Cdt Series 3 Phase in 1 Phase out Low Frequency UPS for Industry Purpose
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T |
| Prod Model: |
CDT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power Capacity: |
7.5kVA to 50kVA |
| Charateristic1: |
Digitalized Signal Processor |
| Charateristic2: |
Run Self-Diagnose |
| Charateristic3: |
with Standard RS232 for Snmp or RS485 Cards |
| Charateristic4: |
Managed by Central Monitoring and Remote Monitorin |
| Phase: |
Three Phase |
| Type: |
On-line |
Product Description
CDT series are 3 phase in 1 phase out UPS. Their capacity range from 7.5KVA to 50KVA. These series have applied full digital control technology based on DSP (digitalized signal processor). IGBT transformation endures high power current and high voltage with an extremely low consumption. The machine can run self-diagnose, and with standard RS232 for SNMP or RS485 cards, they are conveniently managed by central monitoring and remote monitoring. The latest Redundancy Parallel Array technology is available with these series. RPA function can operate on up 32 units.
Main Features
Applying full digital control technology based on DSP
The shift time between Invertion and bypass is less than 1 millisecond.
AC start (cold start), convenient to operate
Auto re-start function
Complete protection and alarm functions, MCU is monitoring all circuits and detecting bugs during the long run
Extremely wide input voltage range
Self-diagnose function
Isolated output transformer islotated the electricity shock from various loads
Most advanced RPA functions allow up to 32 units of machines to be working in the parallel array
Technical Data Sheet | MODEL | CDT7.5KL | CDT10KL | CDT-15KL | CDT20KL | CDT-30KL | CDT-40KL | CDT-50KL |
| Rated Power | 6KW | 8KW | 12KW | 16KW | 24KW | 32KW | 40KW |
| INPUT |
| Rated Voltage | 3 phases 5 wires 380V±25%(285V-475V) |
| Frequency | 50 Hz/60Hz ±5%(optional ±10%) |
| Power Factor | 11KVA | 15KVA | 22.5KVA | 30KVA | 45KVA | 60KVA | 75KVA |
| OUTPUT |
| Rated Voltage | single phases 220V±1% |
| Frequency | 50/60Hz±0.5% (inverted tense) |
| Phase Precision | ±0.5% |
| Degree of 3-phase Imbalance | Pure since wave,linear loads ≤3%;non-linear loads≤5% (full loading) |
| Distortion Factor | Over load 120% can last 10 minutes, over load 150% can last 20 seconds |
| Overload Capacity | <±5% |
| Wave Crest Coefficient | 5:1(full loading) |
| BATTERY(EXTERNAL EXTRA) |
| Rated Voltage | 384VDC,192VDC |
| Battery Nos. | 12Vdcx32 nos. |
| Battery Voltage | 12 Vdc |
| Back-up Time | Extra battery(standby time is determined by battery capacity) |
| System |
| Transfer Time | AC←→battery 0 ms;Invert←→bypass < 4 ms |
| Ingress Protection | IP20 |
| Conversion Efficiency | ≥85%(full loading) |
| Noise | 53db(1 meter) | 55db(1meter) | 58db(1meter) |
| ENVIRONMENT |
| Temperature | 0ºC~45ºC |
| Humidity | 0~93% RH,non-condensing |
| Altitude | <1500m |
| Size |
| W×D×H(mm) | 300×721×708 | 410*752*941 |
| Weight |
| N. Weight (kg) | 95 | 105 | 127 | 147 | 166 | 210 | 240% |
| G. Weight (kg) | 115 | 125 | 170 | 170 | 220 | 270 | 290% |
