Bf350-3AA Resistance Strain Gages

Name: Bf350-3AA Resistance Strain Gages
Brand: all-electronics-online.com
SKU: 827588335
Availability: InStock
Rating: 4.7 (98 reviews)

Price:	US $ 0.3/Piece
Min Order:	100/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BF350-3AA
Material:	Aluminium Alloy

Product Description

Strain gages:

PATTERN	MODEL	GRID DIM (mm)		BACKING DIM (mm)		CREEP CODE
PATTERN	MODEL	a	b	c	d	CREEP CODE
single axis,grid AA	BF(BH)120-1AA	1.0	3.0	3.8	3.8	T0
	BF(BH)350-1.5AA	1.5	3.5	4.0	4.5
	BF(BH)500-1.5AA	1.5	3.5	4.0	4.5

	BF(BH)350-2AA	2.1	3.0	5.5	4.0	T1 T8 T4 T2 T0
	BF(BH)500-2AA	2.1	3.2	5.5	4.2
	BF(BH)1000-2AA	2.1	3.5	5.5	5.0
	TF(TH)1000-2AA	2.1	3.5	5.5	5.0
	BF(BH)350-3AA	3.1	3.0	7.4	4.5	T3 T1 T8 T6 T4 T2 T0 N2 N4 N6 N8 N0 N1 N3 N5 N7
	BF(BH)500-3AA	3.1	3.0	7.4	4.5
	BF(BH)1000-3AA	3.1	3.0	7.4	4.5
	TF(TH)1000-3AA	3.1	3.0	7.4	4.5
	BF(BH)350-4AA	2.6	4.0	9.0	4.5	T0 N0 N3 N5
	BF(BH)1000-4AA	2.6	4.0	9.0	4.5
	TF(TH)1000-4AA	2.6	4.0	9.0	4.5
	BF(BH)350-6AA	2.6	6.0	11.0	5.0	T0
	TF(TH)1000-6AA	2.6	6.0	11.0	5.0	T0
45°single grid AB	BF(BH)350-3AB	3.0	3.0	8.1	5.5	T4 T0 N6 N0 N3
	BF(BH)350-4AB	4.0	4.0	9.3	6.2
	BF(BH)1000-3AB	3.0	3.0	8.1	5.5
	TF(TH)1000-3AB	3.0	3.0	8.1	5.5
	TF(TH)1000-4AB	4.0	4.0	9.3	6.2
	BF(BH)350-6AB	6.0	6.0	10.4	7.5
45°double grids HA	BF(BH)350-2HA	2.0	4.8	9.0	5.6	T4 T0 N2 N6 N0 N3

Guangdong South China Sea Electronic Measuring Technology Co., Ltd. (SCS)is located at Dongguan City, Guangdong Province, Where is the manufacture centre of China. Established in 1992, it specializes in developing and manufacturing advanced load cells, force sensor, Torque sensor, axle weigher, wheel weigher, pressure transducer based on strain-gages. We also manufacture custom designed load cells and weighing system whatever our customers can dream up. Some of our products have "OIML" and European approved "CE" mark. Hope we will establish a long term business-ship with you.
