| Prod Model: |
LYD-48V-10A |
| Material: |
Aluminum |
| Working Temperature: |
-10-70 |
| Storage Temperature: |
-20-85 |
| Output Type: |
Single |
| Output Power: |
401 - 500W |
| Input Voltage: |
110-220V |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Separate-excited Switching Power Supply |
| Voltage Regulating Mode: |
Width Modulation Type |
| Power Supplying System: |
Level 1 Power Distribution Equipment |
| Certification: |
RoHS |
Product Description
Basic Info| place of origin: | Shenzhen,China | brand name: | louita | model no.: | LYD-48V-10A |
| output type: | single | output frequency: | 50/60HZ | material: | Aluminium |
| size: | 240X125X67mm | output current: | 10A | | |
Product DescriptionFeatures:
Universal AC input/ full range
Built-in active PFC function
Protections: Short circuit/ Over load/ Over voltage/ Over temperature
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
LED indicator for power on
100% full load burn-in test
Fixed switching frequency at 100KHz
2 years warranty
SPECIFICATIONS |
OUTPUT | |
Model | LYD-48V-10A | LYD-48V-10A |
DC Voltage | 24V | 48V |
Rated Current | 20A | 10A |
Current Range | 0-20A | 0-10A |
Rated Power | 480W | 480W |
Ripple & Noise | 120mVp-p | 120mVp-p |
Voltage Adj. Range | 24-28V | 48-53V |
Voltage Tolerance | ±1% | ±1% |
Setup, Rise Time | 800ms,40ms/230VAC 800ms,40ms/115VAC at full load |
Hold Up Time | 24ms/230VAC 24ms/115VAC at full load |
| |
INPUT | |
Voltage Range | 180~264VAC 47~63Hz; 250~370VDC |
AC Current | 2.8A/115V 1.4A/230V |
Efficiency | 89% | 89% |
Inrush Current | Cold start 27A/115V 45A/230V |
Leakage Current | <3.5mA/240VAC |
| |
PROTECTION | |
Over Load | 105%~150% |
Protection type: Constant current limiting, recovers automatically after fault condition is removed |
Over Voltage | 30-36V | 54-60V |
Protection type: Shut down o/p voltage, re-power on to recover |
Over Temp. | 100°C±5°C(TSW1) |
Protection type: Shut down o/p voltage, recovers automatically after temperature goes down |
| |
ENVIRONMENT | |
Working Temp., Humidity | -10°C~+70°C; 20%~90%RH |
Storage Temp., Humidity | -20°C~+85°C; 10%~95%RH |
Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes |
| |
SAFETY | |
Withstand Voltage | I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC |
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC |
| |
STANDARD | |
Safety Standard | Design refer to UL508,UL60950-1, TUV EN60950-1 |
EMC Standard | EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,ENV50204,EN55024,EN61000-6-2(EN50082-2) |
| |
OTHERS | |
Dimension | 240X125X67mm |
Weight | 2.5Kg |
Packing | 12pcs/carton |
| |
NOTE | |
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor. 3. Tolerance: includes set up tolerance, line regulation and load regulation. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. 5. Derating may be needed under low input voltages. Please check the derating curve for more details. |
With advantage of many years producing LED in large scale as well as advanced technicians in lamp manufacturing field. LYD entered into the lamp market which uses LED as its lamp-house, as a high-tech enterprise which specialize in producing out door&indoor decorative lighting products.
Our company's main products are: Book Lights, Flexible LED Strips, Rigid LED Strips, LED Module, LED Controller, Power Supply. Our products have been widely used in illumination, advertisement, city enlightening projects, traffic lamp, decorating, electronic gifts and toys, and many other production fields.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
Through persevering efforts, we have become one of the largest suppliers in LED light field in China and also won the trust of our customers because of excellent quality and prompt delivery.
Choosing louita means choosing satisfaction and choosing benefit! We firmly believe "Technology changes the world and the world will be more brilliant because of louita
