It's wateproofand, heat-dissipative and theftproof, easy for replacement in late period.
-The pole patterns are standardized practical model recommended by us. It can be customized with more patterns available according to clients specific requirement.

2 Details of SunMaster solar street light SMLN-80W components



FAQ

Questions for products

1.Q:How many cycles full charge&discharge about your battery?
A: In 50% discharging deepness, it can be cycled for 1,200 times; in floating charging and discharging status, it can be cycled for 5000~6000 times.

2.Q:How to Choose the System Voltage 12V or 24V or for normal solar street Light ?
A: We can design the System for 12v or 24v for solar street Light or 220-380V for normal street light .

3.Q:What's the main difference between mono and polycrystalline solar panel?
A: production process and cost. Polysilicon technology is more mature since it is an early technology compared with Monosilicon.

4.Q:The controller of your solar street light has dual time control function?
A: our solar charge controller is designed with dual time control function, you can set up the lighting time and divide it into two parts, like 12 hours (6 hours full power lighting + 6 hours half power lighting)

5.Q:What information does SunMaster need to offer you the best customized solar lamps?
A: I·· Which City will you install the solar street lights?
I··Road width & road length?
I··What type of road? Highway, National, Suburb or Parking lot?.
l ··How many hours of light per day required?
l ··How many continued days lighting without sunshine?
l ··If retrofit lighting ,what's the existing light type and power?
l ··Do you have the site photo?
l·· Any other special requirement?

6. Q:What is an LED driver?
A: An LED driver is a selfcontained power supply that has outputs matched to the electrical characteristics of your LED or array of LEDs. There are currently no industry standards,
so understanding the electrical characteristics of your LED or array is critical in selecting or designing a driver circuit. Drivers should be current regulated (deliver a consistent current over a range of load voltages). Drivers may also offer dimming by means of pulse width modulation (PWM) circuits. Drivers may
have more than one channel for separate control of different LEDs or arrays.

7. Q:What is a sun hour?
A: Sun hour is a unit of measurement of the intensity of sunlight on the earth at a given time that can be used for generation of solar power, recognizing factors
such as climate and weather. A full sun hour is measured as the intensity of sunlight at noon, whereas less than a full sun hour will result during the hours before and after noon.
8. Q: How does the light know when to turn on and turn off?

A: SunMaster's solar controller uses a photocell and/or timer to control when the light will turn on, when the sun goes down, and to turn off when the sun comes up.
The photocell detects when the sun comes down and when the sun comes up again. SunMaster can make the lamp last anywhere from 8-14 hours, and this varies on the customer's needs.The solar controller utilizes an internal timer that is
pre-set for a specific number of hours to determine when to switch the light off. If the solar controller is set to leave the light on until dawn, it determines when the sun rise (and when to switch the light off) by means of voltage readings from the solar panel array.

9.Q: What happens if there are cloudy days?
A: Electrical energy is stored in the battery each day, and some of that energy is used to operate the light at night. Generally, we design your system so that the battery
will operate the light for five nights without charging. This means that, even after a series of cloudy days, there will be plenty energy in the battery to power the light each night. Also,
the solar panel will continue to charge the battery (although at a reduced rate) even when it is cloudy.What is the typical maintenance schedule for a solar lighting system?There is no regular maintenance required for a solar lighting system. However, it is helpful to keep the solar panels clean, especially in a dusty climate.Do I have to charge the batteries?Batteries are shipped 85% charged. The batteries will be at 100% charged within two weeks of proper operation.

Questions for trade

1.Are you manufacturer or trading company?
We are factory on No.2735 Dongyang Street Jinhua Zhejiang China. 2 hours from Shanghai, 6hours from Guangzhou Shenzhen.Welcome to visit us

2. Can you arrange all shipping for me?
Yes,we can arrange all the process of shipping.If you have other goods need to source from China,we can mix container for you

3. What's the shipping way

FedEx/DHL/UPS/TNT for samples, Door-to-Door;

By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

Customers specifying freight forwarders or negotiable shipping methods!

4. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.

5.Payment Terms

T/T, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.

5. MOQ: 1pcs
6.Can you provice sample?
Yes,we can provide free sample
