| Prod Model: |
YY YL YC YU Single Series motor |
| Output Range: |
0.09kw-7.5kw |
| Cooling Method: |
IC411 |
| Mounting: |
Foot Mounted, Flange Mounted, Vertical Mounted |
| Insulation Class: |
B, F, H |
| Protection: |
IP44, 54, 55 |
| Number Of Stator: |
Single-Phase |
| Function: |
Driving |
| Brand: |
Hongma or Customized |
| Certification: |
Ce |
| Number Of Poles: |
2-4poles |
Product Description
Performance and Characteristics:
YY(DO2), YC(CO2), YU(BO2), YL Series single-phase asynchronous motors are designed according to national standard and are of good performance, low noise, small size, light weight, easy maintenance. Fearures with Protection Class IP44, IP54 and higher up to IP55, Cooling Method IC411, Rated Voltage 220V, 230V and 240V, Frequency 50HZ or 60HZ, etc. They are widely used in mechanical equipment with single phase power supply.
| YY(DO2) Capacitor run motor technical data |
| Type | Output | Speed | Current (A) | Efficiency | Power factor | Tstart/Tn | Tmax/Tn |
|
| (W) | r/min | (220V) | (230V) | (240V) | η% | Cosφ |
| DO2 | 5612 | 90 | 2800 | 0.8 | 0.8 | 0.7 | 56 | 0.92 | 0.5 | 1.7 |
| DO2 | 5622 | 120 | 2800 | 1.0 | 0.9 | 0.9 | 60 | 0.92 | 0.5 | 1.7 |
| DO2 | 6312 | 180 | 2800 | 1.4 | 1.3 | 1.3 | 65 | 0.92 | 0.4 | 1.7 |
| DO2 | 6322 | 250 | 2800 | 1.9 | 1.8 | 1.7 | 66 | 0.92 | 0.4 | 1.7 |
| DO2 | 7112 | 370 | 2800 | 2.7 | 2.6 | 2.5 | 67 | 0.92 | 0.35 | 1.7 |
| DO2 | 7122 | 550 | 2800 | 3.9 | 3.7 | 3.6 | 70 | 0.92 | 0.35 | 1.7 |
| DO2 | 8012 | 750 | 2800 | 5.1 | 4.9 | 4.7 | 72 | 0.92 | 0.33 | 1.7 |
| DO2 | 8022 | 1100 | 2800 | 7.0 | 6.7 | 6.4 | 75 | 0.95 | 0.33 | 1.7 |
| DO2 | 90S2 | 1500 | 2800 | 9.4 | 9.0 | 8.7 | 76 | 0.95 | 0.3 | 1.7 |
| DO2 | 90L2 | 2200 | 2800 | 13.7 | 13.1 | 12.5 | 77 | 0.95 | 0.3 | 1.7 |
| DO2 | 5614 | 60 | 1400 | 0.6 | 0.6 | 0.6 | 50 | 0.9 | 0.45 | 1.7 |
| DO2 | 5624 | 90 | 1400 | 0.9 | 0.8 | 0.8 | 52 | 0.9 | 0.45 | 1.7 |
| DO2 | 6314 | 120 | 1400 | 1.1 | 1.0 | 1.0 | 57 | 0.9 | 0.4 | 1.7 |
| DO2 | 6324 | 180 | 1400 | 1.5 | 1.5 | 1.4 | 59 | 0.9 | 0.4 | 1.7 |
| DO2 | 7114 | 250 | 1400 | 2.0 | 1.9 | 1.9 | 61 | 0.92 | 0.35 | 1.7 |
| DO2 | 7124 | 370 | 1400 | 2.9 | 2.8 | 2.7 | 62 | 0.92 | 0.35 | 1.7 |
| DO2 | 8014 | 550 | 1400 | 4.2 | 4.1 | 3.9 | 64 | 0.92 | 0.35 | 1.7 |
| DO2 | 8024 | 750 | 1400 | 5.4 | 5.2 | 5.0 | 68 | 0.92 | 0.32 | 1.7 |
| DO2 | 90S4 | 1100 | 1400 | 7.4 | 7.1 | 6.8 | 71 | 0.95 | 0.32 | 1.7 |
| DO2 | 90L4 | 1500 | 1400 | 9.8 | 9.4 | 9.0 | 73 | 0.95 | 0.3 | 1.7 |
| DO2 | 7116 | 120 | 900 | 1.1 | 1.1 | 1.0 | 53 | 0.9 | 0.35 | 1.7 |
| DO2 | 7126 | 180 | 900 | 1.7 | 1.6 | 1.5 | 55 | 0.9 | 0.35 | 1.7 |
| DO2 | 8016 | 250 | 900 | 2.2 | 2.1 | 2.0 | 57 | 0.92 | 0.32 | 1.7 |
| DO2 | 8026 | 370 | 900 | 3.2 | 3.0 | 2.9 | 58 | 0.92 | 0.32 | 1.7 |
| DO2 | 90S6 | 550 | 900 | 4.4 | 4.2 | 4.0 | 62 | 0.92 | 0.32 | 1.7 |
| DO2 | 90L6 | 750 | 900 | 5.7 | 5.5 | 5.2 | 65 | 0.92 | 0.3 | 1.7 |
| YC(CO2) Capacitor start motor technical data |
| Type | Output | Speed | Current(A) | Efficiency | Power factor | Tstart/Tn | Tmax/Tn |
|
| (W) | r/min | (220V) | (230V) | (240V) | η% | Cosφ |
| CO2 | 7112 | 180 | 2800 | 1.9 | 1.8 | 1.7 | 60 | 0.72 | 3 | 1.8 |
| CO2 | 7122 | 250 | 2800 | 2.4 | 2.3 | 2.2 | 64 | 0.74 | 3 | 1.8 |
| CO2 | 8012 | 370 | 2800 | 3.4 | 3.2 | 3.1 | 65 | 0.77 | 2.8 | 1.8 |
| CO2 | 8022 | 550 | 2800 | 4.7 | 4.5 | 4.3 | 68 | 0.79 | 2.8 | 1.8 |
| CO2 | 90S2 | 750 | 2800 | 6.1 | 5.8 | 5.6 | 70 | 0.8 | 2.5 | 1.8 |
| CO2 | 90L2 | 1100 | 2800 | 8.7 | 8.3 | 8.0 | 72 | 0.8 | 2.5 | 1.8 |
| CO2 | 100L1-2 | 1500 | 2800 | 11.4 | 10.9 | 10.4 | 74 | 0.81 | 2.5 | 1.8 |
| CO2 | 100L2-2 | 2200 | 2800 | 16.5 | 15.7 | 15.1 | 75 | 0.81 | 2.2 | 1.8 |
| CO2 | 112M2 | 3000 | 2800 | 21.9 | 20.9 | 20.1 | 76 | 0.82 | 2.2 | 1.8 |
| CO2 | 132S2 | 3700 | 2800 | 26.6 | 25.5 | 24.4 | 77 | 0.82 | 2.2 | 1.8 |
| CO2 | 7114 | 120 | 1400 | 1.9 | 1.8 | 1.7 | 50 | 0.58 | 3 | 1.8 |
| CO2 | 7124 | 180 | 1400 | 2.5 | 2.4 | 2.3 | 53 | 0.62 | 2.8 | 1.8 |
| CO2 | 8014 | 250 | 1400 | 3.1 | 3.0 | 2.9 | 58 | 0.63 | 2.8 | 1.8 |
| CO2 | 8024 | 370 | 1400 | 4.2 | 4.1 | 3.9 | 62 | 0.64 | 2.5 | 1.8 |
| CO2 | 90S4 | 550 | 1400 | 5.5 | 5.3 | 5.0 | 66 | 0.69 | 2.5 | 1.8 |
| CO2 | 90L4 | 750 | 1400 | 6.9 | 6.6 | 6.3 | 68 | 0.73 | 2.5 | 1.8 |
| CO2 | 100L1-4 | 1100 | 1400 | 9.5 | 9.1 | 8.7 | 71 | 0.74 | 2.5 | 1.8 |
| CO2 | 100L2-4 | 1500 | 1400 | 12.5 | 11.9 | 11.4 | 73 | 0.75 | 2.5 | 1.8 |
| CO2 | 112M4 | 2200 | 1400 | 17.8 | 17.0 | 16.3 | 74 | 0.76 | 2.2 | 1.8 |
| CO2 | 132S4 | 3000 | 1400 | 23.6 | 22.6 | 21.6 | 75 | 0.77 | 2.2 | 1.8 |
| CO2 | 132M4 | 3700 | 1400 | 28.0 | 26.8 | 25.7 | 76 | 0.79 | 2.2 | 1.8 |
| CO2 | 90S6 | 250 | 900 | 4.2 | 4.0 | 3.9 | 54 | 0.5 | 2.5 | 1.8 |
| CO2 | 90L6 | 370 | 900 | 5.3 | 5.0 | 4.8 | 58 | 0.55 | 2.5 | 1.8 |
| CO2 | 100L1-6 | 550 | 900 | 6.9 | 6.6 | 6.4 | 60 | 0.6 | 2.5 | 1.8 |
| CO2 | 100L2-6 | 750 | 900 | 9.0 | 8.6 | 8.3 | 61 | 0.62 | 2.2 | 1.8 |
| CO2 | 112M6 | 1100 | 900 | 12.2 | 11.7 | 11.2 | 63 | 0.65 | 2.2 | 1.8 |
| CO2 | 132S6 | 1500 | 900 | 14.7 | 14.1 | 13.5 | 68 | 0.68 | 2 | 1.8 |
| CO2 | 132M6 | 2200 | 900 | 20.4 | 19.5 | 18.7 | 70 | 0.7 | 2 | 1.8 |
| YU(BO2) Resistance start motor technical data |
| Type | Output | Speed | Current(A) | Efficiency | Power factor | Tstart/Tn | Tmax/Tn |
|
| (W) | r/min | (220V) | (230V) | (240V) | η% | Cosφ |
| BO2 | 6312 | 90 | 2800 | 1.09 | 1.04 | 0.10 | 56 | 0.67 | 1.5 | 1.8 |
| BO2 | 6322 | 120 | 2800 | 1.36 | 1.30 | 0.13 | 58 | 0.69 | 1.4 | 1.8 |
| BO2 | 7112 | 180 | 2800 | 1.89 | 1.81 | 0.18 | 60 | 0.72 | 1.3 | 1.8 |
| BO2 | 7122 | 250 | 2800 | 2.40 | 2.30 | 0.23 | 64 | 0.74 | 1.1 | 1.8 |
| BO2 | 8012 | 370 | 2800 | 3.36 | 3.21 | 0.32 | 65 | 0.77 | 1.1 | 1.8 |
| BO2 | 6314 | 60 | 1400 | 1.23 | 1.17 | 0.12 | 39 | 0.57 | 1.7 | 1.8 |
| BO2 | 6324 | 90 | 1400 | 1.47 | 1.41 | 0.14 | 48 | 0.58 | 1.5 | 1.8 |
| BO2 | 7114 | 120 | 1400 | 1.88 | 1.80 | 0.18 | 50 | 0.58 | 1.5 | 1.8 |
| BO2 | 7124 | 180 | 1400 | 2.49 | 2.38 | 0.23 | 53 | 0.62 | 1.4 | 1.8 |
| BO2 | 8014 | 250 | 1400 | 3.11 | 2.97 | 0.29 | 58 | 0.63 | 1.2 | 1.8 |
| BO2 | 8024 | 370 | 1400 | 4.24 | 4.05 | 0.40 | 62 | 0.64 | 1.2 | 1.8 |
| YL Series Single-Phase Dyadic Capacitance Induction Motors |
|
| Technical Data |
| Type | Output | Speed | Current(A) | Efficiency | Power factor | Tstart/Tn | Tmax/Tn |
|
| (W) | r/min | (220V) | (230V) | (240V) | η% | Cosφ |
| YL | 7112 | 0.37 | 2800 | 2.7 | 2.6 | 2.5 | 67 | 0.92 | 1.8 | 1.7 |
| YL | 7122 | 0.55 | 2800 | 3.9 | 3.7 | 3.6 | 70 | 0.92 | 1.8 | 1.7 |
| YL | 7114 | 0.25 | 1400 | 2.0 | 1.9 | 1.8 | 62 | 0.92 | 1.8 | 1.7 |
| YL | 7124 | 0.37 | 1400 | 2.8 | 2.7 | 2.6 | 65 | 0.92 | 1.8 | 1.7 |
| YL | 80M1-2 | 0.75 | 2800 | 5.1 | 4.9 | 4.7 | 72 | 0.92 | 1.8 | 1.7 |
| YL | 80M2-2 | 1.1 | 2800 | 7.0 | 6.7 | 6.4 | 75 | 0.95 | 1.8 | 1.7 |
| YL | 80M1-4 | 0.55 | 1400 | 3.9 | 3.8 | 3.6 | 69 | 0.92 | 1.7 | 1.7 |
| YL | 80M2-4 | 0.75 | 1400 | 5.1 | 4.8 | 4.6 | 71 | 0.95 | 1.7 | 1.7 |
| YL | 90S-2 | 1.5 | 2800 | 9.2 | 8.8 | 8.4 | 76 | 0.98 | 1.8 | 1.7 |
| YL | 90L-2 | 2.2 | 2800 | 13.3 | 12.7 | 12.1 | 77 | 0.98 | 1.7 | 1.7 |
| YL | 90S-4 | 1.1 | 1400 | 7.2 | 6.9 | 6.6 | 73 | 0.95 | 1.7 | 1.7 |
| YL | 90L-4 | 1.5 | 1400 | 9.6 | 9.2 | 8.8 | 75 | 0.95 | 1.7 | 1.7 |
| YL | 100L-2 | 3 | 2800 | 18.2 | 17.4 | 16.7 | 79 | 0.95 | 1.7 | 1.7 |
| YL | 100L1-4 | 2.2 | 1400 | 13.9 | 13.2 | 12.7 | 76 | 0.95 | 1.7 | 1.7 |
| YL | 100L2-4 | 3 | 1400 | 18.6 | 17.8 | 17.1 | 77 | 0.95 | 1.7 | 1.7 |
| YL | 112M-2 | 3.7 | 2800 | 22.1 | 21.2 | 20.3 | 80 | 0.95 | 1.7 | 1.7 |
| YL | 112M-4 | 3.7 | 1400 | 22.4 | 21.4 | 20.5 | 79 | 0.95 | 1.7 | 1.7 |
| YL | 132S-2 | 5.5 | 2800 | 32.5 | 31.1 | 29.8 | 81 | 0.95 | 1.7 | 1.7 |
| YL | 132S-4 | 5.5 | 1400 | 32.9 | 31.5 | 30.2 | 80 | 0.95 | 1.7 | 1.7 |
If you need single phase motor customized, you could also contact us as below, we could discuss more details.
