Big Capacity Hollow Compression Load Cell (BR153D)

Name: Big Capacity Hollow Compression Load Cell (BR153D)
Brand: all-electronics-online.com
SKU: 834089315
Availability: InStock
Rating: 4.5 (71 reviews)

Price:	Negotiable/Piece
Min Order:	2/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	BR153D
Measurement Force:	Compression Force Measurement
Size:	31.8mm9.9mm(DiameterHeight)
Product Type:	Miniature Force Sensor
Capacity:	5, 10,20,50, 100kn
Applications:	Industrial Testing and Control System
Pattern:	Load Button
Feature:	High Accuracy
Production Process:	Put on Strain Gauge

Product Description

BR153D is a Load Button Load Cell with Threaded Mounting Holes built for Press, or Inline compression applications. This Load Button Load Cell model has a very robust construction available in 17-4 Stainless Steel, with 20mm outside diameter and a 4 meters long 24 AWG 4 conductor shielded cable. You will also find options for external matched output readily available.

Although Load Button Load Cells are traditionally not known for their high accuracy, our engineers have dispelled this concept by continuously improving the accuracy of this product. The Load Button Load Cell offers high accuracy. It has Nonlinearity of ±0.5% and Repeatability of 0.20%F.S. nominal. The standard Load Button Load Cell can be modified or customized to meet your requirements and most capacities are in our inventory, making them available for 24 hour shipping.

Product Highlights:
Low Deflection
17-4 Stainless Steel Construction
Compression force
Utilizes Metal Foil Strain Gauge Technology
Low profile,small deflection and mini dimension
Made of stainless steel,High temperature could be customized
IP65 protection, customizable
Suitable for Automotive press fit, automated assembly, 3C products testing, new energy product assembly, medical testing, robotics, mold assembly and other industrial testing and control system
High dynamic response frequency

For those who are a looking for a complete system solution, we can provide both signal conditioned displays or our VCal Portable System. Our VCal Portable System brings an easy-to-use system verification directly to the customer making it ideal for on-site verification and calibration of your products.

1	Specifications	Technique
2	Capacity	5, 10,20,50, 100kN
3	Rated output	1.0±20%mV/V
4	Zero balance	± 0.05mV/V
5	Non-linearity	0.20%F.S.
6	Hysteresis	0.20%F.S.
7	Repeatability	0.10%F.S.
8	Creep(30min)	0.10%F.S.
9	Temp.effect on output	0.05%F.S./10ºC
10	Temp.effect on zero	0.05%F.S./10ºC
11	Input impedance	780±20Ω
12	Output impedance	700±10Ω
13	Insulation	≥5000MΩ/100VDC
14	Recommended excitation	5V
15	Maximum excitation	10V
16	Compensated temp range	-10~60ºC
17	Operation temp range	-20~80ºC
18	Safe overload	150%F.S.
19	Ultimate overload	200%F.S.
20	Cable size	φ2×4000mm
21	Weight approx.	0.1kg
22	Material	Stainless Steel
23	IP Class	IP66

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.

Who Brans cooperate with?

Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
