Prod Model: |
303F 303G |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Easy To Install: |
Internal GPS&GSM Antenna |
Warranty: |
12 Months |
Request For OBD Data By SMS: |
Yes |
Support: |
Engine Cut off /Resume |
GPS Tracking: |
GSM Lbs(Location Based Service) |
Tracking Map: |
Google Map |
Alarms: |
Low Battery, Sos, Genfence, Fuel |
Vehicle GPS Tracker: |
Vehicle OBD II Tracker (9-40V) |
OEM/ODM: |
Yes |
Type: |
GPS Tracker |
Use: |
Automotive |
Port Number: |
Multiplex Multi-purpose Channel |
Chip: |
SiRF |
Certification: |
ISO/TS16949 |
Operating Principle: |
by GSM/GPRS |
Model: |
Tk303f |
Screen Size: |
No Screen |
Carrier Frequency: |
850/900/1800/1900MHz |
Brand: |
Coban |
Product Description
GPS tracker tk103
Main Function Description
1. Show location directly on mobile phone with HTTP Google map link
2. Get physical location in real street/address name
3. Remote Engine-stop and Resume.
4. Track by Distance Interval &time
5. USB configuration (option)
6. SD card for data logging (option)
7. ACC working alarm
8. Voice surveillance
9. Multi-Geo fence
10. Less GPRS traffic
11. Automatic update positions of vehicle turns
12. Arm alarm: Door Alarm, ACC Alarm, shock sensor alarm
13. Movement alert.
14. Over speed alarm
15. Power supply disconnection alarm.
16. Low battery alarm function
17. Check the vehicle status
18. Easy switch for track or monitor and switch for SMS tracking and GPRS tracking
Applying directions:
Vehicle fleet/logistics/Vehicle rental
Specifications:
Content | Specifications |
DIM. | 54*62*26mm |
Weight | 120g |
Network | GSM/GPRS |
Band | 850/900/1800/1900MHz |
GSM/GPRS Module | Simcom300d or Simcom340d |
GPS Chip | SIRF3 chip |
GPS Sensitivity | -159dBm |
GPS Accuracy | 5m |
GPS Start time | Cold status 45s |
Warm status 35s |
Hot status 1s |
Voltage of car power system | 12 V -24V |
|
Backup battery | Chargeable changeable 3.7V 800mAh Li-ion battery |
Storage Temp. | -40°C to +85°C |
Operation Temp. | -20°C to +65°C |
Humidity | 5%--95% non-condensing |
Functions | Tracking; Monitor; Geo-fence; Movement alert; Overspeed alert; SOS Button; Low battery alert; Hidden number tracking; Power off alarm; Send SMS cut off/resume the oil and power system, arm, door alarm, sensor alarm, ACC alarm; Supoort 4G SD card; Support TCP and UDP protocol |
Warranty | 12 months Warranty |
Packing contents:
Car GPS Unit tk103
10 PIN harness
Relay for stopping engine
External GSM antenna
External GPS antenna
External microphone
Manual package
SMS/GPRS tracking ways:
- SMS tracking by calling, return google map link
- Absolute street address by SMS
- Free PC based tracking application
- Optional web server www. Gpstrackerxy. COM
