Ligao (Zhongshan) Electrical Appliance Co., Ltd. >> China Paco 500W 12V Power Inverter with Ce

China Paco 500W 12V Power Inverter with Ce

China Paco 500W 12V Power Inverter with Ce
Price: Negotiable/Piece
Min Order: 500/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: PI 500W

Product Description

China PACO 500W 12V Power Inverter With CE






Product Description






1.Low-Battery Alarm/Shutdown
2.Overload,Reverse.Shortage Protection
3.CE/ROHS approval





Function and characteristic
1. Input range of 12V DC to 24V DC;
2. Output voltage range of 115V AC or 230V AC;
3. For use in cars, boats, trucks, trailers and mobile homes;
4. Take the power inverter to camping and get AC power for lamps, radios or TVs.
5.In an emergency such as blackout, attach the power inverter to your car battery or portable battery and get power to run your appliances;
6.Ultra-Compact Metal Housing

Small and rugged; stored easily in any tool box, briefcase or glove compartment.
7.Low-Battery Alarm/Shutdown
Automatically detects low voltage and shuts down to preserve your battery.
8.Integrated Fuse Protection
Protects your battery and power inverter from damage due to outlet overload.
9.Illuminated On/Off Switch
Shows power inverter under operating and battery charged sufficiently.



Specifications





IdealPI-500
Output power (Countinuous Watts)500
Output power (Peak Watts)1000
Nominal Input Voltage (DC)12V (10~15V)/24V (20~30V)
Nominal Output Voltage (AC)115V AC or 230V AC
Frequency50Hz or 60Hz +/- 5%, Crystal controlled
Output RegulationIntelligent Pwm +/- 0.5%
Output WaveformModified Sine wave
Low Battery-voltage Alarm (Volts)10.5 +/- 0.5V   /   21+/-1V
Low Battery-Voltage Shutdown (Volts)10+/- 0.5V   /    20+/-1V
Efficiency85~90%
Thermal Protection65ºC +/-5 ºC
OverloadShut down / Alarm
Battery Polarity ReverseBy Fuse
Output ShortOutput short Cicuit Protection
With Cooling FanNo
AC OutletUSA type: 2AV Outlets, European type:1AC outlet
Replaceable Fuse (12V DC)3 x 20A
Replaceable Fuse (24V DC)3 x 10A
Product Dimension (L x W x H)cm15.5 x 16.4 x 6.2
Weight1.75kg
Qty (PCS)6
Carton Measurement (cm)53.5 x 28 x 27.5
Container 20FT (PCS)4080
