Cbb65 Motor Start Capacitor

Prod Model:	cbb65
Raw Material:	Aluminium Plate
Max Width:	590mm
Max Length:	2050mm
Surface:	Powder Painting
Coating Thickness:	40-90um
Hardness Of Coating:	More Than 2h
Impact Of Coating:	50cm.Kg/Cm Impact, No Crack
Type:	Polystyrene-film-capacitors
Application:	Air Conditioner
Package Type:	Through Hole
Capacitance:	>100uf
Structure:	Variable Capacitor, Double/Single/Part Single Side

Product Description

Specifications
1.Used widely in motors,air conditioner ,water pump etc
2.High performance & Long life Capacitor.
3.work well even in hot area
CBB65 RUN CAPACITORS
Main Feature:
Low dissipation factor small inherent temperature rise, excellent
self-healing stability safety and high voltage withstand etc.
Applications:
Run starting in household electric appliances air conditioner,
refrigerator which demand 50/60Hz AC power supply Have
safe protection constrution.

Specifications

Climatic category	Rate voltage	Testing voltage T-T	Testing voltage T-C	Capacitance tolerance	Dissipation factor
-25/+70/21 -40/+85/21	370/440VAC	1.75Un/5S (2Un/5S)	2000V.AC/5s	±5% (±10%)	≤0.002 (100Hz)

Capacitance range:2MFD-100MFD,15+5MFD-80+7.5MFD
Dimension(mm):D: Φ40-Φ60,H:60-150
Reference standard:UL810,IEC252,EN60252,GB3667
Certification:UL Construction,UL 10,000AFC,TUV,VDE
Safety grade:P1,P2.

CD60-B MOTOR START CAPAClTORS
Main Feature:
1.Bakelite case
2.Voltages from 110V AC to 330V AC
3.UL Recognized Capacitors
Applicable Scope :
To start and run single phase m0tors in alternating current usage,
And it suit for single phase A.C. motors with frequency of 50/60Hz.
General Specifications:
Operating Temperature:-25~+65°C
Voltage Range:110~330V AC
Capacitance Range:21~1280μf
Capacitance Tolerance:+/-20%
Operate Frequency:50/60Hz
Case Size:8 Standard Size from
1 437"x2.750" ~2 562"x4.375"/36mm x 70mm~65mm x111mm
Termination:1/4 " Quick Disconnect Terminals(Std.)
Performance Specification:Meets Requirements of ElA-463-A
Product Description
CD60 start capacitor is developed and researched according to standard of American
Electronics Association (ANSI/EIA-463).The external case of the capacitor is made of
bakelite plasticized which Character is not only good insulating resistance. strong resistance damaged but also protecting electro liquid as good sealed feature. It is popular
used for the super AC application as good life, higher degree of reliability and stability.


Case size of Standard Products (mm)

Rated Voltage Capacitance Range	110-125V	165V	220-250V	330V
	D X H
21-25	36.5 x69.85	36.5 x69.85	36.5 x69.85	36.5 x69.85
25-30	36.5 x69.85	36.5 x69.85	36.5 x69.85	36.5 x69.85
30-36	36.5 x69.85	36.5 x69.85	36.5 x69.85	36.5 x69.85
43-53	36.5 x69.85	36.5 x69.85	36.5 x69.85	46.02 x85.72
53-64	36.5 x69.85	36.5 x69.85	36.5 x69.85	46.02 x85.72
67-77	36.5 x69.85	36.5 x69.85	36.5 x69.85	46.02 x85.72
88-108	36.5 x69.85	36.5 x69.85	46.02 x85.72	46.02 x85.72
124-149	36.5 x69.85	36.5 x69.85	46.02 x85.72	52.37 x111.12
161-193	36.5 x69.85	36.5 x85.72	52.37 x85.72	52.37 x111.12
200-240	36.5 x69.85	46.02 x85.72	52.37 x85.72	52.37 x111.12

Note:All other types of products in form can be fulfilled at the request of customers.


Case size	1	2	3	4	5	6	7	8
Dimension(D x H)(mm)	36.5 x69.85	36.5 x85.72	36.5 x111.12	46.02 x85.72	46.02 x111.12	52.37 x85.72	52.37 x111.12	65.50 x111.12
Dimension(D x H)(mm)	1.437 x2.750	1.437 x3.365	1.437 x4.365	1.812 x3.365	1.812 x4.365	2.062 x3.365	2.062 x4.365	2.562 x4.365

CBB60 COHERER POLYPROPYLENE CAPAClTORS SERlES
Main Feature:
Low dissipation factor,small inherent temperature rise.excellent self-healing stability,safety and high voltage withstand,etc.
Applications:
Used widely in washing machine,water pump,air conditioner and as well household electric appliances etc. to start and run single phase motors in alternating current usage.

Techinnical Parameters:

Capacitance range	1-150μf
Rated voltage Un	250v.ac/400/450V.ac
Rated frequency	50Hz;60Hz
Capacitance tolerance	±5%;±10%
Climatic category	-25+70°C
Dissipation factor(at 50Hz-Hz and 20°C)	≤0.002(100Hz,20°C)
Test voltage between terminals	2×Un for 3s
Test voltage between terminals and case	2×Un+1000VDC FOR 2s
Reference standard	EN 60252-1:2001;IEC252
