Brushless Sensored Motor for Textile Machine (FXD57BLDC-001A)

Name: Brushless Sensored Motor for Textile Machine (FXD57BLDC-001A)
Brand: all-electronics-online.com
SKU: 759819995
Availability: InStock
Rating: 4.8 (53 reviews)

Price:	US $ 54-80/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FXD57BLDC-001A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Speed Of The Motor:	10-1000 Rpm
Power Of The Motor:	1-200 Watts
Torque Of The Motor:	0.5-15 N.M
Price:	Negotiable and Competitive Price
Nane:	23
Application:	Power Tools
Operating Speed:	Adjust Speed
Excitation Mode:	Compound
Structure And Working Principle:	Brushless
Type:	Brushless DC Motor
Certification:	CE,RoHS
Brand:	Fxd Motors

Product Description

Model:FXD 57 BLDC -36 - 23	General Info
A B C D E	Winding type	Star/Delta
Note: A Fuxianda	Hall effect angle	120 degree electric angle
B Motor dia or square size	Shaft runout	0.025mm
C Brushless dc motor	Radial play	0.06mm/50g
D Rated voltage	End play	0.08mm/50g
E Rated power	Max radial force	28/N20mm from the flange
	Max axial force	10N

Motor Specification

Model	Number of Phase	Rated voltage	Rated speed	Rated torque	Rated power	Mass	Body length
Model	Phase	VDC	rpm	N.m	watts	g	mm
FXD57BLDC3623	3	36	4000	0.055	23	400	45
FXD57BLDC3650	3	36	6000	0.08	50	450	55
FXD57BLDC3692	3	36	4000	0.22	92	700	75
FXD57BLDC24133	3	24	4000	0.32	133	950	95
FXD57BLDC24180	3	24	4000	0.43	180	1200	115

Applications:
The bldc motor manufactured by us has wide range of application like robots, electronic automatic equipment, medical instrument, advertisementing instrument, lighting& audio equipment, printer, textile machinery, CNC router etc.
Note: If you have some different specifications, we can product stepper motor as your special requirements.
Web: http://fxdmotor.en.made-in-china.com/ Phone:+86 0519 83666368
http://www.fxdmotors.com Mob: 15295151006

Why choose us? 1. Environmental friendly
2. In time delivery
3. Negotiable and competitive price
4. CE, ROHS, SGS certification
5. In time after-sale service
6.2-year guarantee period
7. Custom products

We also provide stepper motor, brushless gear motor, brake, driver, customized products etc. You are welcomed to visit our website to get details. http://wwww.fxdmotors.com.

Changzhou fuxianda Electromechanical Co., Ltd is established in November 2011. Our company is a factory with products Brushless DC motors, Hybrid stepper motors, gearmotors and matched drivers.

Changzhou fuxianda Electromechanical Co., Ltd also have several joint venture companies who specialized in the production of AC servo motor, PM stepper motor, PM synchronous motor and Brush DC motor. We export our motors to more than 10 countries such as United States, France Italy, South Africa and Russia.

The Fuxianda product line is sold to major manufacturing companies for industry for automation, medical and health care equipment, printer machines, packing devices, information technology, household appliance products, and automobile.

We have an engineering team with many years of experience in application engineering, design engineering with the latest advances equipment. Our engineering staff provides the finest quality product with service after the product is delivered to our customers.

The possession of many excellent mechanical-electronical engineers and marketing personnel make our company skillful at providing customers with the plan of products integration.

Most of our products are CE approved. Our company adheres to principles of "Providing green products" and all of our products are RoHS compliant.

As a global supplier, Changzhou fuxianda electromechanical Co., Ltd scrupulously follows the guideline of international commercial rules and practices. We have achieved our reputation of cooperation with our customers over the years. Our Goal is to "Win the market with quality and service" which is the common voice of every Changzhou fuxianda Motor team member.

Good quality, reasonable price, on time delivery, efficient service is our pursuit. We are looking forward to cooperating with more friends in the future.
