ASTM B416-88 Aluminium Clad Steel Alumoweld Messenger Wire Cable
| Price: |
US $ 1-5/Meter |
| Min Order: |
1/Meter |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
Bare Conductor |
| Product: |
Acs |
| Standard: |
ASTM, CSA, BS, DIN, IEC, NFC |
| Advantages: |
High Quality, Competitive Price, Fast Delivery |
| OEM: |
Yes |
| Related Voltage: |
0.6/1kv; 8.7/15kv; 12/20kv; 21/35kv; 26/35kv |
| Type Of Company: |
Professional Manufacturer |
| Sample: |
Free |
| Exoprt Experience: |
South America, Africa, Middle East Ect |
| Delivery Time: |
15-25days |
| Construction: |
Aluminium Clad Steel Wire for Electrical Purpose |
| Application: |
Power Station |
| Current: |
DC & AC |
| Insulation Material: |
Bare |
| Model: |
Stranded |
| Sheath Material: |
Bare |
| Certification: |
ISO9001, CCC, BV, SGS |
| Brand: |
Rmjt |
| Voltage: |
Low, Medium, High Voltage |
| Wire Core Material: |
Aluminum Clad Steel |
Product Description
Application:Aluminium clad steel wire/strand is used for various voltage level power transmission lines , overhead transmission lines and overhead ground wires. It can also be applied in various special areas with long span length, coastal areas and island as well as other hot and humid regions, salt fog regions and heavily polluted regions where the high corrosion resistance strand is needed. Aluminium clad steel wire/strand can also be used as messanger wire for electrified railways.
Aluminum clad steel wire is widely used in coastal areas, volcano areas, salt atmosphere areas and overhead power line used in areas seriously polluted by industrial materials containing SO2, NO and CO2, etc. It's the optimum material for transmission conductor with kilometric span and carrier cable for electrified railways.
Construction
Aluminum clad steel wire is a piece of round wire made of a round steel core clad with a uniform and continuous aluminum layer. By structure ratio of steel and aluminum, aluminum clad steel wire has different grades, LB14, LB20, LB23, LB27, LB30, LB35 and LB40, with corresponding electric conductivities of 14%, 20.3%, 23%, 27%, 30%, 35% and 40% IACS (IACS stands for International Annealed Copper Standard). Featured by high strength, corrosion resistance and high conductivity, etc.
Aluninium clad steel strand is composed of stranded aluminium clad steel wires.
Standards
(1)ASTM B416 Standard Specification for Hard-Drawn Aluminum-Clad Steel Wire
(2)IEC61232 Aluminium-clad steel wires for electrical purposes
(3)AS 1222.2 Part 2: Aluminium Clad (SC/AC)
Features:
Superior corrosion resistance compared with traditional galvanized conductor cores
Ideal for coastal environments or industrial zones with corrosion concerns
Higher strength to weight ratio than galvanized cores
Outer aluminum cladding is fully compatible with alloy wires used in conductors
Properties
1.sound conductivity
2. mechanical strenghth
3. long service life
4.corrosion resistance
5.maintenance freeSpecificationConductivity14%,20.3%,23%,27%,30%,35%,40% IACSAluminum Clad Steel Strand ASTM B416Code No. | Area | No.of wires | Diameter | wight | Rated Strength | Max DC.Resistance at 20 degree |
| Mm2 | | Wire mm | Cond. mm | Kg/Km | KN | Ohm/Km |
3No5AWG | 50.32 | 3 | 4.62 | 9.96 | 334.1 | 54.42 | 1.699 |
3No6AWG | 39.00 | 3 | 4.11 | 8.87 | 265 | 45.74 | 2.142 |
3No7AWG | 31.65 | 3 | 3.67 | 7.9 | 210.1 | 38.36 | 2.701 |
3No8AWG | 25.10 | 3 | 3.26 | 7.03 | 166.7 | 32.06 | 3.406 |
3No9AWG | 19.9 | 3 | 2.91 | 6.26 | 132.2 | 25.43 | 4.294 |
3No10AWG | 15.78 | 3 | 2.59 | 5.58 | 104.8 | 20.16 | 5.415 |
7No5AWG | 117.4 | 7 | 4.62 | 13.9 | 781.1 | 120.27 | 0.7426 |
7No6AWG | 93.1 | 7 | 4.11 | 12.4 | 619.5 | 101.14 | 0.9198 |
7No7AWG | 73.87 | 7 | 3.67 | 11.0 | 494.1 | 84.81 | 1.16 |
7No8AWG | 58.56 | 7 | 3.26 | 9.78 | 389.6 | 70.88 | 1.4630 |
7No9AWG | 46.44 | 7 | 2.91 | 8.71 | 308.9 | 56.2 | 1.844 |
7No10AWG | 36.83 | 7 | 2.59 | 7.76 | 245.1 | 44.58 | 2.325 |
7No11AWG | 29.21 | 7 | 2.3 | 6.91 | 194.4 | 35.35 | 2.932 |
7No12AWG | 23.16 | 7 | 2.05 | 6.16 | 154.2 | 28.03 | 3.697 |
19No5AWG | 318.7 | 19 | 4.62 | 23.1 | 2129 | 326.39 | 0.2698 |
19No6AWG | 252.7 | 19 | 4.11 | 20.6 | 1688 | 274.55 | 0.3402 |
19No7AWG | 200.4 | 19 | 3.67 | 18.3 | 1339 | 230.18 | 0.429 |
19No8AWG | 158.9 | 19 | 3.26 | 16.3 | 1062 | 192.41 | 0.5409 |
19No9AWG | 126.1 | 19 | 2.91 | 14.5 | 842 | 152.58 | 0.6821 |
19No10AWG | 99.96 | 19 | 2.59 | 12.9 | 667.7 | 121 | 0.8601 |
37No5AWG | 620.6 | 37 | 4.62 | 32.3 | 4170 | 635.43 | 0.1394 |
37No6AWG | 492.2 | 37 | 4.11 | 28.8 | 3307 | 534.85 | 0.1757 |
37No7AWG | 390.3 | 37 | 3.67 | 25.7 | 2623 | 448.09 | 0.2216 |
37No8AWG | 309.5 | 37 | 3.26 | 22.9 | 2080 | 374.67 | 0.2794 |
37No9AWG | 245.5 | 37 | 2.91 | 20.3 | 1649 | 279.11 | 0.3523 |
37No10AWG | 194.7 | 37 | 2.59 | 17.9 | 1308 | 235.61 | 0.4443 |
