ANSI 54 Series Stay Porcelain Insulators

Name: ANSI 54 Series Stay Porcelain Insulators
Brand: all-electronics-online.com
SKU: 826008815
Availability: InStock
Rating: 4.7 (64 reviews)

Price:	Negotiable/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	54-1
Porcelain Insulators:	Spool Insulators
Application:	High-voltage
Material:	Porcelain
Structure:	Shackle Insulator
Type:	B Type Insulator
Color:	Brown
Brand:	Haivol

Product Description

Specifications
ANSI 54 series Strain Porcelain Insulators
1)creepage distance:41/47/57/76mm
2)Certificates:ISO9001:2008
3)good quality

ANSI 54 series Strain Porcelain Insulators
•Material: Porcelain
•standard:ANSI
•class standard:54-1/54-2/54-3/54-4

•specification:

Cat NO			A1049	A1050	A1051	A1052
Fig			1	1	1	2
Class NSI			54-1	54-2	54-3	54-4
Main Dimensions (mm)	H		88	108	140	171
	h		44	57	79	69
	h 1		64	76	103	114
	D		64	73	86	89
	d		44	54	60	60
	d 1		16	22	25	25
Mechanical failing load (kn)			44	53	89	89
Creepage Distance(mm			41	47	57	76
Flashover Voltage	Power-frequency	Dry	25	30	35	40
Flashover Voltage	Power-frequency	Wet	12	15	18	23
Weight(kg			0.43	0.63	1.2	2

Haivo Electrical Co., Ltd, is a provider of power equipment and services for the global electric utility industry. It mainly manufacture power transmission & distribution equipments, covering many product series as Fuse cutout, Surge arrester, Composite & Porcelain insulator, Disconnector switch & Load Break Switch, Hardware fitting for overhead line, Cable accessories and Cable kits (cold & heat shrinkable cable accessories).

HAIVO ELECTRICAL, As one of the international electrical companies in China, We not only manufacture the power equipment, but also provide sustainable power solutions underpinned by technology innovation. To date, HAIVO conducts business in nearly 50 countries and territories in South America, Europe, Latin America, Asia, Africa, and the Middle East. HAIVO′ S high standards have received due recognition from the local power customers.

HAIVO′ S worldwide operation and sales coverage is backed by exceptional experience and expertise to provide customers with the most reliable and highest quality products and services available.

For the quality control system, HAIVO was successively awarded ISO 9001: 2008 by DAS CERTIFICATION Ltd & UKAS QUALITY MANAGEMENT, and TYPE TEST REPORT by China NATIONAL HIGH VOLTAGE APPARATUS QUALITY SUPERVISION TESTING CENTER(XIHARI) & QUALITY INSPECITION AND TEST CENTER FOR EQUIPMENT OF ELECTRIC POWER.

We promise we will offer first-class quality, reasonable price, first-class service and following the business philosophy of development and innovation to serve global power customers!
