Buttons & Leather Laser Marking Engraving Machines
| Price: |
US $ 3200-4000set |
| Min Order: |
1set |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
LS-CO2-100D |
| Model: |
Ls-Co-100d |
| Laser Power: |
30W;50W;100W |
| Power Consumption: |
<500W |
| Wavelength: |
1064nm |
| Engraving Range: |
75*75mm;110*110mm;Optional |
| Engraving Depth: |
1.2mm |
| Minimum Line Width: |
0.012mm |
| Minimum Character: |
0.1mm |
| Repeated Accuracy: |
+-0.003mm |
| Life Of Laser Module: |
100000hrs |
Product Description
Buttons & Leather Laser Marking Engraving Machines
>>>>>>Equipment Description<<<<<<LoSpeed Fiber Laser Marking Machine adopts advanced digital high speed scan galvanometer and module design that separate laser generator and lifter, which is not only small volume, quick speed, but easily marks on big objects surface. Fiber Laser Marking Machine 20W 50W Widely used in food and beverage,leather, packaging, cosmetics, electronics and other industries, low consumption, non-toxic, no pollution. >>>>>>Machine Features<<<<<<
Adopting originally imported USA CO2 Radio Frequency Metal Laser tube and laser Power supply. Originally imported marking software and Scanner Lens, adjustable laser power is controlled by software. Processing cost is low, no consumable materials, marking area is big and fine. Cutting speed is efficient, engraving low or deep can be adjusted freely, suitable for all kinds of products.
>>>>>>Technical Parameters<<<<<<| Wavelength: | 10.6um |
| Average power: | 30W;50w;100w |
| Output stability(8h: | ±5% / 10% |
| Marking area(optional): | 110mm×110mm,300mmx300mm,400mmx400mm,
500mmx500mm,800x800mm |
| Working distance: | 245mm±2mm |
| Marking speed: | ≤3m/s |
| Marking depth: | ≤5mm / ≤8mm |
| Min. line width: | 0.12mm |
| Min. character size: | 0.6mm |
| Repetition accuracy: | ±0.01mm |
| Supply voltage: | 220V/10A / 220V/20A |
| Power consumption: | 2kW / 4kW |
| Environmental resistance | Temperature: | 15~30ºC |
| Humidity: | 45%~75% |
| Marking graph: | User-defined character, CAD data |
| | BMP, JPG, PNG, TIF, PCX, TAG, IOO, GIF, PLT |
>>>>>>Laser Marking Sample Show<<<<<<
>>>>>>Company Information<<<<<<LoSpeed Laser Company is a modern professional Hi-Tech enterprise, specializing in manufacturing of Fiber Laser Marking Machine,CO2 Laser Marking Machine,UV Laser Marking Machine, Portable Laser Marking Machine,Mini Handheld Laser Machine,and Laser Engraver Machine, Laser Tube, Laser Power Supply, Laser Optics and Laser accessories etc.
Lospeed Laser mainly product is including:
Buttons & Leather Laser Marking Engraving Machines , Mini Laser Engraver, Co2 Laser Tube, Laser Focusing Lens, Laser Reflector Mirror, Laser Power Supply, Laser Cooler Unit, Laser Scanner Head, Laser Control System, Laser Cutting Head, Beam Expander, Red Pointer,Laser Rotary Table,3D Laser Table,Laser Rotary Chuck,Laser accessories etc.>>>>>>Contact Us<<<<<<Lospeed Laser is a real manufacturer of fiber laser marking machine,contact us for further information if you are interested,thanks a lot.
Please advise us following inforamtion to recommend you most suitable machine:
1.What's kind of material do you want to mark? metal parts or non metal material?
2.What's the max working area do you need? we can provide you with 110*110mm, 175*175mm, and 220*220mm, 300*300mm, or customized as your demand
Get Contact with Us Now!
Lospeed Laser is a professional Laser Marking Machine Manufacturer.
We are looking for distributors and dealers. This Machine is with stable quality and profitable niche.
Contact us, let's talk more.
Our Products and Service:
--Marking Machine Series--
20watt fiber laser marking machine(Model: YLP-20L, YLP-20C, YLP-20J, YLP-20M, YLP-20M6)
30watt fiber laser marking machine(Model: YLP-20C, YLP-20J)
50watt fiber laser marking machine(Model: YLP-50C)
60watt fiber laser marking machine(Model: YLP-60J)
15watt CO2 laser engraving machine(Model: CO2-15)
30watt CO2 laser engraving machine(Model: CO2-30)
Portable fiber laser marker
--Laser Machine Spare Parts--
Laser Source / Laser Diamond
CO2 Laser Tube
Galvo Scanner Head
F-theta Lens
Controller Card
Laser Power
Red Indicator
Laser Lens / Laser Mirrors
Rotary fixture
Machine Cabinet
--Laser Maintenance--
Gas Filling Refill for CO2 Coherent Laser Tube
--Laser Marking Engraving Solution--
--Laser Products & Laser Gifts--
Good Price, Good Quality, let your products to be more attractive.
Contact us NOW.
Introduction
Lospeed Laser is a company specialized in the research, development, production, sales, training and after-sales of laser marking equipment.
Loseepd sincerely provide customers with full range of laser solutions.
Our Business Principles
"Focusing on customers and regarding the quality as the life". To assist customers to complete a variety of process problems and technical research, to help customers achieve profitability an expectation in production from the technical aspect and to establish an interactive and win-win partnership with customers.
Our Enterprise Culture"People-oriented" is the concept of our corporate culture. This is excellent, motivated and dynamic team, rich in professional knowledge, is creating new possibilities for the laser industry in China.
Our Advantages
Quick Service:
There are professional maintenance engineers and a variety of standby parts in the company.
Full Service:
We provide customers with complete laser processing solutions, including process testing, personal training, parameter reference, feeding system, efficient operation, routine maintenance, troubleshooting and so on.
Caring Service:
With many years experience in the laser manufacturing industry, the company always pursue for the details perfect and quality first from research and development, procurement, production, sales to after-sales standing on the customers' positions.
Our Products
We have fully matured in the design and manufacturer of products. Our main products include fiber laser marking machine, non-metallic CO2 laser engraving machine, CO2 laser cutting machine, CO2 High power laser cutting machine and laser machine parts.
Elite Team
A good business can not do without a good organization, a good organization and ultimately a better team. LOSPEED LASER Group, with an excellent technical team to create laser products has become a thriving industry, with the innovation needs of the community and enjoy the fusion of cutting-edge technology equipment, combined with practical application and development of the system to achieve a diversified domestic market and the simultaneous development of foreign trade cooperation.
