Prod Model:	HC-MS-063
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	0.68''*6.30''
Environmental Friendly:	Raw Material Pass RoHS, SGS Test
Surface:	Grim Adhesive
Touch Feeling:	Excellent Touch Feeling
Material:	PET
Type:	Convex
Application:	With Remote Control

Product Description

Grim Adhesive Membrane Switch

Description:
Membrane switch with grim adhesive
PET 0.05 as metal dome retainer
5 pins connector with Nicomatic

Product Description
All our circuit, graphic overlays and membrane switches are thoroughly tested and inspected before they leave our factory.
Flexible Printed Circuit
Material: Polyester witch conductive sliver and Carbon
Rear Adhesive: 3M 467MP, 3M 468MP, 3M9472LE, etc

Performance indicators:
1. Operating voltage: 35V DC
Operating current: 100mA 1W
Contact resistance: < 100 Ohms
Open circuit resistance: ≥ 10MΩ At 100V(According the trace length and materials to confirm)
Insulation resistance: > 100MΩ 250V DC
Contact bounce: ≤ 5ms Dielectric withstand: 250VRms (50-60Hz 1min)
Life expectancy: Flat type ≥ 5 million times, tactile type: ≥ 1 million times

Working life: More than one million times
Unit price: Negotiable/
Shipment terms: EXW
Payment terms: T/T
Origin: Dongguang
Packing: In carton

Product Description
Materials: Textured PC, gloss PC with matte finish, Autotype PET and PVC
Thickness: 0.5, 0.7, 0.8 and 1.0mm
LED windows: Clear or translucent with all colors
Embossed keys: Polydome and rim
Metal dome: Brand of Nicomatic and Innovan, nickel and gold plated
Tail: With mylar and UV
Connector: Nicomatic, FCI, Molex and Zif
Adhesive: 3M 467, 468, 3M9495, 3M7945 and 3M7959

Notice: We have the capacity to provide you membrane switches with other special requirements, such as water proof, Shielding, Windows/Lens Coating, Embedded LEDs, UV glossy/ matte/ textured, etc.

	Technical Specification Of Membrane Swithc
wire lead resistance:	<1Ω/CM	Life time:	>1 Million times
rated current:	25-100mA,0~30V DC	Operation Temperature:	-104°F~158°F
Rated Voltage:	<50V, DC	Operation Humidity:	at104°F,<98%RH
Insulation resistance:	<100MΩ,250V DC	Dome springback time:	<5 msec
Switch travel:	Flat Type 0.05-0.3mm	Base Material voltage withstand:	1500 V DC
Switch travel:	tactile type:0.3-1.5mm	Tail flexiblility:	any angle within 180 degree
