Ce RoHS DIN Rail 120W 8A 15 Volt LED Power Supply

Name: Ce RoHS DIN Rail 120W 8A 15 Volt LED Power Supply
Brand: all-electronics-online.com
SKU: 832318125
Availability: InStock
Rating: 4.3 (115 reviews)

Price:	US $ 13-14.5/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	DR-120-15
Type:	Constant Voltage
Material:	Aluminum Case
Weight:	0.8kg
MOQ:	1-5PCS Sample Order
Shipping:	Sea Air DHL FedEx EMS UPS TNT
Test:	100% Full Load Burn-in Test
Voltage:	15V
Current:	8A
Output Type:	Single
Warranty:	2 Years
Output Power:	101 - 200W
Input Voltage:	110-220V
Connection Mode:	Series Switching Power Supply
Starting Mode:	Separate-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	ISO
Brand:	Weho

Product Description

CE RoHS din rail 120w 8a 15 volt led power supply

Features:

1. AC input range selectable by switch

2. Protections: Short circuit / Overload / Over voltage / Over temperature

3. 100% full load burn-in test

4. Low cost, high reliability

5. 24 months warranty

Model	DR-120-12	DR-120-15	DR-120-24	DR-120-48
DC output voltage	12V	15V	24V	48V
Output voltage range	±2%	±2%	±1%	±1%
Rated output current	10A	8A	5A	2.5A
Output current range	0-10A	0-8A	0-5A	0-2.5A
Wave and noise	85mVp-p	85mVp-p	85mVp-p	100mVp-p
Inlet stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±1%	±1%	±1%
DC output power	120W	120W	120W	120W
Efficiency	80%	81%	84%	85%
Adjustable range for DC voltage	10.8~13.2V	13.5~16.5V	21.6~26.4V%	43.2~52.8V%
AC input voltage range	88~132VAC 47~63Hz;240~370VDC
Input current	3.3A/115V 2A/230V
AC inrush current	Cold-start current 30A/115V 60A/230V
Leakage current	<3.5mA/240VAC
Overload protection	105%~150% Type: pulsing hiccup shutdown Reset: tuto recovery
Over-voltage protection	13.8~16.2V	18~21V	27.6~32.4V	58~62V
Temperature coefficient	±0.03%/°c(0~50°c)
Setup, rise , hold up time	500ms,70ms, 50ms/230V
Vibration	10~500Hz, 2G 10min,/1cycle, Period for 60min, Each axes
Withstand voltage	Input and output internal: Input and encolsur: 1.5KvAC, Output and enclosure: 0.5KvAC
Isolation resistance	Input and output internal: Input and enclosure, Output and enclosure:500VDC/100MΩ
Working temperature and humidity	10°c~50°c(Refer to output derating curve), 20%~90%RH
Overall dimension	65.5×125.2×100mm
Weight	0.8Kgs 24PCS/19.2Kg/1.1CUFT
Safety standards	Meet UL 1012 requiement (Not apply for the mark)
EMC standards	Meet FCC PART 15 J Conduction class B

With 10 years OEM experience, we can provide professional solutions for customers. Send your Inquiry Details Now!!!

Zhejiang Weihao electronic Co., Ltd is located in "Chinese Electrical Capital"-Liushi Town, it is a high-tech enterprise, specializing in research, development and production of AC/DC DC/DC series switching power supply, adapter and AC stabilizer, frequency inverter, etc.

Our products are widely used in LED system, postal service, comunication system, power system, instrument and meter equipements, semiconductor refrigeration and heating system, medical equipments, monitorand automatic control system and railway system. etc. Our design is on basis of UL1012 TUVE60950, EMC LVD. VL1950, IEC950 and so on. The first-class imported components, advanced workmanshipand the consummation instruments achieved high quality products. All of them have past 100% high-temperature and full-load testing, the qualified rate can come to 99% and 3% repair rate.

We sticks to the principle of "Quality first Technology Advanced and providing ssatisfactory product and service " we also draw high attentionto demand of customers and provide high quality products.

The products are sold to oversesas market like America, Austrilia, Europe and MID-east etc.

Warmly welcome both of domestic and overseas customers to visit, negotiate and cooperate with us
