| Prod Model: |
LLT-LKSS-VER7.4.3L |
| Hvga: |
800X480 |
| Navigation: |
800(GHz), 256(Storage), 800*400(HD Dispaly). |
| Map: |
Careland/Daodaotong/Igo/Papago |
| Size: |
155*90*20 (mm)X2 |
| Language: |
Multi-Language |
| APP Download: |
Support |
Product Description
Android 6.0 Navigation Interface for 2010-2017 Lexus support OEM Mouse Control
Overview
Android auto interface allows to connect external video sources, such as android navigation box , front rearview camera , camera , 360 round view cameras , DVR , mobile phone mirrorlink , DVB-2 module , DVD module etc . Through auto interface,all video source which you installed can be played on car's screen . Work for : 2010-2017 Lexus RX/IS/ES/IS/NX/LX/LS
Special Features :
1. Support apps download (YouTube, Waze, Real-time & offline navigation etc).
2. Multi-touch by two fingers
3. Support resistive touch and capacitive touch at the same time
4. With Android/IOS mirrorlink function
5. Full plug and play
6. Online-map
7. Offline -map
8. Play 4K HD video
9. Online YouTube
10.Support factory rear camera
11. Rear view camera , front view camera , Left-side camera , right-side camera optional
12. DVR / ADAS optional
13. wifi network
Product description:
1. Support external video source input ( DVD TV ),full touch screen ;
2. Long-press the hold button switch to android system
3. Operate apps by factory Knob or mouse
4. Turn to next song/last song by steering wheel
5. Adjust volume by steering wheel
6. Voice search by factory microphone
7. Sounds come from factory speaker( Knob versionPlay lossless music
8. Control left/right side cameras by Steering wheel or turn light
9. Press AUX button to switch to Android system
Specifications:Specifications for Hardware :Master processor: RK3188T Quad-Core Processor (RK 3188T/RK 3188/PX3)
Basic frequency : 1.6G.
Memory capacity: 2G DDRIII .
Flash memory: 16G.
OS: Android 6.0
GPS receive: support AGPS function
GPS antenna: 3V active antenna
GPS antenna protection: prevent the antenna short circuit
WiFi module: RTL8188 / RTL8723.
BT module: RTL8723BU,support BT4.0, firmware support Bluetooth functions.
A2DP,Bluetooth telephone.
Support USB 3G dongle,WiFi can be as a hot spot output.
Synchronizing signal: composite synchronizing signal. Separate sync signal.
Video output format: simulate RGB and CVBS composite synchronizing signal output , one of them optional.
Analog video output: Support the display position adjustment,and brightness contrast adjustment.
The resolution of the video output: 800×480,1024X600,Maximum 1920X1080, Support any resolution.
Audio output: Left and right channel stereo output with audio valid indication signal.
Sound Control output: IO output or UART output.
Single track MIC input: support voice navigation, support SPDIF output.
Touchscreen interface: Support 4-wire resistive touch (support two point touch function), support serial touch, two ways to touch without modifying the hardware. Change software will be ok.
Memory card types: support maximum 64 gb TF/SD card, support read U disk, mobile hard disk storage.
USB port : USB OTG 2.0 .
Voltage range: 7 ~ 16v (optional 9 ~ 28V), with undervoltage shutdown (7V protection shutdown).
ACC control: ACC support delay shutdown, and SLEEP combination can be set off at any time.
Supported map software: APK install automatically or installation package .
| | |
Quality warranty policy: 3 month free replacement and 1 year free maintenance due to product problem . Send goods in 1 or 2 days after full payment received. Customer service department will contact with you by whatsapp, email, skype for after-sale service . |
Product list:1* Android navigation interface two-in-one unit
1* speaker
1* Microphone
1* GPS Antenna
1* map card
Touch screen as optional
All necessary cables
