Car Tracking Device with PC Based Tracking System

Car Tracking Device with PC Based Tracking System
Price: Negotiable/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: GP4000
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brand: Jointech
Function: GPS Tracking
Color: Silver
Unique Feature: Support 10 Kinds of External Sensors
External Sensors: Fuel Sensor, Thermal Sensor, RFID, Camera
Dimension: 103*71*26mm
Working Voltage: 10-30V
GSM Band: 850/900/1800/1900 MHz
GPS Chip: Sirf Star III
Type: GPS Tracker
Use: Automotive
Screen Size: No

Product Description

Gp4000 is a mainstream GPS/GSM/GPRS vehicle tracking device, designed as solution for fleet management, which is a robust fleet tracking device not only allows mdt but also supports external high precision fuel sensor.

*Advantages:
Multiple useful fleet management reports
Excellent redevelopment ability
More than 10 kinds of sensors supported

*Applications:
Vehicle tracking/monitoring
Vehicle data warehouses
Fleet management
Vehicle securities/recoveries/anti-hijacks
Mobile asset tracking/monitoring
Location based services
Taxi/bus groups

*System features:
1. Low power consumption & wide voltage input
2. Multiple intelligent uploading modes, especially data uploading for angel variation.
3. Built-in triaxial G sensor applicable to different customized projects including intelligent harsh braking alarm.
4. Built-in road and polygon Geo-fence with alarms for road deviation, road speeding, zone speeding, zone overtime, etc...
5. More than 20 kinds of alarm are available (SMS, GPRS).
6. More than 10 kinds of external devices are supported with excellent redevelopment frame.
7.43, 200 pieces of history data storage with the feature of continuing transferring from breakpoint.
8. OTA

*Interfaces:
Port A: Power and vehicle control
Port B: Detecting 14-channel vehicle signal
Port C: Connect to additional peripheral, such as RFID, scanner, sensor
I/O: 11 digital input/1 analog input(0-5V)/1 pulse input/8 digital output/1 RS232 COM port

*Optional items:
Fuel sensor
RFID
Camera
Thermal sensor
Tire Pressure Sensor
Barcode Scanner
Microphone
MDT
Door Sensor

Paramters:
Parameter Dimension (L×W×H) 103×71×26mm
Weight 750g  (with standard accessories)
Working Current 60-100mA
Working Voltage 10-30V
Backup Battery 8.4V  400mAh  NI-MH battery
GPS Chip SIRF Star III
GSM Band 850/900/1800/1900 Mhz
