Audio Frequency Transform Ei41

Prod Model:	audio frequency transform
Application:	Audio
Phase:	Single
Coil:	Core-type Transformer
Cooling Method:	Dry-type Transformer
Winding Type:	Multi-winding Transformer

Product Description

Specifications



Low frequency transformer:
1. Output power: 0.2W-2.5KW.
2. Rated current: 2A-1500A loads.
3. ISO9001, RoHS, UL, CQC
Switching power transformer Applications:
1. VCRS, Copy machine, Audio equipment, Game machines;
2. TV sets, Microcomputer equitpmen
3. Communications control equipment
4. Printers, Terminals.
5. Wigh good magnetic shield form itself and slight interferece.
Switching power transformer Electrical Characteristics:
1. Operating Temperature range: -20 to +45
2. TV sets, Microcomputer equipment
3. Switching frequency: 1kHz to 200kHz
4. Withstanding voltage: 1500/3750VAC for 1 minute between primary&secondary
5. Insulation resistance: 500VDC 100M min. Between primar&secondary
Transformer is to transform ac voltage, current and impedance of the device, when the primary zhongtong have alternating current coil, iron core (or core) to produce ac magnetic flux, induced in the secondary coil voltage (or current). Transformer is composed of iron core (or core) and the coil, coil, there are two or more than two windings, which connect power winding is called primary coil and the rest of the winding is called secondary coil. In the generator, whether it's movement through the magnetic field or magnetic field coil through fixed coil, all can induction electric potential in the coil, the two cases, the value of the magnetic flux are unchanged, but the fellowship with coil chain there is a change in the number of magnetic flux, this is the principle of mutual induction. The transformer is one kind of use of electromagnetic should be mutual inductance, transform voltage, current and impedance of the device.

Model	Power	Dimension(cm)					Weight (KG)	Voltage   regulation	Approval mark
		A(cm) ±1.5	B(cm) ±2	C(cm) ±2	D(cm) ±2	E(cm) ±2
TDW-EI28	1.5W	43		30	38	28	0.11	35	CE,
TDW-EI35	3.0W	47		37	38	33	0.15	22	CE,
TDW-EI41	11.0W	54		43	47	35	0.32	16.5	CE,;
TDW-EI48	25.0W	62		50	65	43	0.57	13.1	CE,
TDW-EI57	40.0W	73		59	65	51	0.84	11.8	CE,
TDW-EI66	80.0W	83		68	80	58	1.38	9.3	CE,
TDW-EI76	140W	64	70	76	85	68	2.25	7.6	CE,
TDW-EI86	180W	72	75	86	92	73	2.82	7.1	CE,
TDW-EI96	250W	80	81	96	90	82	3.36		CE,;
