ATV UTV off-Road LED Light Bar Rocker Switch

Prod Model:	ATV UTV off-Road LED Light Bar Rocker Switch
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Warranty:	One Year
Usage:	Vehicle
Standard:	Standard
Lamp:	Without Lamp
Color:	Black
Certification:	CE
Condition:	New

Product Description

Quick Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: MY
Model Number: MY-14112201
Max. Current: DC 20A / AC 16A
Max. Voltage: DC 24V / AC 250V
Mechanical Life: 500,000 times
Products name: Waterproof Rocker Switches
Switch Color: Black (other)
LED Light Color:Amber\Orange\Red\Blue\Green
Panel Material: ABS+PBT+PC+POM
Switch Type: SPDT\DPDT\DPTT
Operating Temperature: -25° ~ +80°
Waterproof: Ingress Protection 68
Cover Dimensions: 48.43X26.48mm
Switch Dimensions: 29.90 x21.00mm
Fit For: Marine /Off-Road /4x4 ATV /Motorcy
Packaging & Delivery

Packaging Details:	25pcs/plate*20 plate = 500pcs/Carton,  Carton size: 34.5cm * 36 cm* 55 cm ,  Total weight : 18 kg (Gross weight / Carton Box).
Delivery Detail:	Seller ships within 7-10 days after receiving cleared payment

Specifications

Rating 12V/20A 24V/10A DC
CE RoHs approved
Waterproof IP68
Anti-corrosion ABS plastic panel
High quality, And Free sample




ATV UTV Off-Road LED Light Bar Rocker Switch

DC 12V at 20A , 24V at 10A Rating
AC 125V at 16A , 250V at 10A  Rating
Operating Temperature :  -25° ~ +80°
Electrical Life : 50,000 make and break cycles at full load
Sealed rocker switch IP68
Anti-corrosion ABS plastic panel
For Marine Off-Road 4x4 ATV Motorcy

1. Description:

Avaliable power: 20A/12V 10A/24V DC And 16A/125V 10A/250V
Switch electrical functions : ON-OFF (ON)-OFF ON-ON (ON)-ON ON-OFF-ON (ON)-OFF-ON (ON)-OFF-(ON) ON-ON-ON ON-ON-OFF , (NO): MOM ON.
Automatic reset OFF. Carling Style ,Installation dimensions is : 21.2*37.2mm (the same as Carling style).
Sealed rocker switch IP68,Anti-corrosion ABS plastic panel,Sealed rocker switch suited for Marine,Off-Road,4x4 ATV and Motorcycle Beware of inferior products on the market that claim to be just as good .but we support the sample for the test .

2. Production Specification

(1).100% test before shipment
(2).more than 50,000cycles life
(3).High current rating to 20 amps
(4).New style with rounded corners
(5).Lighted and non-lighted
(6).Maintain-action and momentary

3. Advantages

  All symbols are printed directly onto the switch face using modern high tech inks and printers to ensure long image life. we do not use stickers which will wear off in a very short time.
The switch is rated at 20amp's however in ALL case we recommend that you wire the accessory through a fused relay.

4.  Warranty & Returns

  30 days money back guarantee. If you are unhappy with your Warehouse Direct Performance purchase we will offer a 100% money back guarantee. If you have changed your mind or are unhappy with your purchase you can return items back to our warehouse.
