CIP cleaning system |
| Material: |
SUS304 |
| Fuel: |
acid or alkali |
| Certification: |
ISO |
Product Description
Split type full-auto CIP cleaning systemThe operating principle of the full auto CIP cleaning system refers that the tank body, pipelines, pumps and all valves and also the whole processing line are cleaned on line no need to disconnect the pipes or the equipments, all cleanings are done at the closed circuit.
Configuration table| Item | Brand or supplier |
| Controller | Siemens PLC, color screen, full automatic control |
| Conductivity meter | Germany JUMO |
| Flow switch | Germany IFM |
| Pneumatic valve | Germany GEA |
| Concentrated acid/alkali adding system | USA sandipipe diaphragm pump |
| Level alarm | at high/low level |
| Steam pressure reducer valve | Spirax Sarco from UK |
| Temperature regulating system | Spirax Sarco from UK |
| Temperature sensor | Germany JOMO |
| Electromagnetic flow meter | Germany E+H |
| Frequency converter | Danfoss |
| Tank thickness | Inner shell of CIP tank is 3mm;Outer cladding is 1.5mm |
| PU insulation, heating by plate heat exchanger, separately standing tanks, material SUS304, in acid/alkali tank with vertical agitator, flow rate 10-20m³/h, pump head 24 meters, stainless steel control box. |
Main components list| Item | parts |
| CIP cleaning liquid storage tanks | Include acid tank, alkali tank, hot water tank, clear water tank |
| Concentrated acid and alkali | single layer storage tank for each |
| Pumps | CIP forward and return pumps |
| Two diaphragm pumps for acid/alkali concentrate |
| Heat exchanger | Plate or tubular type |
| Control cabinet | One electrical appliance box |
| Pipes and valves | One set of controlling pipe and valve component |
| Electrical appliance material | One set of auto-performance components and parts and the electrical appliance material. |
| CIP cleaning liquid storage tank | 1000L-10000L. |
| Cleaning recycles | Single circuit, double circuits, three circuits ,four circuits or multi circuit operating at the same time; We can customized as to customers' need |
| Heating type | Plate type, coil tube type, tubular type. |
This system adopts the PLC program to control, with the colored touch --screen to operate and display the whole process flow and also the each controlling parameter. The temperature of the cleaning liquid can be installed. It can set the PH value , the cleaning time, cleaning sequence , and also the PH value. With the system malfunction alarm device.
The operating principle of the system:
1. Auto-flow control for the cleaning solution
2. Automatically regulate the temperature of the cleaning liquid.
3. Auto-compensate for the inside tank liquid level.
4. Automatically-compensation for the acid and alkali concentration.
5. Auto transfer from one cleaning liquid to another.
6. System auto alarm-device
Condition: NewBrand name: Shanghai Beyond;
Type: whole processing Line/turnkey project/fruit and vegetables processing/dairy processing/beverage processing
Voltage: 220v/380v
Power(W): 100-200kw
Weight: Different size different weight/customized
Dimension(L*W*H): Different size different dimension/customized
Certification: CE&ISO
Warranty: 12 months/1 year
After-sales Service Provided: Engineers available to service machinery overseas
Main material: SUS304 or SUS316
Control type: automatic, semi-automatic
energy consumption: Low consumption with high efficiency
capacity: 500-10000L/H-customized
installation period: 1-3monthsPeriod time: 30 days-120 days
Cups material: pouches, paper box, glass bottle, pet bottle, glass bottle Product storage condition: room temperature; low temperature; Related machinery of fruit processing lineFruit storage silo-- Washing, sorting machine-- Grading/classifier machineSqueeze extractor--Juice refiner-separator-evaporator-- Juice concentrate productFruit flesh/pulp collector-sterilizer--filling machine-fruit fleshEssential oil refiner-fruit oilFruit residues collector-animal feedSoaking extraction, pre-cooking, pulping, quick freeze, stemmer, ultra-filtration, decolor, destoner, crusher, stone washer, brusher washer, pine apple extractor, refiner, enzymolysis, filtration, CIP cleaning systemRelated machinery of dairy(cheese, butter, milk, yoghurt,cream) processing lineLarge outdoor storage tank, agitator tank, jacket tank, ferment growing tank, emulsification tank, milk weighing, milk receiving/collecting, extracting, pasteurizer yoghurt, UHT, HTST pasteurizer, plate pasteurizer, tubular UHT sterilizer, spraying type pasteurization, cooling tunnel, bottle tilting sterilization chain, CIP cleaning system, full-auto CIP, semi-auto CIP, evaporator, curd cutting, whey draining, cheese making, scalding/stretching/molding, cheese vat, mozzarella cheese, cheddar cheese, blending system, pre-pasteurization, cream separator system, powder melting, dissolving system, homogenizer system, turn-key project.
