Bhp 1p Mini Circuit Breaker

Name: Bhp 1p Mini Circuit Breaker
Brand: all-electronics-online.com
SKU: 722493345
Availability: InStock
Rating: 4.9 (38 reviews)

Price:	US $ 1.3-1.6/Piece
Trade Terms:	FOB
Min Order:	200/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BHP 1P
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Weight:	0.2kg
Model Number:	Feql
Rated Current:	6, 10, 16, 20, 25, 32, 40
Poles:	1, 2, 3, 4
Certificate:	CE ISO9001
Place Of Origin:	Zhejiang, China (Mainl)
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Insert
Structure:	MCB
Poles Number:	3

Product Description

Specifications
1.high breaking capacity
2.rated current: 6, 10, 16, 20, 25, 32, 40, 50, 63
3.poles: 1, 2, 3, 4
4.certificate: CE ISO9001
THQL MCB

BH-P miniature circuit breaker applies to industrial, commerical, lighting and electric machine distribution system with AC415V, 50/60Hz, rated working current up to 100A to protect against overload and short circuit. The item is installed into plug-in type mounting base.

Specifications
Electrical Life (Times) 6000
Mechanical Life (Times) 20000

SPECIFICATIONS
RATED CURRENT	POLE NUMBER	RATED WORKING VOLTAGE(V)	RATED SHORT CIRCUIT BREAKING CAPACITY
			TEST EXPECTED CURRENT(A)	POWER FACTOR
			TEST EXPECTED CURRENT(A)	POWER FACTOR
6,10,16,20,25,32,40	1,2	230/240	6000	0.65-0.70
	1,2	230/400,240/415	6000	0.65-0.70
	2,3,4	400/415	6000	0.65-0.70
50,63	1,2	230/240	4500	0.75-0.80
	1,2	230/400,240/415	4500	0.75-0.80
	2,3,4	400/415	4500	0.75-0.80

Yueqing Heng Nuo Imp. & Exp. Co., Ltd. is the export department for TENGEN GROUP Co., Ltd, it is one leading manufacturer and exporter in the fields of electrical apparatus, wiring accessories, hardware, fire alarm system, tools and so on, our company located in Liushi town of Wenzhou city where is the largest production centre in China for electrical products.

From 1983 to now, our company has cooperated with more than 80 factories, and produces over 20 kinds, thousands of models of high quality electric products yearly. Mainly including:

1. Electrical apparatus: Circuit breaker, AC contactor, Relay, fuse, timer, counter, distribution box, meter socket, current transformer, meter, pushbutton switch, LED pilot lamp, limit switch, pedal switch, float switch, industrial plug & socket, Stabilizer and so on.

2. Wiring accessories: Cable tie, cable clip, cable puller, cable marker, cable lugs, cable glands, terminal blocks, wiring ducts, insulated terminals, MCB insulated busbar, dinrail and so on.

3. Hardware: Flexible conduit & connector, EMT fittings, Metal switch boxes and so on.

4. Tools: Hand crimping tools, cable cutter, hydraulic crimping tool, tester, screwdriver and so on

5. Fire alarm and warning system: Fire alarm bell, electric bell, smoke detector, motor siren, buzzer, warning light and so on

Internationalization standard quality guarantee system:

The product quality of Tengen Group has been strictly controlled in each working procedure,

Many kinds of internationalization standard quality guaranteed system can be highly effective

Under company's strict monitoring. Fellowtrader commended, customer's approval can sufficiently

Make sure of our product quality.

"Tengen" was evaluated as " Chinese famous trademark", Tengen Group has obtained American

FMRC Corporation ISO9001 quality system authentication, ISO14001 environment management

System authentication, CCC authentication, European Union CE safe Authentication, American UL

Authentication and Dutch KEMA authentication and so on, at the same time, it has had the first

Side laboratory -- low voltage electric appliance test center which is the first connected with

International in China.

We promise to offer you superior products, favorable price, and timely delivery. If you are interested in cooperating with us, please feel free to contact with us in your earliest convenience time.
