Amplifier Transistor Bc557b of Electronic Component for PCB Assembly

Name: Amplifier Transistor Bc557b of Electronic Component for PCB Assembly
Brand: all-electronics-online.com
SKU: 796770725
Availability: InStock
Rating: 4.6 (97 reviews)

Price:	US $ 0.029/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BC557B

Product Description

Lead time	2 to 3 days after receiving the payment.
Remark	100% New and original ; 30 days warranty
Payment	Heng Seng Bank (Hong Kong), Paypal,
Shipment	DHL ,TNT ,FEDEX, UPS or any other express

Features
• Pb−Free Packages are Available

Specifications
Emitter-Base Voltage:5(V)
Frequency:150(MHz)
Transistor Polarity:PNP
Power Dissipation:0.5(W)
Mounting:Through Hole
Collector Current (DC) :0.1(A)
Collector-Base Voltage:50(V)
Collector-Emitter Voltage:45(V)
DC Current Gain:200
Operating Temp Range:-55C to 150C
Packaging:Tape and Reel
Pin Count:3
Operating Temperature Classification:Military
Category :Bipolar Small Signal
Package Type:TO-92
Number of Elements:1
Rad Hardened:No

EU RoHS Compliant
Type PNP
Number of Elements per Chip 1
Maximum Collector Base Voltage (V) 50
Maximum Emitter Base Voltage (V) 5
Maximum Collector Emitter Voltage (V) 45
Maximum DC Collector Current (A) 0.1
Maximum Power Dissipation (mW) 625
Minimum DC Current Gain 180@2mA@5V
Maximum Transition Frequency (MHz) 320(Typ)
Product Category Bipolar Small Signal
Minimum Operating Temperature (°C) -55
Maximum Operating Temperature (°C) 150
Packaging Fan-Fold
Mounting Through Hole
Package Height (mm) 5.33(Max)
Package Length (mm) 5.2(Max)
Package Width (mm) 4.19(Max)
PCB changed 3
Standard Package Name TO-92
Supplier Package TO-92
Pin Count 3
Lead Shape Formed
