| Maximum Temperature: |
1500deg.C |
| Main Material: |
Silicon Carbide |
Product Description
China High Quality Sic Rod Heater Embedded in the High Temperature Furnace
Main features:
1. SiC heating element is a kind of non-metal high temperature electric silicon carbide heating elements, made of selected super quality green silicon carbide as main materials.
2. Silicon carbide heating elements for element temperatures up to more than 1700 C, available in a wide variety of standard sizes and geometries, or in customized designs to meet the specific needs of various processes and equipment as furnace sic heater.
3. SiC heating elements are capable of high power output, and may be mounted either vertically or horizontally. Because the element material remains rigid even at the maximum operating temperatures, no special supports are required, which simplifies the design of the equipment.
4. Feature of SiC heating elements: Anti-oxidization, anti-corrosion, long service life, little deformation, easy installation and maintance.
5. Silicon carbide heating elements can be used in the furnace temperature 600C-1600C, directly in the air use as well, and it need not any protective atmosphere. Because of SiC heating elements well performance, they are widely used in high temperature furnace, ceramics, glass, analysis and test, semiconductor, science research etc.
6. Types of SiC heating elements: Rod\ U-shape\ W-shape\ single spiral\ double spiral\ Slot
7. Specidications:
| Diameter (mm) | 14 | 16 | 20 | 25 | 30 | 35 | 40 |
| Length of heating (mm) | 400 | 400 | 500 | 700 | 1500 | 1500 | 2400 |
| Length of cold (mm) | 300 | 300 | 400 | 450 | 650 | 650 | 850 |
Specail size is also provided as per customer size and requirement of SiC silicon carbide heating elements.
Packaging & Shipping
1) Packing: from the inside to outer packaging, is foam sponge, carton, wooden case.
2) Transport modes: Sea or Air transportation, TNT, DHL express or FedEx.
3) Please make sure the 'shipping address' is your confirmed address.
4) We do check everything in good condition before we ship your parcel out.
5) We will process your order ASAP after payment is confirmed.
