| Prod Model: |
LLT-BSJ-VER1.5.1 |
| Device Type: |
Navigation |
| Suitable Model: |
Porsche |
| Main Function: |
Android Navigation |
| Android Version: |
4.4 / 5.1 |
| CPU: |
Quad Core 1.6 GHz |
| RAM: |
1 / 2 GB |
| Storage: |
8/16 GB |
| Video Support: |
HD 1080P |
| WiFi Bluetooth: |
Yes |
| Type: |
GPS Navigator |
| Operating Principle: |
Square Type |
| Port Number: |
Multiplex Multi-purpose Channel |
| Carrier Frequency: |
Dual-Frequency |
| Chip: |
SiRF |
| Model: |
Llt-Bsj-Ver1.5.1 |
| Brand: |
Lsailt |
Product Description
Car Android Navigation System Video Interface box For Porsche Macan, Cayenne, Panamera;
Upgrade Touch Navigation,WIFI,BT, MirrorLink,HD 1080P,Google MAP, Play Store,Voice
Android's features:- Android 5.1 & 4.4 system, Quad core 1.6GHz A9 chip, faster running speed.
- Compatible all Android app include YouTube, Waze, Real-time & offline navigation etc.
- Car origin rear view & front view is compatible, DVR, 360 panorama, TV box, TPMS optional.
- Connection include Wi-Fi Bluetooth USB.
- Could be switch to origin system with just one click on dashboard and steering wheel.
- Simple plug & play installation.
Brand: Lsailt Model: LLT-BSJ-VER1.5.1
Standard Configuration: Video Interface (Trajectory Reversing,Front View,Video Input)and Android Navigation Box;
Suitable car model: 2010-2015 Porsche Macan, Cayenne, Panamera(Car PCM3.1 System);
Upgrading Function:Touch Android Navigation System,Trajectory Reversing,Front View,DVD,TV,360 Panoramic,DVR,TMPS etc.
Custom Properties| Way to Install | Original Car Screen Installation | Advantage | Retains All Features |
| RGB IN | Support | AV IN | AV1 or AV2 |
| DVR IN | Support | Rear View | Support |
| Front View | Support | 360 | Optional |
| CPU | 1.6GHZ | RAM | 1GB/2GB |
| Flash | 8GB and 16GB | HD Video | 720P/1080P |
| Working voltage | 9-12V | OS | Android4.2.2/4.4.1 |
| HVGA | 800X480 | MAP | GOOGLE MAP/IGO |
| Play Store | Support | Voice | Support |
| WIFI | Support | Specific Features | One-Key Reset |
| BT | Support | MirrorLink | Support |
Advantage for Upgrading 1.Nondestructive installation design, do not damage the original car lien, special interface wire, plug-up installation without wire cut;2.Select installation function freely (handwritten navigation, BT, DVD, Reversing, 360 panoramic, automobile data recorder, TPMS, mobile Internet app etc).Make low-end surpass high-end, and make up the function defect of high-end car;3.Technology is comparatively reliable; Do not involve in the original car agreement. Technology risks are fewer and safer comparatively;4.Remain all functions of the original host after upgrading. If there are some wrong with navigation, it will not have influence on the original car function;5.Convenient After-sale service; point-to-point reparation, do not involve in original car accessories, it is more simple, fewer risks, safer and more reliable than dedicated machine;6.Real nondestructive installation of Original car type, remain all functions of the original host after upgrading and tackle the problem of the new "Three Parks of Policy" and 4S that do not support warranty;7.Original car UI design, perfect match. Long presses touch screen or original car button to switch navigation pattern.
Features of Android system Master processor:RK3188T Quad-Core Processor(RK 3188T/RK 3188/PX3)basic frequency is 1.6G.
Memory capacity:1G DDRIII, 2G DDRIII optional.
Flash memory:8G EMMC Flash, maximum 64G.
OS:Android 4.4.4 or 5.1
GPS receive:support AGPS function
GPS antenna:3V active antenna
GPS antenna protection:prevent the antenna short circuit
WiFi module:RTL8188/RTL8723.
BT module:RTL8723BU,support BT4.0, firmware support Bluetooth functions.
A2DP,Bluetooth telephone.
Support USB 3G dongle,WiFi can be as a hot spot output.
Support USB camera which support DVR.
Synchronizing signal:composite synchronizing signal. Separate sync signal.
Video output format:simulate RGB and CVBS composite synchronizing signal output , one of them optional.
Analog video output:Support the display position adjustment,and brightness contrast adjustment.
The resolution of the video output:800×480,1024X600,Maximum 1920X1080,Support any resolution.
Audio output:Left and right channel stereo output with audio valid indication signal.
Sound Control output:IO output or UART output.
Single track MIC input:support voice navigation, support SPDIF output.
Touchscreen interface:Support 4-wire resistive touch (support two point touch function), support serial touch, two ways to touch without modifying the hardware. Change software will be ok.
Memory card types:support maximum 64 gb TF/SD card, support read U disk, mobile hard disk storage.
USB port :USB OTG 2.0 .
Supported map software:APK install automatically or installation package .
Voltage range: 7 ~ 16v (optional 9 ~ 28V), with undervoltage shutdown (7V protection shutdown).
ACC control: ACC support delay shutdown, and SLEEP combination can be set off at any time.
Please add me on +86-136 9976 5242 Cosmo) for directly contact!
| Product Accessories |
| Interface box | 1(standard configuration) |
| Android box | 1(standard configuration) |
| LVDS IN | 1(standard configuration) |
| LVDS OUT | 1(standard configuration) |
| AV IN/OUT | 1(standard configuration) |
| POWER Line | 2(standard configuration) |
| GPS ANT | 1(standard configuration) |
| WIFI ANT | 1(standard configuration) |
| Specification | 1(standard configuration) |
| Warranty card | 1(standard configuration) |
| Microphone | 1(standard configuration) |
| SPK | 1(standard configuration) |
| Map card | 1(standard configuration) |
| Interface Parameter |
| Model | LLT-BSJ-VER1.5.1 |
| Brand | (Lsailt) |
| Car Screen Size | 8 " |
| Type | Silver interface box |
| Display | LVDS/GVIF Signal transmission(The Board) |
| RGB Input | One |
| AV Input | Two |
| DVR Input | One |
| Front View | One |
| Rear View | Track Reversing and Video |
| Customization | Negotiated |
| General Parameters Andrews |
| CPU | 1.6G Hz |
| Model | Cortex A9 Four dual-core processor,car rule PX3 |
| RAM | DDR3 1GB/2GB |
| Flash | Inand standard equipped,8GB or 16GB |
| Navigation Storage | TF card |
| OS | Android 4.2/4.4 |
| HVGA | 800X480 |
| WIFI | Support |
| BT | support BT4.0 |
| MirrorLink | Android and OS The android support touch |
| Operating Voltage | DC(9-15)V |
| Operating Current | Normal 400 mA@12V |
| Operating Temperature | -20°C-+70°C |
| Storage Temperature | -30°C-+80°C |
| Audio Output | Left and right channels,stereo,distribute the signal and analog output |
Quality warranty policy:3 month free replacement and 1 year free maintenance.Deliver 1 or 2 days after payment received.
