| Item: |
China Mobile Charger PCB Factory |
| Color: |
Black |
| Size: |
Custom |
| Min.Hole Size: |
0.1mm |
| Min.Line Spacing: |
3 Mil |
| PCBA QC: |
X-ray, Aoi Test, Function Test(100% Test) |
| Specialised: |
LED, Medical, Industrial, Control Board |
| Delivery: |
PCB, 7-10 Days;PCBA, 2-3weeks |
| MOQ: |
10PCS |
| Service: |
Turn Key Assembly, Ageing, Function Test |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
China mobile charger pcb factory
Application
Shenzhen SHTL Tech Co.,Ltd (HK SHTL Co.,Ltd), an electronics manufacturing service provider and printed circuit board manufacturer, offers custom-designed electronics manufacturing and mid-sized OEMs and ODMs.A wide range of end markets that include PCBAs for Automotive, Communications, Computing, Consumer, Industrial,and Healthcare All these PCBAs are being exported to foreign markets, mainly to eastern europe market. SHTL is dedicated to being a long-term PCBAs partner with our customers to achieve quality and cost optimization.
A professional PCB& PCBA design, product, sale manufacturer, established in 2010. Specially dedicate to Security, Industrial Automation, Medical, Household Appliance PCBA and Electrics products finished assembly. Currently with 100 workforce and covering 2, 000 square meters area, our products exported worldwide including North American, & South American, European Countries and Asia, etc.
PCB Technical standard:
| PCB Item | Manufacture Capacity |
| Layer Counts | 1--20L |
| Base Material | FR4,High-TG FR4,CEM3,aluminum,High Frequency(Rogers,Taconic,Aron,PTFE,F4B) |
| Material Thickness(mm) | 0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2 |
| Max board size(mm) | 1200x400mm |
| Board Outline Tolerance | ±0.15mm |
| Board Thickness | 0.4mm--3.2mm |
| Thickness Tolerance | ±8% |
| Minimum line/space | 0.1mm |
| Min Annular Ring | 0.1mm |
| SMD Pitch | 0.3mm |
| Holes | |
| Min Hole Size(mechanical) | 0.2mm |
| Min Hole Size(laser hole) | 0.1mm |
| Hole Size Tol (+/-) | PTH:±0.075mm;NPTH: ±0.05mm |
| Hole Position Tol | ±0.075mm |
| Plating | |
| HASL/LF HAL | 2.5um |
| Immersion Gold | Nickel 3-7um Au:1-5u'' |
| Surface Finish | HAL,lead-free HAL,ENIG,Plated Gold,Immersion Gold,OSP |
| Copper | |
| Copper Weight | 0.5--6oz |
| Color | |
| Soldermask | Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue |
| Silkscreen | White, Black, Blue,Yellow |
| Acceptable File Format | Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000 |
| Certificate | ROSH,ISO9001,UL
|
OFFICE
5SMT Line
2DIP Line
Our Services
Our professional engineering team can put your project into production in a short time. Sample pictures and BOM are needed to make customized products.Also we can supply for the copy of the PCB and PCBA ,so you just sent me the enquiry is ok ,we can do what you need to do !
SMT and Dip Equipment
Advanced SMT Equipment:
* HITACHI Screen Printer
* FUJI NXT-2 & FUJI XPF-L Modules
Assembly Production Machines:
* 2 automatic YAMAHA YS24 and YS12 SMT lines and 3 automatic MX400 and MX200 STM lines
* 2 DIP Dual wave soldering line
* 2 manual soldering production line
Capacity:
* 180 million points per month
Component range:
* 0201,0402,0603,0805,1206,1608,2125,3216
* Fine Pitch QFP to 0.2mm
* BGA, Flip Chips, Connectors
* BGA to 0.2mm
Testing Equipment:
* Printing Solder Paste Test
* AOI(Automatic Optical Inspection)
* X-Ray for BGA and QFN Testing
* Function Testing
* In Circuit Testing
* Testing Service
Every board is carefully examined by our dedicated inspection team using AOI and high magnification viewers. Using our X-Ray machine, we test PCBs to component level and all wiring is fully inspected and tested. Flash testing and earth bonding tests can also be undertaken where required.
Package & shipping cost
FAQ
Q: Does STHL technology co.,ltd is a ture factory?
A: Of course, we are the true factory. Welcome to visit our factory at Shenzhen , and we can talk with skype video to visit our factory at frist.
Q: Do you have a capability to offer one-stop service, include ODM ?
A: Yes, STHL company have 4 hardware engineers 6 software engineers and 2 structural engineers. Can offer ODM product include industry control , smart home .instrumentation , and so on .
Q: How can you make sure the components quality?
A: We buy the components from the A-level agents, and have IQC workers test
Q: Do you have ISO9001 certificate?
A: Yes ,STHL passed the UKAS ISO9001.
Q: How long is the delivery time ?
A: Make pcb board need 7-12workdays, and pcb assembly need 3-5workdays ,Test the function need 1-2workdays .
Q: Which way to ship?
A: Ship by DHL, UPS, TNT, FEDEX, EMS etc ,3-4days arrive.
Shenzhen STHL Technology Co., Ltd.
A professional PCB& PCBA design, product, sale manufacturer, established in 2010. Specially dedicate to Security, Industrial Automation, Medical, Household Appliance PCBA and Electrics products finished assembly. Currently with 100 workforce and covering 2, 000 square meters area, our products exported worldwide including North American, & South American, European Countries and Asia, etc.
We have 4 strong and professional, R&D engineers, 6 SMT production lines 2 DIP production lines, 1 final assembly production lines and many advanced testing instruments. Our current annual production capacity is more than 4, 000, 000 PCS PCBA (circuit control board) and 100, 000 sets electronic end products assembly. Relying on high quality, high efficiency, and prompt way, we can provide various, multi-layer, customized PCBA, Final assembly and tailor-made service to our customers. Small and medium orders. Also be welcome.
Main Products:
1. PCBA OEM
PCBA Application:
*Telecommunication PCBA: Exchange Board, Router, GPRS
*Automation PCBA: Automatic Refueling Machine, Automatic Cutter, Inverter, Electricity Monitoring System, Frequency Conversion Controller, Electric Welding Machine, Elevator, Escalator
*RFID technology: Active RFID, Passive RFID
*Power Supply and New Energy: Industrial Power Supply, LED Driving Power, Solar Power System, Wind Power System
*Medical Equipment PCBA: Color Doppler Ultrasound Instrument, Medical Monitor
*Financial PCBA: Currency count machine, POS machine, Teller machine.
*Household Appliance PCBA: Coffee Maker, Blender, Soybean Milk Machine, Cleaner, Hair Straightener, Electric Toothbrush.
2. PCBA ODM: Embedded Industrial Control Product, Power Supply, Household Appliance Control Board
3. End Electronic Products Assembly and relative EMS
Metal, Plastic, Rubber or other material industrial design services.
Charnas has sophisticated R&D management system, Quality Assurance System, Supply Chain Management System, and Environmental Protection Management System. Based on our solid smartpower, considerate service, excellent core technology, added value service to customers, we have been approved and trusted by our home and abroad well -known customers. Company to pursue' Keep Searching for Development Innovation, Insist on keeping Improving, Charnas is on its way to be the best electronic products EMS company in the world.
As a developing enterprise, we are willing to do everything possible for customers, work together to create a new win-win situation continuously with you.
