| Prod Model: |
CBB60 capacitor |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| AC Capacitor Capacitance Tolerance: |
+/-5% |
| AC Capacitor Security Level: |
P0/P2 |
| AC Capacitor Standard: |
IEC60252-1:2001 |
| Operating Life: |
10000h (Class B), 3000h (Class C) 30000h(Class a) |
| Operating Frequency: |
50Hz/60Hz |
| AC Capacitor Filling: |
Epoxy Resin |
| AC Capacitor Can: |
Plastic Can |
| AC Capacitor Materials: |
Metallized Film |
| AC Capacitor Application: |
AC Motor, Water Pump,Condenser, Refrigerat |
| Manufacturer: |
Anhui Safe Electronics Co., Ltd. |
| Type: |
Polypropylene Capacitor |
| Application: |
Washing Machine |
| Package Type: |
Through Hole |
| Capacitance: |
1UF~120UF |
| Manufacturing Material: |
Polypropylene Film |
| Electrolyte: |
Polypropylene |
| Usage: |
Washing Machine |
Product Description
Film description:
AL-Zn METALLIZED POLYESTER & POLYPROPYLENE FILM (ZTM, ZPM), ,CAPACITOR GRADE METALLIZED BOPP FILM 4micro,4.5micro,5micro,6micro,7micro,8micro,9micro,10micro,11 micro,12micro
This film is specially used for capacitors, power electronics capacitors, film capacitors,DC capacitor, AC capacitor and so on.This film is manufactured with high purity, high isotacticity polypropylene. It has high BDV, excellent mechanical strength.
Film Specification
| Thickness | *m | 3.3 ~ 6.8 | 3.5 ~ 15 | - |
| Density | G/cm3 | 1.4 | 0.91*0.01 | ASTM D 1505/DIN 53 479 |
| Tensile Strength | MD(N/mm2) | 255~274 | 130 | ASTM D 882/ DIN 53 455 |
| TD(N/mm2) | 294 | 250 | ASTM D 882/DIN 53 455 |
| Elongation at Break | MD(%) | 110 | 180 | ASTM D
882/DIN 53 455 |
| TD(%) | 100 | 40~70 | ASTM D 882/DIN 53 455 |
| Heat Shrinkage | MD(%) | 2.2(150oC , 30 min) | 6 ( 6.0 *m ) 5 ( > 6.0 *m ) ( 120*C , 15 min ) | DIN 40 634 |
| TD(%) | 0.8~1.0 | | DIN 40 634 |
| Break-down voltage(BDV) | V/*m | 1900 | 700( 23oC, DC ) | DIN 53 481 |
| Surface Roughness | Ra(*m ) | 0.08~ 0.1 | 0.8 | JIS B 0601/DIN 4762 |
| Rmax(*m) | 1.39 | 1.09 | JIS B 0601/DIN 4762 |
| Dissipation Factor(20oC, 1KHz) | 10 -4 | 50 | 3 | DIN 53 483(20oC, 1KHz) |
| Dielectric Constant | - | 3.2 | 2.2*0.1 | DIN 53 483(20oC, 1KHz) |
| Insulation Resistance | MF(20oC) | 30,000 | 100,000 | DIN 53 482 |
| Water Absorption | % | 0.34 | <0.1 | JIS C2318/DIN 53 472 |
| Number of Pinhole(Insulation Failure) | Ea/m2 | 2 | 5 ( 6.5*m ) 2 ( 7*mMMV 11*m ) 1 ( >11*m ) | - |
Note: other specifications and size out of the table are negotiable.
FAQ
1 .Q: Are you a manufacturer or a trading company?
A: We are a manufacturer located in Tongling Anhui,Closed to Shanghai,NanJing. Welcome to visit our factory.
2.Q: What certificates do you have?
A:We strictly executive ISO9001 quality management system certification,and our products won CQC,TUV,UL,VDE and other performance certification,compliance with EU ROHS directive, with SGS report.
3 .Q: Can you provide free samples?
A: Yes, we can. Free samples are available, but the postal fee should be paid by your side.
why choose anhui safe company?
1.)As a national high-tech enterprise,we have 21 years exprience in capacitor industry,25 industry patents and a number of invention patents.
2.)To ensure the product quality and consistency,we have obtained the ISO 9001 quality system certificate and CQC product certificate.
3.)We have modern factories and purification plant,the world first-class production equipment and the technical team consisted of a number of experts.
We are committed to become a world-class supplier!
More information you can visite our website: www.capacitorfilm.com or www.anhuisafe.com
Anhui Safe Electronics Co., Ltd. is a member of Green International Group. We mainly deal with AC motor capacitors, DC link capacitors, BOPP film (polypropylene film), MPP film (metalized film), inkjet PVC ID cards, polyester heat transfer film, PET film and other related products.
Our company has arranged the production of AC Motor Capacitors since 1999. Since the foundation of our company, the high-end slitters, the large-scale high-velocity winding machines, metal-spraying machines, automatic lines, automatic test lines and other advanced lines have been imported successively from Japan, Italy and Switzerland.
The production lines are state-of-the-art with internationally first-class quality. The annual output of all types of AC Motor Capacitors is 18 million pieces. We take the lead in this industry in China. There is a standard capacitor lab and calibration rooms for weight-and-measure gauges and test instruments in our company. We have got ISO9000 Quality System Certification and are endowed with considerable strong capability of technological development and quality control.
With one decade of experience accumulation and constant renovation, our company makes three key essential technological breakthroughs in the aspects of safety, endurance and temperature resistance. The products have all kinds of quality approvals to enter international markets such as CQC, UL, cUL, TUV and VDE. The products are suitable in diversified kinds of domestic and overseas prestigious-branded air-conditioners, refrigerators, compressors, washers, illuminators and other industries.
Our company is located in Tongling city-- ecological city of China. Our company adjoins to Shanghai, Nanjing and Ningbo and is close to traveling scenic spots of famous Huangshan Mountain and Jiuhuashan Mountain.
"good faith, serving the whole world" is our principle.
