| Prod Model: |
TCC |
| Environmental Certification: |
ISO14001 |
| Quality Certification: |
ISO9001 |
| Safety Certification: |
CQC03003095~3097 |
| Other Certification: |
RoHS |
| Material: |
Copper |
| Type: |
Choke Inductor |
| Structure: |
Inductive Choke |
| Brand: |
Liwang |
Product Description
ferrite core toroidal inductor
| Toroidal Inductor Transformer Series |
| Model :OR8-OR102(inductance coil color:green, gray, red, yellow and white) |
| No. | Model | Outer diameter(mm) | inside diameter(mm) | High(mm) |
| 1 | OR8x5x3 | 8.0 | 5.0 | 3.0 |
| 2 | OR10x6x5 | 10.0 | 6.0 | 5.0 |
| 9 | OR12x6x4 | 12.0 | 6.0 | 4.0 |
| 11 | OR13x6x7 | 13.0 | 6.0 | 7.0 |
| 12 | OR13x7x5 | 13.0 | 7.0 | 5.0 |
| 13 | OR14x8x7 | 14.0 | 8.0 | 7.0 |
| 16 | OR16x8x5 | 16.0 | 8.0 | 5.0 |
| 17 | OR16x9x5 | 16.0 | 9.0 | 5.0 |
| 21 | OR18x10x10 | 18.0 | 10.0 | 10.0 |
| 23 | OR19x13x11 | 19.0 | 13.0 | 11.0 |
| 26 | OR20x12x10 | 20.0 | 12.0 | 10.0 |
| 27 | OR22x14x8 | 22.0 | 14.0 | 8.0 |
| 31 | OR25x15x12 | 25.0 | 15.0 | 12.0 |
| 36 | OR28x18x13 | 28.0 | 18.0 | 13.0 |
| 38 | Or29x19x15 | 29.0 | 19.0 | 15.0 |
| 39 | OR31x18x14 | 31.0 | 18.0 | 14.0 |
| 40 | OR31x19x13 | 31 | 19 | 13 |
| 44 | OR36x23x15 | 36 | 23 | 15 |
| 46 | OR38x19x13 | 38 | 19 | 13 |
| 47 | OR38x19x15 | 38 | 19 | 15 |
| 52 | OR40x23x20 | 40 | 23 | 20 |
| 53 | OR40x25x20 | 40 | 25 | 20 |
| 54 | OR42x26x18 | 42 | 26 | 18 |
| 55 | OR45x30x15 | 45 | 30 | 15 |
| 56 | OR47x27x15 | 47 | 27 | 15 |
| 57 | OR48x30x10 | 48 | 30 | 10 |
| 58 | OR48x30x15 | 48 | 30 | 15 |
| 60 | OR49x31x19 | 49 | 31 | 19 |
| 62 | OR50x25x20 | 50 | 25 | 20 |
| 63 | OR51x31x13 | 51 | 31 | 13 |
| 64 | OR56x32x18 | 56 | 32 | 18 |
| 66 | OR58x40x18 | 58 | 40 | 18 |
| 67 | OR60x38x20 | 60 | 38 | 20 |
| 70 | OR63x38x25 | 63 | 38 | 12.7 |
| 71 | OR68x44x15 | 68 | 44 | 15 |
| 72 | OR74x40x13 | 74 | 40 | 13 |
| 73 | OR80x50x20 | 80 | 50 | 20 |
| 74 | OR87x54x14 | 87 | 54 | 14 |
| 75 | OR87x54x30 | 87 | 54 | 30 |
| 76 | OR100x50x20 | 100 | 50 | 20 |
| 77 | OR102x66x15 | 102 | 66 | 15 |
Product description of Power coils inductors 5mH 20A Inductor Exported to Worldwide.Specifications:
1. High frequency
2. Low magnetic leakage
3. Useful various power coversion and line filter application
4. Low radiation noise based on toroidal construction
5. Various material available to meet different frequency requirements.
6. Special specifications available upon request
7. Primary competitive advantage: Country of region; small order accepted ;Experienced technical staff ; Pass ISO ,RoHs,UL;Standard Packing
Applications:
1. Switching power output and smoothing circuits
2. Used as choke coil for high frequency SMPs
3. Countermeasure against spike ripples
4. EMI/RFI filters
5. DC/DC converters
6. IP and OP devices
Headline |
Help you quickly complete the new product's whole
process within 3 days from design production to delivery. |
Basis of title |
The entire process is completed internal, in order to
ensure that you can get faster delivery service
than from any other supplier. |
We introduce the most advanced technology
continually to meet the most stringent quality standards,
every product is tested,and returning rate <0.01%,
so that we can meet the needs of buyers from more than 70 countries. |
Other advantages |
1,Complete Certification and standards: UL;
ISO9001; ISO14001; SGS; REACH; RoHS;TS16949 |
2,Factory Area: 13000 square meters |
3,Production capacity: 30,000,000 pieces of
transformers, inductors, coils,resistors |
4,Service: provide customers with the most
satisfactory service to solve the product difficult |
5,"3 fast": Replying fast; Offering fast; Delivering fast |
company profile |
Changzhou Southern Electronic Element Factory Co., Ltd.
was founded in 1989 and is a high-tech company
which integrates production, design, R&D, and sale.
We specialize in developing many
kinds of electronic components. Include electronic
transformers, SMD power, inductors coils,
fixed inductors, toroidal coils, common mode chokes, resistors and transformers.We are ISO 9001 and ISO 14001 certified and our
products come with UL, RoHS and SGS marks.
For more details, please contact us without hesitation. |
All products of the size, electrical performance can be designed.If you have any questions or requirements,please contact us freely in any time.Our advantage:
1.More than 5,000,000 ownstock inventory to meet your needs of different products.
2.Competitive price advantage helps to save your purchase cost and your precious time.
3.Own the international advanced testing equipment of electronic components and scientific storage system to ensure the quality stability.
4.Excellent elite team, more than 5 years seniority, and a good understanding of international market trends.
We'll reply you within 24 hours.If any questions or concerns pls contact us at any time convenience to you
Thank you and Have a nice Day!
Changzhou Southern Electronic Element Factory Co., Ltd. is located in China, with a long history. We enjoy convenient transportation by highway, railway and airway. It takes only one and half hours' Drive to Shanghai or Nanjing.
Our company was founded in 1989, and currently we employ more than 300 people, including 60 professional technicians, covering an area of 10, 000 square meters, with a construction area of more than 5000 square meters. Our main products are wirewound resistors, wirewound resistor fuses, membrane fuse resistors, fixed inductors, filters, ferrite transformers, ring-shaped coils, fuse dedicated energy-saving lamps and UL fuses. Our annual output is 200 million resistors, 200 million transformers, 100 million coils and 200 million fuses, which are mainly used for household appliances, communication equipment, energy-saving lamps, automation control devices (such as inverters), power equipment and facilities. Our products are exported to Europe, the United States and Southeast Asia. GE, OSRAM and PHILIPS are our customers.
