Cg12-200 Deep Cycle 12V 200ah Gel Battery for Solar Storage
| Price: |
US $ 160-200/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
CG12-200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Cg12-200 12V 200ah Deep Cycle Gel Battery |
| Size: |
522*240*218mm |
| Weight: |
56kg |
| Warranty: |
3 Years |
| Delivery Days: |
10-15 Days |
| Color: |
Black, Dark Gray |
| Capacity: |
200ah |
| Brand: |
Cspower/OEM |
| Certificate: |
Ce, Iecce, UL, Tlc, ISO9001, ISO14001, Ohsas1 |
| Lifespan: |
15-20 Years |
| Type: |
Lead-Acid Batteries |
| Usage: |
Wind and Solar System |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
| Electrolyte: |
Gel Acid |
Product Description
SPECIFICATION
Nominal Voltage---------------------------------------------------------------------------------------------------------12Volt(6cell)
Nominal Capacity
10HR,10.8V,25ºC(77ºF)----------------------------------------------------------------------------------------200Ah/20.0A
5HR,10.5V,25ºC(77ºF)------------------------------------------------------------------------------------------176Ah/35.2A
1HR,9.6V,25ºC(77ºF)---------------------------------------------------------------------------------------------124Ah/124A
Dismensions
Length------------------------------------------------------------------------------------------------------522+2mm(20.57inch)
Width---------------------------------------------------------------------------------------------------------240+2mm(9.45inch)
Container Heigh--------------------------------------------------------------------------------------------216+2mm(8.50inch)
Total Height(with Terminal)-----------------------------------------------------------------------------240+2mm(9.45inch)
Internal Resistance(approx.)---------------------------------------------------------------------------------------------40 mOhm
Max Discharge Current(5S)------------------------------------------------------------------------------------------------------75.0A
Operating Temperature Range
Charge-----------------------------------------------------------------------------------------------10ºC(14ºF)To60ºC(140ºF)
Discharge--------------------------------------------------------------------------------------------20ºC(-4ºF)To60ºC(140ºF)
Storage-----------------------------------------------------------------------------------------------20ºC(-4ºF)To60ºC(140ºF)
Case---------------------------------------------------------------------------------------------------------------------------------------ABS
Terminal Typ ---------------------------------------------------------------------------------------------------------------------------T11
CG12-200 12V200Ah VRLA GEL Battery Applicition
1. Solar & Wind power systems accumulator
2. Fire & security systems
3. Uninterruptible power supplies
4. Golf cart, Electric vehicle
5. Electric powered bicycle and wheelchairs
6. Marine equipment
7. Communication equipment
8. Power tools
9. Telecommunication systems
CG12-200 12V200Ah VRLA GEL Battery Advanced Features 1. Environmentally friendly
2. Completely Maintenance-Free
3. Non-Spillable construction design.
4. Wide Operating Temperature Range(-20°C~+60°C)
5. Longer Life(20years designed life) With GEL
6. Explosion Proof
7. Valve Regulated & High Discharge Rate Capability
8. Low Self Discharge
9. Independent of Position
10. Ease of Shipment
11. No need of balanced charge or boost
12. No Memory
CSPOWER SUPPLY CG GEL Battery Series
1. Sealed free maintenance deep cycle GEL AGM battery upto 12V200Ah, 250Ah, 300Ah
2. OEM/ODM free charge
3. Warranty 3years free replacement
CSPOWER Solar GEL Battery series Detailed Product Description
1. Gel solar battery accumulator shows some distinctive advantages over flooded battery or AGM battery.
2. Such as super thermal stability, high deep discharge capability, good recovery from deep discharge, even if
the battery is left discharged for three days, it will recover to 100% of capacity.
3. The gel battery has long service life, specially suitable for motive power applications, such as golf
trailer,sruubber, folklift, etc.
4. The deep discharge cycles increased 50% as compared with the AGM battery.
never leakage and volatile acid, longer life.| Model NO. | Nominal
Voltage | Rated Capacity
(AH) | Approx. Weight | Dimensions(mm) | Terminal Type |
| ------------------- | (V) | 20hrs/25 | kg | lbs | Length | Width | Height | Total Height | |
| mm | inch | mm | inch | mm | inch | mm | inch |
| CG12-33 | 12 | 33 | 10.4 | 22.9 | 196 | 7.70 | 131 | 5.16 | 155 | 6.10 | 170 | 6.69 | T9/T16 |
| CG12-38 | 12 | 38 | 12.2 | 26.84 | 197 | 7.73 | 166 | 6.54 | 174 | 6.85 | 181 | 7.13 | T12 |
| CG12-50 | 12 | 50 | 16.2 | 35.6 | 230 | 9.06 | 138 | 5.43 | 211 | 8.30 | 229 | 9.01 | T9/T16 |
| CG12-55 | 12 | 55 | 16.2 | 35.6 | 230 | 9.06 | 138 | 5.43 | 211 | 8.30 | 229 | 9.01 | T9/T16 |
| CG12-65 | 12 | 65 | 20,5 | 45.1 | 350 | 13.8 | 166 | 6.54 | 179 | 7.05 | 179 | 7.05 | T9 |
| CG12-70 | 12 | 70 | 22.0 | 48.4 | 260 | 10.2 | 169 | 6.65 | 211 | 8.30 | 215 | 8.46 | T16 |
| CG12-80 | 12 | 80 | 23.4 | 51.5 | 260 | 10.2 | 169 | 6.65 | 211 | 8.3 | 229 | 9.02 | T14 |
| CG12-85 | 12 | 85 | 29 | 64.10 | 307 | 12.08 | 169 | 6.65 | 211 | 8.3 | 234 | 9.21 | T16A/T8 |
| CG12-100 | 12 | 100 | 30 | 66 | 331 | 13.0 | 173 | 6.81 | 213 | 8.39 | 233 | 9.17 | T10 |
| CG12-120 | 12 | 120 | 36.5 | 80.3 | 407 | 16.0 | 174 | 6.85 | 209 | 8.23 | 233 | 9.17 | T11 |
| CG12-134 | 12 | 134 | 41 | 90.2 | 341 | 13.43 | 173 | 6.81 | 283 | 11.14 | 283 | 11.14 | T9/T20 |
| CG12-150 | 12 | 150 | 42.5 | 93.5 | 484 | 19.1 | 171 | 6.73 | 241 | 9.49 | 241 | 9.49 | T11 |
| CG12-180 | 12 | 180 | 56.5 | 124 | 530 | 20.9 | 209 | 8.23 | 214 | 8.43 | 240 | 9.45 | T9 |
| CG12-200 | 12 | 200 | 60 | 132 | 522 | 20.57 | 240 | 9.45 | 216 | 8.50 | 240 | 9.45 | T11 |
| CG12-230 | 12 | 230 | 64 | 140.8 | 522 | 20.6 | 240 | 9.45 | 216 | 8.50 | 240 | 9.45 | T9 |
| CG12-250 | 12 | 250 | 68 | 150 | 520 | 20.5 | 268 | 10.55 | 220 | 8.66 | 243 | 9.57 | T11 |
| CG2-100 | 2 | 100 | 6.4 | 14.11 | 171 | 6.73 | 72 | 2.83 | 206 | 8.11 | 227 | 8.94 | T16 |
| CG2-150 | 2 | 150 | 9.0 | 19.8 | 172 | 6.77 | 102 | 4.02 | 207 | 8.15 | 227 | 8.94 | T6 |
| CG2-200 | 2 | 200 | 14 | 30.9 | 172 | 6.77 | 111 | 4.37 | 329 | 13.0 | 356 | 14.0 | T20 |
| CG2-300 | 2 | 300 | 20.5 | 45.2 | 171 | 6.70 | 151 | 5.94 | 330 | 13.0 | 366 | 14.4 | T20 |
| CG2-400 | 2 | 400 | 27.5 | 60.6 | 210 | 8.27 | 176 | 6.93 | 329 | 13.0 | 366 | 14.4 | T20 |
| CG2-500 | 2 | 500 | 33.5 | 73.9 | 241 | 9.5 | 172 | 6.8 | 331 | 13.0 | 366 | 14.4 | T20 |
| CG2-600 | 2 | 600 | 41 | 90.4 | 301 | 11.9 | 175 | 6.89 | 331 | 13.0 | 366 | 14.4 | T20 |
| CG2-800 | 2 | 800 | 55 | 121.3 | 411 | 16.1 | 175 | 6.89 | 330 | 13 | 356 | 14 | T20 |
| CG2-1000 | 2 | 1000 | 66.5 | 146.6 | 475 | 18.7 | 175 | 6.89 | 330 | 12.99 | 356 | 14.02 | T20 |
| CG2-1500 | 2 | 1500 | 103.5 | 228.2 | 401 | 15.8 | 351 | 13.8 | 342 | 13.5 | 369 | 14.5 | T20 |
| CG2-2000 | 2 | 2000 | 136 | 299.8 | 491 | 19.3 | 351 | 13.8 | 343 | 13.5 | 369 | 14.5 | T20 |
| CG2-3000 | 2 | 3000 | 195 | 429 | 710 | 28.0 | 352 | 13.9 | 342 | 13.5 | 369 | 14.5 | T20 |
Shenzhen CSPOWER Battery Tech Co.,Ltd.
1. We are manufacturer of sealed lead acid battery and GEL battery in China since 2003.
2. As a UL, CE, ISO9001, ISO14001 company, we believe that our battery quality can definitely satisfy you.
3. We focus on quality, never use faulse gel and recycle lead.
4. All production lines in our factory are automatic and imported from Germany, and produce lead plates by ourselves in order to control quality and lowest save cost in order to give best competitive price for customers.
CSPOWER batteries are classified into two categories:
Valve-Regulated Lead Acid Battery and GEL Battery. The VRLA battery includes UPS inverter AGM battery, Solar Deep Cycle battery, Car battery, Motorcycle battery, Telecom Front terminal battery;
The GEL Battery is Solar Gel electrolyte battery and OPzV Battery, longer life span 15-25years mainly for solar and wind power system.
OUR BATTERY MATERIAL ADVANTAGES:
1. Container/Cover: Made of UL94HB and UL 94-0ABS Plastic, fire resistance and water proof.
2. 99.99% pure new lead NEVER use recycle lead.
3. Negative Plates: Use the special PbCa alloy grids, optimize the recombination efficiency and less gassing.
4. High quality AGM separator
5. Positive plates: PbCa grids minimize corrosion and prolong life.
6. Terminal post: Copper or lead material with maximum conductivity, enhance the high current rapidly.
7. Vent Valve: Allows the release of the excess gas automatically for safety.
8. Three steps of Seal procedures: Ensure battery completely sealed with safety,
Battery FAQ1. What's kinds of battery will you provide?
We have three type battery: AGM, Deep cycle and Gel.There are many different model battery here, we can supply 2v 100ah-3000ah battery, 4v 0.25Ah-4v 4.5Ah battery, 6v 1.3Ah-6v 12Ah battery, 12v 0.8Ah-12v 250Ah battery.
2. Your battery can meet CE RoHS requirements?
Our battery are with the certificate of CE/RoHS.
3. Can we change the color based on the original?
Yes, the color can be customer-made according to your requirement.
4. Can you print my picture or logo on the battery cover?
Yes, OEM is available,we can print your picture or logo on the battery case, and you can offer your logo.
5. What kind of guarantee you give?
Our battery products can be used for more than 3 years. For AGM battery our warranty time is 1year and GEL battery warranty time is 3years.If it has quality problem during the warranty time we will change new battery for you.
Welcome to contact us for the battery details.
Attn: Mr.Leo (Sales manager)
Mobile +86-13798341910
-----------------------------------------------------------------------------
Shenzhen CSPOWER Battery Tech Co.,Ltd.
(GEL/AGM Battery, Inverter, Solar Energy Provider)
Add: Floor 3, Building B, Huafeng technology park, Baoan, Shenzhen, China
Web: www.csagmbattery.com
Tel: 86-755-29123661
Visit our factory viedo: http://cspower.en.made-in-china.com/
CSPOWER BATTERY TECH Co., Ltd is a professional manufacturer and exporter of environmental friendly Rechargeable Deep Cycle AGM Sealed Lead Acid (SLA) Batteries, Solar GEL Batteries, Front Terminal Battery, High Temperature long life GEL battery, OPzV Battery, Car/Auto Batteries, Telecom Batteries, Lithium batteries and other Solar related products such as Solar inverter, Solar charger controller, Solar panel and so on.
Incorporated in 2003, CSPOWER has steadily expanded to approximately 1000 employees which include an experienced management team supported by a team of highly committed technical and manufacturing workers.
Located in a world-class, modern industrial park of 50, 000 square meters in Guangdong, China, CSPOWER's top of line facilities produce an annual capacity of approximately 2, 000, 000kVAh.
CSPOWER batteries are classified into two categories: Valve-Regulated Lead Acid Battery and GEL Battery. The VRLA battery includes UPS inverter AGM battery, Solar Deep Cycle battery, Telecom Front terminal battery, Car battery; The GEL Battery includes Solar Gel electrolyte battery, High temperature long life Gel battery, OPzV Tubular Gel battery, longer life span 15-25years mainly for solar and wind power system.
With the continuous innovation and pursuit of perfection, CSPOWER has own professional Quality Management System since established. We have successfully got the certificates of ISO9001 quality management system, ISO14001 environment management system, and passed the audit of OHSAS 18001. Also, we have received various product quality recognitions, like UK's IEC, Germany VDS Norm certificates, CE authentication of the European Union, UL recognition of the USA, and TLC certificates in China.
In domestic market, our main customers include China Mobile Limited & Unicom Limited, ZTE Corporation, Delta Electronics Inc, Huawei Technologies, APC, Eaton and so on. And for overseas market, we have exported to over hundreds of countries such as: USA, Brazil, Italy, Greece, Germany, Spain, Russia, Iran, Korea, Thailand, South Africa, Nigeria, etc.
CSPOWER is competent at ODM and OEM orders according to customers realtime request.
Please come to us for your quality battery and solar partner in China today.
