C45 Isolator Switch (CEI45 Series)

Name: C45 Isolator Switch (CEI45 Series)
Brand: all-electronics-online.com
SKU: 615749914
Availability: InStock
Rating: 4.9 (23 reviews)

Price:	US $ 0.83/Piece
Trade Terms:	FOB
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	CEI45-1P 100A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current:	32A~100A
Rated Voltage:	230(240)/400(415)V
Type:	Low-voltage
Structure:	Single-column Disconnector
Operation:	Electric
Installation:	Fixed
Number Of Poles:	1p,2p,3p,4p
Brand:	Cea

Product Description

C45 Isolator switch
Application:
It is a isolator, no overload protection function, and works to connect to cut off the load circuit. When it works as main switch, it may also trip when some of it's sub-circuit faulty. In such situation, it functions as main switch to function as earlier circuit protection.

Main technical parameters:
Standard: IEC60947-3 GB14048.3
Rated current: 100 A
Rated voltage: 50 Hz, 230V/400V
Rated operating current: 32A, 63A, 100A
Rated short time withstand capacity: 25 KA(connect 100A fuse protector)
Pole: 1P, 2P, 3P, 4P
Electric life: ≥ 1500 times
Mechanical life: ≥ 1000 times
Using type: AC-22
Protection class: IP 20
Operating temperature: -5 + 40C
Altitude: ≤ 2000m
Pollution level: Grade 3
Installation: IEC standard, DIN rail 35mm
Installation: The main switch be vertically installed, handle up means current connection.
Place: No oblivious or frequent vibration or impact

Breaking Capacity: H: 10000A; N: 6000A; L: 4500A

Rated Voltage	230(240)/400(415)
Rated Current(A)In	32, 40, 63, 80, 100
Frequency(Hz)	50/60
Short-circuit Bears to Suffer Capacity	Connected to 100A, Fuse to 25KA
Making or Breaking Capacity	1.25In; 1.1Ue
Usage Category	AC22
Connection Wire Cut	Max. 50mm
Protection Grade	IP40(Install the term)
Insulation	Appearance of clear and definite switch Position according to DIN VDE0106

Founded in 1999, CEA Group International Co., Ltd.Is being acknowledged as one of the most respected nationwide manufacturers and exporters of low voltage electrical apparatus in P.R of China.

The Group, comprising 5 factories, owns a production area of 50, 000m2 and employs more than 1, 000 staff.During the past 13 years, we invested abundant resources in both research and development and employee training programs.The company was ranked in the front of 100 tops of wenzhou private enterprises." CEA" is named as a famous trademark in domestic and overseas markets.Our company has took the lead in applying IS09001 Quality Management System and ISO14001 Environmenttal Management System.Many products are certified under international certificate, such as CB, CE, BS, VDE, UL, SONCAP, CCC.

Currently, we have manufactured and exported more than 160 varieties of products, with over 2000 types of low voltage electrical apparatus including all kinds of LED lighting, Circuit Breakers, Contactors, Relays, Starters, Switches, , Wire & Cable and Electrical Accessories etc.As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching South East Asia, Middle East, South America, Africa, Europe.

We are fully aware of the fact that only "Versatile Staff, Distinctive Quality and Advanced Technology"enable us to survive and succeed in today's intensively competitive market.Hence, we will be with overall technology support, good service to meet the requirements of world.

Enquiries from both domestic and overseas customers are cordially welcomed.Just Tell Us Your Requirements and Let Us Do The Rest For You!
