| Prod Model: |
ZVF9V-M0007S2DR |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
0.75kw |
| Output Frequency Hz: |
0.01~400.00Hz |
| Input Power Frequency: |
50/60Hz |
| Control Mode: |
Sapwm Space Vector Control |
| Torque Boost: |
0.0~20.0% |
| Overload Capacity: |
150% Rated Current for 1 Minutes |
| V/F Characteristic: |
Linear, Quadratic |
| External Signal: |
Terminal 0-10V, 4~20mA, 0~10kHz, up/Down |
| Output Type: |
Triple |
| Principle Of Work: |
Vector Control Transducer |
| Switch Mode: |
High Carrier Frequency PWM Control |
| Main Circuit Type: |
Voltage |
| Application: |
Frequency Drive |
| Brand: |
Chziri, OEM |
Product Description
ZIRI Electrical produce low voltage AC drive. Power range 0.4kW from 600kW. Output Frequency: 0~600Hz. Built-in RS485 port. The keypad can be removed. Key parts are imported from Europe. Such as capacitor Import from Japan, Infineon IGBT and MITSUBISHI. Imported from Germany).
The AC drive has the good effect energy conservation, fine speed adjustment performance, stable operation, stable operation, electrical machinery soft start, protect function and self diagnostics fault and other advantages.
Technical Indications:
1. Control Mode: SAPWM vector control.
2. Output Frequency range: 0.00~400.00HZ
3. Operation command selection: Keyboard control, Terminal Control, Multi-stage control, External analog voltage input control. External analog current input control. RS485 control.
4. Frequency setting Mode: Digit keypad setting, Analog setting ( current, voltage signal ). Remote communication setting, Multi-step speed setting. Terminal assembled setting. PID closed-loop setting.
5. Start torque control: 0-20% can be adjusted.
6. Carrier frequency range: 1.0K~15KHz
7. DC current braking: Start and stop DC current braking can be adjusted solely.
8. Automatism voltage Modulate: ( AVR): Automatically keep output voltage stable when input voltage fluctuation.
9. Automatic limiting current: Can limit the Maximum current of the motor. And can protect the inverter and the motor reliably.
10. PLC programmable control: Single Cycle, continuous loop, wobble control and are suitable for all kinds of applications
11. Input, output terminal are programmable and It's convenient for user.
12. Analog signals output, voltage and current can be selected.
| Inverter Model | Voltage
(V) | Power
(KW) | Current
( A) | Dimension (mm) |
| H | W | A | B | D | d |
| ZVF9V-M0007S2 | 220V
| 0.75 | 4.0 | 151.0 | 100 | 140.0 | 89.5 | 116.5 | 5 |
| ZVF9V-M0015S2 | 1.5 | 7.5 | 151.0 | 100 | 140.0 | 89.5 | 116.5 | 5 |
| ZVF9V-M0022S2 | 2.2 | 10 | 151.0 | 100 | 140.0 | 89.5 | 116.5 | 5 |
| ZVF9V-M0007T4SDR | 380V | 0.75 | 2.3 | 151.0 | 100 | 140.0 | 89.5 | 116.5 | 5 |
| ZVF9V-M0015T4SDR | 1.5 | 3.7 | 151.0 | 100 | 140.0 | 89.5 | 116.5 | 5 |
| ZVF9V-M0022T4SDR | 2.2 | 5.0 | 151.0 | 100 | 140.0 | 89.5 | 116.5 | 5 |
CHZIRI Clients
FAQ 1. Can I get some samples?Yes, Sample order is available for quality check and market test .But you have to pay for it .2. What's delivery time?It usually takes about 3-5 working days for small order and 10-15 days for big order .3. What's your payment terms?We usually accept all kinds of payment terms .Such as T/T,L/C, Western Union.Cash.4. What's your warranty terms?We offer 12 months warranty time .5. Do you have the products in stock?Depends on your request ,We have standard models in stock. Some special products and big order will be newly produced according to your order .6. Can I mix different power in one container .Yes ,Different models can be mixed up in one container ,even one order .7. How does your factory do the quality control?Quality is priority ,we always attach the importance to quality control from the beginning to the end of the production .every product will be fully assembled and carefully tested before packing and shipping .8. Can you sell spare parts ?If you are using CHZIRI products .we can sell spare parts to you . But we couldn't sell the half-finished products.9.I would like to know if you have a partner for export?Yes .CHZIRI Electrical have the right to export and can sell electrical product all over the world..10. Can you make the inverter and soft starter control boards (switchgear)?Yes. We have a lot of experience to design frequency inverter and soft starter cabinet according to your request . But you can send us the wiring diagram .11.Can the inverter connect with computer?Yes .All inverters have built-in RS485 port .and support Modbus communication protocol. 12.How can I trust you ?The core of CHZIRI electrical culture is honesty and loyalty .our company has been audited and approved ISO9001,CE.CCC. Assessment report will could be sent to you by e-mail .also .we are the made-in-china's gold supplier since 2008.Now we have clients all around the world .
1. CHZIRI Electrical located in Liushi, Wenzhou -Capital city of low voltage electrical products in China. There have many different factories produce low voltage electrical products. Such as fuses. Circuit breakers. Contactors. And pushbutton. You can buy complete components for automation system.
2. Since 1998. CHZIRI Electrical begin to produce reducer and gear boxes. In 2003. CHZIRI Electrical begin to produce frequency inverter and soft starter and control panels and related products.
3. CHZIRI Electrical is frequency inverter and soft starter manufacturer. We have big stock in warehouse. So we can offer prompt delivery and professional technical support and fast after sale service.
4. CHZIRI Electrical can also provide clients with customized control panel. We
Can design MCC panel and inverter cabinet & soft starter cabinet according to clients the wiring diagram.
5. CHZIRI Electrical also respectively obtained ISO9001, CE, CCC certificates.
6. CHZIRI Electrical set up branch offices in more than 30 cities and established a perfect, professional and efficient sale-and-service system. At the same time, ZIRI Electrical also working up international sales net. CHZIRI products have been exported in large quantity to Europe, South America, Southeast Asia, Middle East.
7. CHZIRI Electrical also go aboard to attend the fair every year.
8. OEM service can be offered.
9. CHZIRI Electrical can offer the optional parts for frequency inverter. Such as braking unit. Braking resistors. EMI Filter. Reactor. CHZIRI Electrical can offer the whole solution for automation system.
