Bridge Type Load Cell (CZL117)

Name: Bridge Type Load Cell (CZL117)
Brand: all-electronics-online.com
SKU: 761361925
Availability: InStock
Rating: 4.7 (30 reviews)

Price:	US $ 100/Piece
Trade Terms:	FOB,EXW
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	CZL117
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Rated Load(t): 5, 10

Main features: Alloy steel & stainless structure; bellows hermetically sealed by laser, nickel plated, waterproof and anti-corrosion, suitable for multiform environments; suitable for electronic platform scales, hopper scales, and other electronic weighing devies.

Parameters
Precison : G2		Temp. effect on span(%F.S/10°C): ±0.03
Comprehensive error(%F.S) : ±0.2		Temp. effect on zero(%F.S/10°C): ±0.05
Rated output(mv/v) : 2.5±0.008		Compensated temp. range(°C ) : -10~+40
Creep(%F.S/30min) : ±0.05		Use temp. range(°C ) : -20~+55
Zero balance(%F.S) : ±1.0		Excitation voltage(V) : 9~12(DC)
Input resistance(Ω) : 700±10		Safe overload (%F.S) : 120
Output resistance(Ω) : 700±5		Ultimate overload (%F.S) : 150
Insulation resistance(MΩ) : ≥5000(100VDC)		Defend grade : IP66

Installation size (mm): 598x48x56

Wiring schematic diagram:
Red: Input ( + ) White: Output ( - )
Black: Input ( - ) Green: Output ( + )

Notes:It used 6-core shielded cable(φ5×6000mm)

Guangdong South China Sea Electronic Measuring Technology Co., Ltd. (SCS)is located at Dongguan City, Guangdong Province, Where is the manufacture centre of China. Established in 1992, it specializes in developing and manufacturing advanced load cells, force sensor, Torque sensor, axle weigher, wheel weigher, pressure transducer based on strain-gages. We also manufacture custom designed load cells and weighing system whatever our customers can dream up. Some of our products have "OIML" and European approved "CE" mark. Hope we will establish a long term business-ship with you.
