| Prod Model: |
TK104 |
| Warranty Time: |
1 Year |
| Certificate: |
Ce FCC |
| Features: |
Internal Antenna, Waterproof, Magnetic |
| Delivery Time: |
1-3 Working Days |
| Quad Band: |
850/900/1800/1900 MHz |
| Network: |
GSM GPRS |
| Person Vehicle Security: |
Sos, Real Time Tracking, Geo Fence Alarms etc |
| OEM: |
Support |
| GPS Accuracy: |
5m |
| Power: |
12V-24V |
| Type: |
GPS Tracker |
| Use: |
Automotive&Hand Held |
| Carrier Frequency: |
Dual-Frequency |
| Screen Size: |
No Screen |
| Operating Principle: |
GPS Satellite Positioning and Data Transmit by GSM |
| Port Number: |
20 |
| Model: |
GPS102 Tracker |
| Brand: |
Coban |
| Chip: |
No |
| Certification: |
ISO9001 |
Product Description
China free Tracking Platform GSM/GPRS/GPS Car GPS Tracker Tk104
A)Built-in GSM/GPRS antennas
B)Built-in Microphone
C)Powerful magnet+waterproof
D)GPS+LBS double tracking solution
E)Absolute street address
F)Tracking By SMS or computer
G)Real-time online tracker
GPS Tracker 104 Features:
1. Small size GPS tracker, easy to take to everywhere
2. Powerful magnet+water proof, easy to adsorb in the hidden place of car.
3. Real-time tracking, retrieve of lost vehicles, cargo.
4. Tracking by SMS as well as with internet or PC
5. Protect children, old people or pets by remote control
6. Auto tack and can get location in real street/address name
7. Full battery can standby 80 hours and only need charge about 3-5 hours a time
8. Support both GPS / GSM station positioning ways.
9. Support SMS / GPRS dual-mode switching
10. with its compact and small size, (cigarette box size), easy hide and installation inside the vehicle.
GPS Tracker 104 Basic functions:
1. GPS + LBS double solution,exact street address
2. Auto track continuously
- Track with limited times upon time interval
- Track with unlimited times upon time interval
- smart track upon time and distance interval
3.Turning points update automatically
4.GPS drift suppression
5.Data logging or load
6.Alarms
7.Sleep Mode
8. Real time tracking via SMS or GPRS (TCP/UDP)
9.Track on demand by calling or sms comamnd
10. Live http google map link in message
11.Five authorized phone numbers
12. Voice Surveillance
13.Easy switch for track or Monitor
GPS Tracker 104 New Functions:
14.ACC work and alarm
15.Cut off the Oil and Power,Engine stop and resume
16.INT/EXT GSM/GPS antenna switch
18.Magnet battery
Specification:
| Content | Specs. |
| Dim. | 94mm*60mm*38mm |
| Weight | 300g |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS chip | SIRF3 chip |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5m |
| Time To First Fix | Cold status 45s
Warm status 35s
Hot status 1s |
| Car charger | 12- 24V input
5V output |
| Wall charger | 110--220V input
5V output |
| Battery | Chargeable changeable 3.7V 800mAh Li-ion battery |
| Standby | 80hours |
| Storage Temp. | -40° C to +85° C |
| Operation Temp. | -20° C to +55° C |
| Humidity | 5%--95% non-condensing |
Application: Live real-time GPS tracking for all mobile vehicle.
Warranty:
1. All products have been strictly Quality Checked in house before packing.
2. All products have been well packed before shipping.
3. One year warranty is provided for all models.
4.We will bear maintenance cost during warranty.
