Class 130, 155, 180 200 Grade Enameled Copper Wire

Prod Model:	EAS
Type:	Insulated
Conductor Type:	Solid
Conductor Material:	Copper Clad Aluminum
Insulation Material:	PVC
Certification:	RoHS
Range Of Application:	Supermarket,Shop,Store
Brand:	Sansen
Application:	Alarm

Product Description

Colored Enameled Flat/Rectangular Magnet Copper Wire For Motor Winding

1.Data


Diameter	3.00mm×8.5mm
Test Item		Unit	Technical Requirement	Test Result
Bear Conductor		a	±0.03	3.01
		b	±0.07	8.49
Thickness of insulation film		a	0.12~0.17	0.14
		b	0.12~0.17	0.15
Resistance		Ω/	<0.017241	0.017116
Elongation			>15%	19%
Winding test			≤1d Winding, no cracking	No cracking
Tensile Test		%	a(mm)      ≤2.5   30%      >2.5   32%	38%
Resistance to heat shock		°C	200°C insulation film b side no cracking	Within half an hour, no cracking
Breakdown Voltage		KV	≥2.0KV	6.4,6.8,6.3,7.0,6.5
package			Meet Export Standards	Pass
Quality Control Result			Pass

2. Insulatig Varnish
1) Polyester enameled aluminum wire, class 130
2) Modified polyester enameled aluminum wire, class 155
3) Polyesterimide enameled aluminum wire, class 180
4) Polyester (imide) coated with polyamide-imide enameled aluminum wire, class 200
5) Polyimide enameled aluminum wire, class 220

FAQ
Q1. What kind of products can your company supply?
A: We specialize in supplying network cable, coaxial cable, power cable ,control cable , telephone cable, speaker cable and ect.

Q2. What's your MOQ?
A: The MOQ of long meter cable is 50 km, or we can negociate.

Q3. What's your delivery time?
 A: Our delivery time is about 15-20 days after comfriming the deposite, it is based on the quantity of the order.

Q4. What are your payment terms?
A: Normally, we accept T/T in advance, as for other payment term, we can negociate with you.

Q5. What's your trade term ?
A: We can accept FOB, CIF, EXW term.

Q6. What's your conventional packing ?
A: 100m/plastic or wooden drum, 305m/wooden drum or color box. However, we can produce according your demand.

Q7. Can your factory customize cables based on clients' samples or data sheet ?
A: Yes, we can.

Q8. Can you offer me a free sample?
A: Yes,we do,that is a start of business-I think. And you will only pay the cost of delivery,which we will return it to you when you put the order.
