China F Type Female PCB Mount Connectors Suitable for PCB
| Price: |
US $ 0.08-0.1/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
| Prod Model: |
F Type PCB Mount Connector |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Gender: |
Female |
| Style: |
F |
| Material: |
Brass |
| Certification: |
CE,FCC,RoHS |
| OEM: |
Welcome |
| Type: |
PCB Coaxial Connector |
| Coupling Mechanism: |
Threaded Connection |
| Brand: |
Daytai |
| Classification: |
F Type PCB Mount Connector |
Product Description
F Type PCB Mount Connector Suitable for PCB
A. PCB Mount Connector Suitable Specification
F female PCB Mount connector, The pin size: We Can be designed according to the requirements of different customers.
B. F Type PCB Mount Connector Features:
1. This F Type PCB Mount Connector is four feet female seat.
2. This F Type PCB Mount Connector appearance is L type.
3. This F Type PCB Mount Connector applies to CATV, CCTV equipment(signal distributor, branch, amplifier, satellite TV power splitters, switches, high-frequency connection) etc.
C. Business Scope: ( F Type PCB Mount Connector)
We deal with all connector: TV connector, TV jack connector, antenna connector, coaxial connector, F connector, RF connector, CATV connector, BNC connector, catv f connector, QR320 connector, qr412 connector, qr500 connector, qr540 connector, qr750 connector...Etc. All production are cheaper than other company. Meanwhile, our pruduction are high-qualty. There are so many choice in our company.
D. Technical Characteristics of F Type PCB Mount Connector
|
Impedance |
75Ω |
|
Frequency Range |
DC-1GHz |
|
Vibration |
100m/s2(10~500Hz),10g |
|
Withstanding Voltage |
500V r.m.s at sea level |
|
Temperature Range |
-40 to +60°C |
|
Working Voltage |
170V r.m.s at sea level |
|
Insulation Resistance |
≥ 1000 MΩ |
|
Durability |
≥ 500(cycles) |
|
Contact resistance |
Center Contact ≤ 6mΩ
Outer Contact ≤ 1mΩ |
|
Voltage Standing Wave Ratio |
Straight ≤ 1.20
Right angle ≤ 1.30 |
