| Prod Model: |
ZVF300-G200/P220T4M |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power Range: |
200kw |
| Input Voltage: |
440V.380V |
| Input Frequency: |
50Hz/60Hz |
| Output Frequency: |
0.00-600Hz |
| Net Weight: |
230kg |
| Gross Weight: |
248kg |
| Packing Size: |
1760*775*510mm/1PCS |
| Brand: |
Chziri.Ce |
Product Description
ZVF300 series frequency inverter suitable for many kinds of general model of high quality, low noise and multi-purpose. It characteristic as follow:
1. Adopt the Magnetic Flux Vector PWM control algorithm, advanced technique, resonant wave of output current is few and high efficiency.
2. Good at characteristic of low frequency operation, It can output of torsion on low frequency reting.
3. Maximum carrier wave frequency are 15kHz, It can oeration with Static sound
4. Numeral keyboard, simulation Potentiometer, Exterior intelligence terminal, COM and etc that so many kinds of input mode. The control mode is extremely agility.
5. Prolific function, for example: Voltage control in automatism, dead-time compensation, automatic slip compensation and DC braking, restarting after power interruption and etc. It can according to the require of control of high precision and complexity.
6. Program operation(multiple speed), Pendulum-frequency operation. In sets at the PI regulator, It can structure expediently to satisfy different need automatization control system.
7. In sets RS485 standard communication interface, It can realize the networking control or the proportion gearing control.
8. Consummation malfunction management and protection function, and guarantee the frequency inverter and motor are not damaged in any malfunction situation.
9. Advanced technology, compact-structure and the product contour artistic is natural.
Scope of application:
ZVF300 series frequency inverter applied at the metallurgy, plastomer, textile, food-stuff, petroleum, chemical industry, paper-making, pharmacy, printing, building material, crane and all kinds of machine equipment. As AC asynchronous motor's driving and speed control.
| Ambient | Place to be used | Indoor location free from direct exposure to sunlight,high humidity or dew condensation,high levels of dust, corrosive gas,inflammable gas,oil mist salt and ect |
| Altitude | Below 1000M |
| Ambient Temperature | -10~+45C, [Bare machine:-10~50C] |
| Humidity | 20~90% RH without dew condensation |
| Vibration | <0.5G |
| Storage Temperature | -20~+60C |
| Structure | Protective Class | IP20 |
| Cooling system | Forced air cooling |
| Installation | Wall mounted or floor-type actuator |
1. CHZIRI Electrical located in Liushi, Wenzhou -Capital city of low voltage electrical products in China. There have many different factories produce low voltage electrical products. Such as fuses. Circuit breakers. Contactors. And pushbutton. You can buy complete components for automation system.
2. Since 1998. CHZIRI Electrical begin to produce reducer and gear boxes. In 2003. CHZIRI Electrical begin to produce frequency inverter and soft starter and control panels and related products.
3. CHZIRI Electrical is frequency inverter and soft starter manufacturer. We have big stock in warehouse. So we can offer prompt delivery and professional technical support and fast after sale service.
4. CHZIRI Electrical can also provide clients with customized control panel. We
Can design MCC panel and inverter cabinet & soft starter cabinet according to clients the wiring diagram.
5. CHZIRI Electrical also respectively obtained ISO9001, CE, CCC certificates.
6. CHZIRI Electrical set up branch offices in more than 30 cities and established a perfect, professional and efficient sale-and-service system. At the same time, ZIRI Electrical also working up international sales net. CHZIRI products have been exported in large quantity to Europe, South America, Southeast Asia, Middle East.
7. CHZIRI Electrical also go aboard to attend the fair every year.
8. OEM service can be offered.
9. CHZIRI Electrical can offer the optional parts for frequency inverter. Such as braking unit. Braking resistors. EMI Filter. Reactor. CHZIRI Electrical can offer the whole solution for automation system.
10. CHZIRI Electrical adhere to the eximious tradition of technical innovation, continue to introduce new generation products to meet market demands. Make great strides forward gradually to high-end application domain, and strive to shoulder heavy responsibilities to create a full of hope for the future.
