Anti-Fog Toughened Glass Insulator

Name: Anti-Fog Toughened Glass Insulator
Brand: all-electronics-online.com
SKU: 694641042
Availability: InStock
Rating: 4.4 (92 reviews)

Price:	US $ 5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	U70BP U120BP U160BP U210BP
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Standards:IEC:	Anti-Fog Glass Insulator
Application:	Low-voltage
Structure:	Suspension Insulator
Type:	A Type Insulator
Material:	Toughened Glass
Color:	Light Green
Brand:	Cie or OEM

Product Description

1. Name :Anti-Fog Toughened Glass Insulator

2. Standard of the Glass Insulator: IEC & ANSI &BS standard approved

3. Mechanical strength: From 70KN, 120KN, 160KN, to 550K

4. Package of the Glass Insulator: 5Pcs in one ply-wood case or by customer's requirements.

We have exported the Glass Insulators to Vietnam, Turkey, Lithuana, Poland , India, Iraq about 10years with very competitve price and good quality.
The type test report from the international Lab can offer you if you have any inquiry about the Glass insulators.

IEC Standard insulators	U70BLP	U120BP	U160BP	U160BLP	U210BLP	U240BLP	U300BP
Designation	LXWP5-70	LXWP4-120	LXWP7-160	LXWP5-160	LXWP3-210	LXWP3-240	LXWP-300
( mm ) Diameter D	280	280	550	550	550	550	550
( mm ) Spacing H	146	146	146	170	170	170	195
( mm ) Creepage L	450	450	320	320	320	320	340
( mm ) Ball and Socket soupling	16	16	20	20	20	24	24
( kN ) Mechanical failing load	70	120	160	160	210	240	300
( kN ) Mechanical routine test	35	60	80	80	105	120	150
( kV ) Wet power frequency withstand voltage	50	50	55	55	55	55	55
( kV ) Dry lightning impulse withstand voltage	125	125	140	140	140	140	140
( P.U ) Impulse puncture voltage	2.8	2.8	2.8	2.8	2.8	2.8	2.8
( kV ) Power frequency puncture voltage	130	130	130	130	130	130	130
( µV ) Rodio influence voltage	50	50	50	50	50	50	50
( kV ) Corona visual test	18/22	18/22	18/22	18/22	18/22	18/22	18/22
Power frequency electric arc voltage	0.12s/20kA	0.12s/20kA	0.12s/20kA	0.12s/20kA	0.12s/20kA	0.12s/20kA	0.12s/20kA
( kg ) Net weight per unit	5.5	5.5	8.8	9.2	9.2	9.6	12.5

Experience: 16 years producing experience from 1999-2015 for insulator and line hardware

Product: Composite insulator, glass insulator and ceramic insulator

SML: From 40KN to 550KN From AC insulator to DC insulator.

Package: Exported free-fumigation

Quality control: Can do all the test according to IEC

Quality control System: Exactly according to ISO9001: 2000

Exporting Market: USA, Argentina, Mexico, Italy, South Africa, Turkey, Vietnam, France, Chile, etc.

Engineer term: Have 12 engineers to reply all your questions and offer professional service.

Sale term: All the sale man have been trained every month. And offer best service.
