Ce RoHS Approved 3A 15V DC Output DIN Rail Switched Power Supply

Name: Ce RoHS Approved 3A 15V DC Output DIN Rail Switched Power Supply
Brand: all-electronics-online.com
SKU: 832314825
Availability: InStock
Rating: 4.5 (138 reviews)

Price:	US $ 7-8/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	DR-45-15
Type:	Constant Voltage
Material:	Plastic Case
Weight:	0.27kg
MOQ:	1-5PCS Sample Order
Shipping:	Sea Air DHL FedEx EMS UPS TNT
Test:	100% Full Load Burn-in Test
Voltage:	15V
Current:	3A
Output Type:	Single
Warranty:	2 Years
Output Power:	1 - 50W
Input Voltage:	110-220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Separate-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	ISO
Brand:	Weho

Product Description

CE RoHS approved 3a 15v dc output din rail switched power supply

Features:

1. AC input range selectable by switch

2. Protections: Short circuit / Overload / Over voltage / Over temperature

3. 100% full load burn-in test

4. Low cost, high reliability

5. 24 months warranty

Model Specification	DR-45-5	DR-45-12	DR-45-15	DR-45-24
DC output voltage	5V	12V	15V	24V
Rated output current	5A	3.5A	2.8A	2A
Output current range	0-5A	0-3.5A	0-2.8A	0-2A
Wave and noise	100mVp-p	200mVp-p	240mVp-p	480mVp-p
Inlet stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±0.5%	±0.5%	±0.5%
Efficiency	72%	77%	77%	80%
AC input voltage range	85~264VAC/47~63HZ;120~370VDC
AC impulse current	Cold-start current 28A/115V 56A/230V
Overload protection	105%150% Typecurrent limiting .Reset: auto recovery
Setup rise hold up time	800ms,60ms,50ms/230VAC
Withstand voltage	Input and output interval3KVAC,Input and enclosure1.5KVAC, Output and enclosure0.5KVAC
Isolation resistance	Input and output interval,Input and enclosure, Output and enclosure500VAC/100M Ohms
Working temperature and humidity	-10°c+50°c
Overall dimension	789356mm
Weight	0.31Kgs
Safety standards	Meet GB4943 UL60950
EMC standards	Meet GB9254 UL55022 Class B

With 10 years OEM experience, we can provide professional solutions for customers. Send your Inquiry Details Now!!!

Zhejiang Weihao electronic Co., Ltd is located in "Chinese Electrical Capital"-Liushi Town, it is a high-tech enterprise, specializing in research, development and production of AC/DC DC/DC series switching power supply, adapter and AC stabilizer, frequency inverter, etc.

Our products are widely used in LED system, postal service, comunication system, power system, instrument and meter equipements, semiconductor refrigeration and heating system, medical equipments, monitorand automatic control system and railway system. etc. Our design is on basis of UL1012 TUVE60950, EMC LVD. VL1950, IEC950 and so on. The first-class imported components, advanced workmanshipand the consummation instruments achieved high quality products. All of them have past 100% high-temperature and full-load testing, the qualified rate can come to 99% and 3% repair rate.

We sticks to the principle of "Quality first Technology Advanced and providing ssatisfactory product and service " we also draw high attentionto demand of customers and provide high quality products.

The products are sold to oversesas market like America, Austrilia, Europe and MID-east etc.

Warmly welcome both of domestic and overseas customers to visit, negotiate and cooperate with us
